Quick Start
Figure 1. 621i ONT
D
ESCRIPTION
The 621i XGS-PON ONT is a Single Family Unit (SFU) Optical
Network Terminal (ONT) that leverages XGS-PON technology for
delivering premium 1 Gbps Ethernet services.
g
NOTE
The "i" in 621i designates that the customer UNI is a 1 Gbps
Ethernet interface, as opposed to a 10 Gbps Ethernet interface on
the non-i version.
The 621i ONT is an indoor unit that supports up to 1 Gbps data
rates.
This document supports the following versions of the 621i ONT.
Description
621i XGS-PON ONT with NA power adapter
(included)
621i XGS-PON ONT with UK power adapter
(included)
621i XGS-PON ONT with EU power adapter
(included)
621i XGS-PON ONT with AUS/NZ power
adapter (included)
Figure 1
illustrates the front LED display.
SDX
621i XGS-PON ONT
1GE SFU
F
EATURES
The basic features of the 621i ONT include the following:
Refer to the following table for a description of each feature in
Figure
Callout
P/N
1287844F1
1287844F2
1287844F3
1287844F4
10 Gbps XGS-PON SC/APC connector (WAN)
1 Gbps Ethernet (RJ-45) Customer Interface
Remote activation and deactivation
Remote firmware upgrades and downgrades
Remote OMCI management as per ITU-T G.988
2.
Description
1
LEDs
2
10 Gbps XGS-PON SC/APC connector (WAN)
3
1 Gbps Ethernet interface
4
Reset Button
5
Power Connection for the Supplied AC to DC Power
Converter (12 V)
6
On/Off button
1
Figure 2. ONT Interfaces
September 2020
61287844F1-13B
2
3
4
5
6
