Window Pane Navigation
Use the following chart to assist you in moving between and within the two window panes.
To do this...
Move from left pane to right pane
Move from right pane to left pane
Move within each pane
Right Window Pane Notation
The right window pane shows the contents of the currently selected menu. These contents can include both
submenu items and data fields. Some submenus contain additional submenus and some data fields contain
additional data fields. The following chart explains the notation used to identify these additional items.
This notation...
[+]
<+>
Highlighted menu item
Underlined field

Additional Terminal Menu Window Features

• Tool Tip - provides a brief description of the currently selected mode
• Network Status - displays network status information, Up or Down
• Extended Help - displays information about selected commands (CTRL+A)
• Navigation Help - lists characters used for navigating the terminal menu and session management (CTRL+Z)
• System Time - displays current time

Navigating using the Keyboard Keys

You can use various keystrokes to move through the terminal menu, to manage a terminal menu session, and to con-
figure the system. Press <CTRL+Z> to activate a pop-up screen listing the navigation keystrokes.
64200600L1#T-31A
Total Access 600R User Interface Guide (UIG)
Press this key...
Tab
Enter
Right arrow
Tab
Escape
Left arrow
Backspace
Up arrow
Down arrow
Left arrow
Right arrow
Means that...
More items are available when selected
An action is to be taken, such as activating a test
You can enter data in this field
The field contains read-only information
© 2002, ADTRAN, Inc. Page 17
