Bridge Map
This menu is used to permit bridging of packets over this DLCI. Each DLCI or virtual circuit must be
assigned a bridge group. The bridge group treats all virtual circuits as one circuit. Bridge packets des-
tined to be transmitted out a particular bridge group are copied and transmitted individually out each
DLCI in the bridge group. However, incoming bridge packets received from one DLCI are not retrans-
Page 52
S P This option is only available when
ERVER ORT
enabled. This is the port used on the public side.
T This option is only available when
IME
enabled. This is the time since the entry was last used.
I C This option is only available when
N NT
enabled. This is the number of packets that came in.
O C This option is only available when
UT NT
enabled. This is the number of packets sent out.
This option is only available when
DDRESS
enabled. Represents the public address that is being used as the
NAPT address. Read-only.
C This option is only available when
OUNT
enabled. The number of entries in the NAT table. Maximum is
1500.
O This option is only available when
VERFLOW
enabled. A count of the dropped entries due to entry count being
1500 or greater; i.e., the NAT table is full.
The RIP protocol can be specified per DLCI. The possible
selections are Off (default) (meaning no RIP packets are lis-
tened to or sent), V1 (RIP version 1) or V2 (which is RIP
version 2).
This specifies the way the RIP protocol sends out its adver-
tisements.
N ( ) All routes in the router table are advertised out this virtual
ONE DEF
circuit with no modification of the metrics.
S H Only routes not learned from this particular virtual circuit
PLIT ORIZON
are advertised.
P R All routes are advertised, but the routes learned from this
OISON EVERSE
port are "poisoned" with an infinite metric.
This parameter specifies the direction at which RIP adver-
tisements are sent and listened.
T R ( ) RIP advertisements are periodically transmitted and are lis-
X AND X DEF
tened to on this virtual circuit.
T O RIP advertisements are periodically transmitted but are not
X NLY
listened to on this virtual circuit.
R O RIP is not transmitted on this virtual circuit but they are lis-
X NLY
tened to.
