Fuse Replacement - HERO SPLENDOR+ PROGRAMMED FI Manual

Always ensure the battery is fully charged
•
before installation.
Ensure the battery leads are properly
•
connected to the battery terminals during
installation.
Battery removal
Make sure the ignition switch is "O
•
Remove the right side cover (1) by
•
removing side cover screw (2). Pull out lug
(3) from the grommet and slide the cover as
per direction indicator (4).
1
(1) Right side cover (2) Side cover screw
(3) Lug
Remove the fuse box (B).
•
Remove the battery clamp bolt (5) and the
•
battery clamp (6).
FF" ( ).
4 3
2
(4) Direction indicator
7
(B) Fuse box
(6) Battery clamp
(8) (+)ve terminal
Disconnect the (-)ve terminal lead (7)
•
from the battery first, then disconnect the
(+)ve terminal lead (8).
Pullout the battery (9) from the battery box.
•
Battery installation
Reinstall in the reverse order of removal. Be
•
sure to connect the (+) terminal first, then
the (-) terminal. ve
Check all fasteners are secured properly.
•

FUSE REPLACEMENT

Fuse box (A) Mounted on the battery :
clamp (1).
Fuse ype: t
Blade fuse
Circuit fuse (2) : 15A, 10A
Spare fuse (3) : 15A, 10A
51
8 B
9 6 5
(5) Bolt
(7) (-)ve terminal
(9) Battery
ve
