N
V
ET
ANTA
P/N 1200740E1
P
E
OWER OVER
Power over Ethernet (PoE) technology provides the ability to detect attached powered devices
(PDs) and deliver 48 VDC to the PD via existing CAT 5 cabling. The NetVanta 6355 PoE units are
fully compliant with the power delivery options called out in the IEEE 802.3af Power over Ethernet
specification. By default, the PoE interfaces discover and provide power to IEEE-compliant PDs.
To disable power detection and supply, use the power inline never command in the command
line interface (CLI). To disable power detection and supply from the Web-based graphical user
interface (GUI), select the Ports page. Then select a single port from the list (e.g., eth 0/1). This
will bring up the port detail page for eth 0/1. On this page, there is a check box to enable power
detection.
G
S
ETTING
TARTED
Two configuration methods are available for your NetVanta 6355 PoE unit:
•
GUI
•
AOS CLI
The GUI lets you configure the main unit settings and provides online guidance and explanations
for each setting. However, using the AOS CLI may be necessary for more advanced
configurations.
A
GUI
CCESS THE
You can access the GUI from any Web browser on your network by following these steps:
1.
Connect the unit to your PC using the Ethernet (ETH 0/0) port on the rear of the unit.
2.
Set your PC to obtain an IP address automatically via Dynamic Host Configuration Protocol
(DHCP), or change your PC to a fixed IP address of 10.10.10.2. If you cannot change the
PC's IP address, you will need to change the unit's IP address using the CLI. (Refer to the
next two sections for instructions.)
3.
Enter the unit's IP address in your browser address line. The default IP address is
10.10.10.1.
4.
You will then be prompted for the user name and password (the default settings are admin
and password).
5.
The initial GUI screen appears.
Quick Start Guide, 61200740E1-13B, July 2008
6355 P
OWER OVER
THERNET
E
THERNET
1
Advertisement
Table of Contents
Related Manuals for ADTRAN NETVANTA 6355
Summary of Contents for ADTRAN NETVANTA 6355
- Page 1 Power over Ethernet (PoE) technology provides the ability to detect attached powered devices (PDs) and deliver 48 VDC to the PD via existing CAT 5 cabling. The NetVanta 6355 PoE units are fully compliant with the power delivery options called out in the IEEE 802.3af Power over Ethernet specification.
- Page 2 NABLE ELNET CCESS The following steps create a password of adtran for Telnet access. By default, Telnet access is enabled with a password of password. Verify that the prompt of your unit displays (config)#. Enter line telnet 0 4 to change the configuration parameters for the Telnet sessions.
- Page 3 Enter login to initiate Telnet access. Enter password adtran to change the login password for the Telnet sessions. Enter exit to return to the Global Configuration mode. Verify that the prompt of your unit displays (config)#. Enter do write memory to save the current configuration.
- Page 4 ONFIGURE PPLICATION More detailed documentation for configuring your ADTRAN unit is provided on the AOS Documentation CD included in your shipment. For more detail on hardware setup, refer to the appropriate NIM quick start guides and the hardware installation guide. For more detail on configuring your system, refer to the AOS Command Reference Guide, configuration guides, and technical support notes.
