Datamax M-Class Mark II Operator's Manual page 39

SET DEFAULTS *
GPIO PORT
GPIO DEVICE
DISABLED
APPLICATOR
BARCODE
VERIFIER
START OF PRINT
LOW PULSE
HIGH PULSE
ACTIVE LOW
ACTIVE HIGH
EDGE
END OF PRINT
LOW PULSE
HIGH PULSE
ACTIVE LOW
ACTIVE HIGH
SLEW ENABLE
STANDARD
LOW PULSE
HIGH PULSE
ACTIVE LOW
ACTIVE HIGH
Chapter 4 – Menu System
Depending upon the RFID MODULE, selecting YES will return these settings:
If MODE = HF, then:
RFID POSITION = 1.10
HF SETTINGS:TAG TYPE = ISO 15693
RETRY ATTEMPTS = 3
--------------------------------------------------------------------------------------------
----
If MODE = UHF, then:
RFID POSITION = 1.10
UHF SETTINGS:TAG TYPE = GEN 2; TAG DATA SIZE = 96-BIT
RETRY ATTEMPTS = 3
Controls the optional Applicator Interface Card's GPIO function, where:
Sets the option to work with a specific device type, where:
Disables the option.
Enables the following GPIO parameters for label applicator functions:
De-asserts Data Ready (DRDY) when the last label starts printing to indicate
•
completion;
FEED allowed at any time; and,
•
Does not de-assert DRDY upon PAUSE.
•
Enables the GPIO Port to work with a bar code verifier.
Selects the type of input signal required to initiate Start of Print (SOP), where:
Triggers printing with a low pulse.
Triggers printing with a high pulse.
Triggers printing with a low signal.
Triggers printing with a high signal.
Triggers printing with a signal edge transition.
Sets the type of output signal generated to indicate End of Print (EOP), where:
Outputs a low pulse upon completion.
Outputs a high pulse upon completion.
Outputs a logic low upon completion.
Outputs a logic high upon completion.
Selects the type of input signal required to initiate label slew, where:
Triggers slew with a low signal.
Triggers slew with a low pulse.
Triggers slew with a high pulse.
Triggers slew with a low signal.
Triggers slew with a high signal.
33
