ADTRAN 6540 Installation And Maintenance Practice
Shdsl 2-wire; shdsl 4-wire ntu
Hide thumbs
Also See for 6540:
- Installation and maintenance manual (50 pages) ,
- Description (4 pages) ,
- Installation and maintenance practice (34 pages)
Related Manuals for ADTRAN 6540
Summary of Contents for ADTRAN 6540
- Page 1 ® SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Document Number: 61230001L1-5C December 2006...
- Page 2 In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this document.
- Page 3 Revision History Revision Date Description August 2003 Initial release June 2004 Revise to include feature modifications December 2006 Revise to include TSCAN feature, Firmware System Release v1.68 Conventions The following typographical conventions are used in this document: This font indicates a cross-reference link. indicates screen menus, fields, and parameters.
- Page 4 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Training ADTRAN offers training courses on our products. These courses include overviews on product features and functions while covering applications of ADTRAN product lines. ADTRAN provides a variety of training options, including customized training and courses taught at our facilities or at customer sites.
-
Page 5: Table Of Contents
Contents Introduction ................1 Description . - Page 6 Rear Panel for Model 6540, AC Powered ........
- Page 7 Contents Table 15. KEY to Symbols used in Table 14 ..........26 Table 16.
- Page 8 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice viii 61230001L1-5C...
-
Page 9: Introduction
6541 SHDSL 2-Wire/4-Wire NTU, DC Powered 1230009L1 6542 SHDSL 2-Wire/4-Wire NTU, Span or DC Powered Note: The 6540 and 6541 model sets are separate AC or DC powered versions of the same base product (for example, P/Ns 1230001 and 1230002; 1230007 and 1230008). Description... -
Page 10: Shdsl 2-Wire/4-Wire Mode, Line Rate
SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Management System VT100 Network VT100 2 - 4-Wire Twisted Pair(s) Total Access 3000 Customer E1 or BAU Equipment REG Applicable Only for 4-Wire (e.g., PABX) SHDSL Customer Nx64k Equipment SHDSL SHDSL (e.g., Router) 2W/4W Figure 1. -
Page 11: Features
Introduction Table 2. 2-Wire/4-Wire Multi-Rate Operation Data Rate Type 2-Wire Mode 4-Wire Mode 200 kbps to 2.312 Mbps (N × 64 400 kbps to 4.624 Mbps (N × 64 kbps + SHDSL Line Aggregate Data Rate kbps + 8 kbps, where N = 3 to 36) 16 kbps, where 2 x N = 3 to 36) In 2-wire mode, 8 kbps of In 4-wire mode, 16 kbps is required for... -
Page 12: Compliance
• • G.703 E1 Port (RJ-45 120 ohms, SELV rated) • • • Optional G.703 E1 Port (RJ-45 to BNC 75 ohms through external adapter, ADTRAN P/N 1225002L1) • • • G.703 E1 Port (BNC, 75 ohms, SELV rated) •... -
Page 13: Installation
1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by ADTRAN could void the user’s authority to operate this equipment. INSTALLATION... -
Page 14: Shipping Contents
SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Shipping Contents The contents include the following items: • SHDSL 2w4w NTU • Mating quick-connect terminal screw block (DC models only) • SHDSL 2w4w NTU Job Aid (product specific) Front Panel Pushbuttons There are four pushbuttons on the SHDSL 2w4w NTU front panel (refer to Table 4). -
Page 15: Figure 4. Front Panel For 6540 And 6541 Models
Installation Express 6500 Series Figure 4. Front Panel for 6540 and 6541 Models Express 6500 Series Figure 5. Front Panel for 6542 Model 61230001L1-5C... -
Page 16: Table 5. Led Indicator Functionality
SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Table 5. LED Indicator Functionality Label Status Description Unit is powered off SHDSL Green Port is trained; no active alarms Yellow Port is trained with a minor active alarm Port is attempting to or is trained with a major alarm Port is not active G.703 Green... -
Page 17: Pushbutton And Led Indicator Interaction
Installation Pushbutton and LED Indicator Interaction The following is a further explanation of the required interaction between the front panel pushbuttons and LEDs. When no port has been selected, (no flashing port LEDs) only the pushbutton is PORT SELECT enabled, and the , and LEDs indicate the status (refer to Table... -
Page 18: Connections
100-240VAC, 50/60 HZ 100 mA Terminal Block (DC) • • 35-80VDC, 250 mA Terminal Block (Span or DC) • 35-80VDC, 250 mA Nx64K X.21 100-240VAC 50/60Hz 100mA V.35/V.36 SHDSL G.703 CONTROL V.28 Figure 6. Rear Panel for Model 6540, AC Powered 61230001L1-5C... -
Page 19: Figure 7. Rear Panel For Model 6540, Dc Powered
Connections Nx64K X.21 V.35/V.36 5-80VDC 250mA SHDSL G.703 CONTROL V.28 Figure 7. Rear Panel for Model 6540, DC Powered Nx64K X.21 100-240VAC 50/60Hz 100mA V.35/V.36 G.703 SHDSL CONTROL V.28 Figure 8. Rear Panel for Model 6541, AC Powered Nx64K X.21 V.35/V.36... -
Page 20: Power Supply
SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Power Supply The various models support one of the following power schemes: • Local AC powered only • Local DC powered only • Span powered with local DC power auto-switchover No adjustments, strapping, or configuration changes are necessary to power the units. The NTU power supply includes “dying gasp”... -
Page 21: G.703 Pinout
Connections Table 9. SHDSL Port RJ-45 Pinout Circuit Name Function Tip 1 2-Wire Pair Tip, 4-Wire Loop, 1 Pair Tip Ring 1 2-Wire Pair Ring, 4-Wire Loop, 1 Pair Ring 6 - 8 Not Connected G.703 Pinout The G.703 port is SELV rated with a rear panel connection of either a 120Ω balanced RJ-45 10, or a TX/RX pair of 75 Ω... -
Page 22: Nx64K Port V.35, Iso 2593, 34-Pin Female Pinout
SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Nx64K Port V.35, ISO 2593, 34-pin Female Pinout Table 11 lists the V.35 pinout information. Table 11. Nx64k Port V.35 34-Pin Pinout V.35 (M34 Interchange Circuit Winchester) Name Function Electrical To/From Characteristics PGND Protective Ground... -
Page 23: V.36 Pinout
This product supports a 37-pin (DB-37) female connection through a 12-inch V.35-to-V.36 adapter cable that complies to ISO 4902 pinouts (ADTRAN P/N 1225004L1). This cable connects to the NTU rear panel V.35 M34 Winchester female connector and provides ID pins to automatically set the Nx64K type to V.36. - Page 24 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Table 12. V.35 to V.36 Adapter Cable Pinouts (Continued) V.35 V.36 Interchange Circuit (M34 (DB-37 Winchester) Female) Pin Name Function Electrical To/From Characteristics TC-B Element Timing V.11 From RC-A Receive Signal V.11 From Element Timing...
-
Page 25: Pinout
Connections X.21 Pinout The SHDSL 2-Wire/4-Wire NTU Product Series rear panel provides a 15-pin female connection that complies with ISO 4903 pinouts. The X.21 interface implementation is intended to be for leased lines with no end-to-end signaling or byte timing. Refer to Table 13 for the X.21 pinouts. -
Page 26: Optioning
SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice OPTIONING Timeslot Cross-Connect Map The SHDSL 2-Wire/4-Wire NTU Product Series supports the configuration of multiple services. A service is comprised of an arbitrary collection of timeslots from the SHDSL interface that are configured through the management interface. -
Page 27: Figure 11. Contiguous Time Slot Allocation
Optioning V.35 Nx64k Service Nx64k Port 14x64k SHDSL Service V.35 Service 2-Wire 4-Wire -OR- E1 Service E1 Service E1 Service NTU Generated (10x64k) (5x64k) G.704 Framing 2-Wire G.703 (E1) Port Figure 11. Contiguous Time Slot Allocation V.35 Nx64k Service Nx64k Port 14x64k SHDSL Service... -
Page 28: Timing Sources
SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Timing Sources Transmit and receive clocking is controlled by a configurable option, , which has the Clk Source following settings: • Internal Clock (derived from internal oscillator with better than 32 ppm tolerance) •... -
Page 29: Figure 14. 6500 Series Menu Tree
Optioning 1. LTU 1. NT 1. Unit Information 1. Unit Mode 2. NTU 2. LT 2. Cross-Connect Map 1. Internal Clock 3. Clock Source 1. Unit Options 2. Nx64 ETC(113)/X 4. Circuit ID 3. G.703 Rx Clock 5. Date and Time 4. -
Page 30: Troubleshooting
SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice TROUBLESHOOTING Local and Remote Loopbacks for Ports and Services For troubleshooting purposes, the SHDSL 2w4w NTU provides five types of loopback tests for each interface port and each data service. • Dual sided •... -
Page 31: Table 14. Loopback Test Summary
Troubleshooting Table 14. Loopback Test Summary Initiating Source SHDSL Port G.703 Port G.703 Service Nx64k Port/ Service Proprietary EOC Local Loopback Request Message ACTIVATE (Initiates one of five loopback types, regardless of the associated Loopback Type Option setting.) Proprietary EOC Local Loopback Request Message DEACTIVATE Proprietary EOC Remote... - Page 32 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Table 14. Loopback Test Summary (Continued) Initiating Source SHDSL Port G.703 Port G.703 Service Nx64k Port/ Service VT100 Remote Inband Loopback OFF VT100 Remote Loopback Single propriet -ary (Initiates a Remote Loopback using proprietary EOC request request messages, regardless...
- Page 33 Troubleshooting Table 14. Loopback Test Summary (Continued) Initiating Source SHDSL Port G.703 Port G.703 Service Nx64k Port/ Service RL (Circuit 140) ON Sends (Initiates a Remote Loopback Inband by sending an inband signal. Signal The remote unit implements a Nx64K service loopback per its Nx64K Loopback Type option setting, if supported, and in the direction of signal...
-
Page 34: Bit Error Rate Tester (Bert)
SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Table 15. KEY to Symbols used in Table 14 Directions Loopbacks No Loop Dual Sided If an NTU: Network (to LTU) Network Transparent Customer Transparent Customer (to NTU) Network Non-Transparent Customer Non-Transparent If an LTU: Customer (to NTU) Customer Transparent... -
Page 35: Searching For Pattern
Troubleshooting Searching for Pattern The SHDSL 2w4w NTU is able to reset the BERT counters when requested to do so by an NMS or VT100 test screen. Injection of a single bit error from the NMS, VT100 test screen, or front panel BERT pushbutton is also possible. -
Page 36: Bad Splice Detection (Tscan)
SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Bad Splice Detection (TScan) The SHDSL 2w4w NTUs provide bad splice protection using the ADTRAN proprietary Runtime ™ TScan 2.0 splice protection feature. TScan splice detection is a non-intrusive algorithm that enables SHDSL 2w4w NTUs to detect anomalies (bad splices) in the copper pair. -
Page 37: Figure 17. Bad Splice Detection (Tscan) Menu
Troubleshooting • If more than one count register exceeds the threshold, then the count that is larger displays as a bad splice. • If two or more count register exceed the threshold and are of equal count, then the distance count closest to the unit displays as a bad splice because the detector is more accurate the closer the anomaly is to the unit. -
Page 38: Restart Bad Splice Detector Screen
SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Practice Restart Bad Splice Detector Screen Configuration The Restart Bad Splice Detector screen (Figure 18) enables a reset of the 24 hour count history. NOTE SHDSL 2w4w NTUs also clear the count history automatically on power-up. -
Page 39: Bad Splice Detection (Tscan) 24 Hour Counts Screen
Troubleshooting Bad Splice Detection (TSCAN) 24 Hour Counts Screen Provisioning The Bad Splice (TSCAN) 24 Hour Counts screen displays the history register. If the unit is handshaking or training, the splice loop rates and count registers do not update. If the unit is trained, it updates the splice current day data registers. But, if there was just a change in trained rate, it updates the loop rates and re-initializes to zero the current day data registers. -
Page 40: Specifications
5.0 watts Physical Dimensions: Height: 3.125 inches Width: 1.14 inches Depth: 10.1 inches Weight: Less than 1 pound Part Numbers 6540, AC Powered: 1230001E1 6540, DC Powered: 1230002L1 6541, AC Powered: 1230007L1 6541, DC Powered: 1230008L1 6542, Span or DC Powered:... -
Page 41: Warranty
Appendix A Warranty WARRANTY AND CUSTOMER SERVICE ADTRAN will replace or repair this product within the warranty period if it does not meet its published specifications or fails while in service. Warranty information can be found at www.adtran.com/warranty. Refer to the following subsections for sales, support, Customer and Product Service (CAPS) requests, or further information. - Page 42 ® Carrier Networks Division 901 Explorer Blvd. Huntsville, AL 35806...
