Danfoss FC 102 Operating Manual page 44

Electrical Installation
Terminal
61
68 (+)
group 8-3* FC
Port Settings
5 5
69 (-)
group 8-3* FC
Port Settings
01, 02, 03 Parameter 5-40
Function Relay
04, 05, 06 Parameter 5-40
Function Relay
Table 5.1 Serial Communication Terminal Descriptions
Terminal
12, 13
18 Parameter 5-10
Digital Input
19 Parameter 5-11
Digital Input
32 Parameter 5-14
Digital Input
33 Parameter 5-15
Digital Input
27 Parameter 5-12
Digital Input
29 Parameter 5-13
Digital Input
42
Serial communication terminals
Parameter Default
setting
– – Integrated RC-filter for
cable shield. ONLY for
connecting the shield
in the event of EMC
problems.
Parameter – RS485 interface. A
switch (BUS TER.) is
provided on the
control card for bus
Parameter –
termination
resistance. See
Illustration 5.22.
Relays
[0] No Form C relay output.
operation For AC or DC voltage
[0] and resistive or
inductive loads.
[0] No
operation
[1]
Digital input/output terminals
Parameter Default
setting
– +24 V DC 24 V DC supply
voltage for digital
inputs and external
transducers.
Maximum output
current 200 mA for all
24 V loads.
[8] Start Digital inputs.
Terminal 18
[10]
Terminal 19 Reversing
[0] No
Terminal 32 operation
[0] No
Terminal 33 operation
[2] Coast For digital input or
Terminal 27 inverse output. Default
setting is input.
[14] JOG
Terminal 29
Danfoss A/S © 01/2017 All rights reserved.
VLT® HVAC Drive FC 102
Terminal
Description
20
37
Table 5.2 Digital Input/Output Terminal Descriptions
Terminal
39
42
Description
50
53
54
55
Table 5.3 Analog Input/Output Terminal Descriptions
Digital input/output terminals
Parameter Default
setting
– – Common for digital
inputs and 0 V
potential for 24 V
supply.
– STO When not using the
optional STO feature,
a jumper wire is
required between
terminal 12 (or 13)
and terminal 37. This
set-up allows the
drive to operate with
factory default
programming values.
Analog input/output terminals
Parameter Default
setting
– – Common for analog
output.
Parameter 6-50 [0] No Programmable analog
Terminal 42 operation output. 0–20 mA or
Output 4–20 mA at a
maximum of 500 Ω.
– +10 V DC 10 V DC analog
supply voltage for
potentiometer or
thermistor. 15 mA
maximum.
Parameter Reference Analog input. For
group 6-1* voltage or current.
Analog Input 1 Switches A53 and
A54 select mA or V.
Parameter Feedback
group 6-2*
Analog Input 2
– – Common for analog
input.
Description
Description
MG16O102
