DC stop
The motor is held with a DC current
(parameter 2-01 DC Brake Current) for a
specified time (parameter 2-02 DC Braking
Time).
DC brake is activated in parameter 2-03 DC
Brake Cut In Speed [RPM] and a stop
command is active.
DC brake (inverse) is selected as a function
for a digital input (parameter group 5-1*
Digital Inputs). The corresponding terminal
is not active.
The DC brake is activated via serial
communication.
Feedback high
The sum of all active feedbacks is above the
feedback limit set in parameter 4-57 Warning
Feedback High.
Feedback low
The sum of all active feedbacks is below the
feedback limit set in parameter 4-56 Warning
Feedback Low.
Freeze output
The remote reference is active, which holds
the present speed.
[20] Freeze Output was selected as a
function for a digital input (parameter
group 5-1* Digital Inputs). The
corresponding terminal is active. Speed
control is only possible via the terminal
functions speed up and speed down.
Hold ramp is activated via serial communi-
cation.
Freeze output
A freeze output command has been given, but
request
the motor remains stopped until a run
permissive signal is received.
Freeze ref.
[19] Freeze Reference was selected as a
function for a digital input (parameter group
5-1* Digital Inputs). The corresponding terminal
is active. The drive saves the actual reference.
Changing the reference is now only possible
via terminal functions speed up and speed
down.
Jog request
A jog command has been given, but the
motor is stopped until a run permissive signal
is received via a digital input.
Jogging
The motor is running as programmed in
parameter 3-19 Jog Speed [RPM].
[14] Jog was selected as function for a
digital input (parameter group 5-1* Digital
Inputs). The corresponding terminal (for
example, terminal 29) is active.
The jog function is activated via the serial
communication.
The jog function was selected as a reaction
for a monitoring function (for example, No
signal). The monitoring function is active.
MG16O102
Operating Guide
Motor check
OVC control
Power unit off
Protection md
QStop
Ramping
Ref. high
Ref. low
Run on ref.
Run request
Running
Danfoss A/S © 01/2017 All rights reserved.
In parameter 1-80 Function at Stop, [2] Motor
Check was selected. A stop command is active.
To ensure that a motor is connected to the
drive, a permanent test current is applied to
the motor.
Overvoltage control was activated in
parameter 2-17 Over-voltage Control, [2]
Enabled. The connected motor is supplying
the drive with generative energy. The
overvoltage control adjusts the V/Hz ratio to
run the motor in controlled mode and to
prevent the drive from tripping.
(For drives with a 24 V external supply
installed only.) Mains supply to the drive is
removed, but the control card is supplied by
the external 24 V.
Protection mode is active. The unit has
detected a critical status (an overcurrent or
overvoltage).
To avoid tripping, the switching frequency
is reduced to 1500 kHz if
parameter 14-55 Output Filter is set to [2]
Sine-Wave Filter Fixed. Otherwise, the
switching frequency is reduced to 1000 Hz.
If possible, protection mode ends after
approximately 10 s.
Protection mode can be restricted in
parameter 14-26 Trip Delay at Inverter Fault.
The motor is decelerating using
parameter 3-81 Quick Stop Ramp Time.
[4] Quick stop inverse was selected as a
function for a digital input (parameter
group 5-1* Digital Inputs). The
corresponding terminal is not active.
The quick stop function was activated via
serial communication.
The motor is accelerating/decelerating using
the active ramp up/down. The reference, a
limit value, or a standstill is not yet reached.
The sum of all active references is above the
reference limit set in parameter 4-55 Warning
Reference High.
The sum of all active references is below the
reference limit set in parameter 4-54 Warning
Reference Low.
The drive is running in the reference range.
The feedback value matches the setpoint
value.
A start command has been given, but the
motor is stopped until a run permissive signal
is received via digital input.
The drive is driving the motor.
