Appendix

10.2 International/North American Default Parameter Settings

Setting parameter 0-03 Regional Settings to [0] International or [1] North America changes the default settings for some
parameters. Table 10.2 lists those parameters that are effected.
Changes made to default settings are stored and available for viewing in the quick menu along with any programming
entered into parameters.
Parameter
Parameter 0-03 Regional Settings
Parameter 0-71 Date Format
Parameter 0-72 Time Format
Parameter 1-20 Motor Power [kW]
Parameter 1-21 Motor Power [HP]
Parameter 1-22 Motor Voltage
Parameter 1-23 Motor Frequency
Parameter 3-03 Maximum Reference
Parameter 3-04 Reference Function
Parameter 4-13 Motor Speed High Limit
[RPM] 3)
Parameter 4-14 Motor Speed High Limit [Hz]
Parameter 4-19 Max Output Frequency
Parameter 4-53 Warning Speed High
Parameter 5-12 Terminal 27 Digital Input
Parameter 5-40 Function Relay
10 10 Parameter 6-15 Terminal 53 High Ref./Feedb.
Value
Parameter 6-50 Terminal 42 Output
Parameter 14-20 Reset Mode
Parameter 22-85 Speed at Design Point
3)
[RPM]
Parameter 22-86 Speed at Design Point [Hz]
Parameter 24-04 Fire Mode Max Reference
Table 10.2 International/North American Default Parameter Settings
1) Parameter 1-20 Motor Power [kW] is only visible when parameter 0-03 Regional Settings is set to [0] International.
2) Parameter 1-21 Motor Power [HP], is only visible when parameter 0-03 Regional Settings is set to [1] North America.
3) This parameter is only visible when parameter 0-02 Motor Speed Unit is set to [0] RPM.
4) This parameter is only visible when parameter 0-02 Motor Speed Unit is set to [1] Hz.

10.3 Parameter Menu Structure

102
VLT® HVAC Drive FC 102
International default parameter value
International
DD-MM-YYYY
24 h
1)
2)
230 V/400 V/575 V
50 Hz
50 Hz
Sum
1500 RPM
50 Hz
4)
100 Hz
1500 RPM
Coast inverse
Alarm
50
Speed 0-HighLim
Manual reset
1500 RPM
50 Hz
50 Hz
Danfoss A/S © 01/2017 All rights reserved.
North American default parameter value
North America
MM/DD/YYYY
12 h
1)
2)
208 V/460 V/575 V
60 Hz
60 Hz
External/Preset
1800 RPM
60 Hz
120 Hz
1800 RPM
External interlock
No alarm
60
Speed 4-20 mA
Infinite auto reset
1800 RPM
60 Hz
60 Hz
