ADTRAN Total Access 600R Specifications

Product Features

Seamless voice and
I
data integration over
IP, TDM, or ATM based
architectures
Up to 24 analog
I
POTS interfaces
I Optional DSX-1 for PBX
connectivity
I VoIP, TDM, and
VoATM support
Compatible with
I
industry-leading
DSLAMs, aggregation
routers, gateways, soft
switches, and call agents
I Integral full-featured IP
router for data support
and Internet access
I V.35 Nx56/64 DTE
interface
Dynamic bandwidth
I
allocation
I Software upgradeable
from TDM to packet-
based architectures
I Rugged metal case
Optional battery backup
I
I Industry-leading 10-year
North American warranty
Total Access 600 Series
Carrier-class VoIP, TDM, and VoATM IADs
With millions of small- to medium-sized
enterprises existing today, the requirement
for carriers to provide cost-effective integrated
voice and data solutions is growing at a
rapid rate. ADTRAN ® delivers with the
industry-leading Total Access
Access Devices (IADs). The Total Access 600R,
604, 608, 612, 616, and 624 are cost-effective,
fixed-port, IADs designed to support IP , TDM,
or ATM networks. These IADs offer CLECs,
ILECs, RBOCs, and ISPs a means to offer
combined voice and data traffic over a single
network interface terminating at the
customer's premises.
The Total Access 604 provides four analog
FXS voice interfaces while the 608 provides
eight. The Total Access 612 provides 12 fixed
analog voice interfaces, while the Total Access 616
provides 16 fixed analog voice interfaces, and
the Total Access 624 provides a full 24-port
voice capacity for larger voice applications.
These analog FXS interfaces support the
stringent design and full feature set required
by today's carriers. Total Access 600 Series
IADs provide a built-in IP router, Nx56/64
V.35 port for synchronous data applications,
and optional DSX-1 interface, allowing the
customer to combine a broad variety of voice
and data services into a single platform.
The Total Access 600R provides an integral
IP router and no analog ports with digital
voice connectivity provided via the optional
DSX-1 connection.
In applications involving IP network archi-
tectures, a Total Access IAD at the customer
premises consolidates voice (packet, analog,
and digital) and data traffic, and supports IP
voice signaling over any Layer 2 protocol. This
allows service providers to offer traditional
telephony services, while taking advantage of
a lower cost IP network architecture. Total
Access IADs are also interoperable with
leading feature server vendors to support
hosted PBX service offerings. Total Access
IADs enable traditional analog services (POTS
phones, fax machines, and other devices) to
be combined with IP phone support to allow
customers to migrate to IP telephony at their
own pace.
Built with the carrier in mind, the Total
Access 600 Series IADs are housed in a
Integrated
®
rugged metal case and provide the flexibility
needed for quick turn-up in harsh environ-
ments. Wall and desktop mounting options
are available for ease of installation. An
optional ADTRAN battery backup system is
available for added security.
For Telco applications, the T1 loop (end
section) from the last regenerator to the NIU
must contain no more than 22dB of loss.
Additionally, from the NIU to the CPE (e.g.,
CSU), there must be no more than 5.5 dB of
loss. Said differently, with 7.0dB of loss per
1kft of 24AWG wire, this equates to approxi-
mately 3100 feet and 775 feet for the telco end
section and NIU to CPE segments, respec-
tively. For a campus environment in a private
T1 application, the Total Access 600 Series
receiver sensitivity of -36dB allows for a
maximum distance of up to 5,000 feet
between units. The integral IP router provides
a powerful suite of performance and security
features. Each Total Access 600 IAD offers
multiple PVC configurations for simultaneous
access to the corporate network and the
ISP. Supporting NAT and packet filtering,
Total Access 600 IADs secure the corporate
network from unwanted intrusion. All
configuration options, testing parameters,
and passwords are accessed through an
easy-to-use VT100 terminal interface or a
TELNET session.
Using local or remote inband management,
the service provider can turn features, func-
tions, and access ports on and off. For net-
work access, the Total Access 600 IADs have
a single T1, SDSL, SHDSL, or ADSL (604/608)
interface. In addition to all of these features,
the Total Access 600 IADs are backed by an
industry-leading 10-year warranty and
ADTRAN's technical support.
