Electrical Installation
5.7.2 Mains, Motor, and Ground for E2h
6X
613 (24.1)
1
515 (20.3)
485 (19.1)
200 (7.9)
0 (0.0)
1
Mains terminals
2
Brake or regeneration terminals
Illustration 5.8 E2h Terminal Dimensions (Front View)
MG16O102
Operating Guide
3
Motor terminals
4
Ground terminals, M10 nut
Danfoss A/S © 01/2017 All rights reserved.
2
721 (28.4)
5
5
3
4
33
