  • Page 1 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Document Number: 61230001E1-5E July 2015...
  • Page 2 In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this documen...
  • Page 3 Revision History Revision Date Description May 2006 Initial revision created from 61230001L1-5B to add RoHS Directive 2002/95/EC compliance December 2006 Revise to include TSCAN features September 2011 Revise Safety and Regulatory Compliance content July 2015 Remove RoHS Directive 2002/95/EC compliance information. Conventions The following typographical conventions are used in this document: This font...
  • Page 4 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Hazard Classifications The following hazard classifications are used in this document: DANGER DANGER indicates a hazard with a high level of risk which, if not avoided, will result in death or serious injury. WARNING WARNING indicates a hazard with a medium level of risk which, if not avoided, could result in death or serious injury.
  • Page 5 Training ADTRAN offers training courses on our products. These courses include overviews on product features and functions while covering applications of ADTRAN product lines. ADTRAN provides a variety of training options, including customized training and courses taught at our facilities or at customer sites.
  • Page 6 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide 61230001E1-5E...

  • Page 7: Table Of Contents

    Contents Scope of this Guide ..........1 In this Guide .
  • Page 8 ADTRAN Technical Support ........
  • Page 9 Figure 4. Front Panel for 6540 and 6541 Models ....... 11 Figure 5.
  • Page 10 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Tables Table 1. Topic List ............1 Table 2.

  • Page 11: Scope Of This Guide

    NTU Product Series SHDSL 2-Wire/4-Wire NTU Scope of this Guide This guide provides instructions for the installation and maintenance of the SHDSL 2-Wire/4- Wire NTU Product Series, including connections, optioning, and troubleshooting. In this Guide This guide contains the topics listed in Table Table 1.

  • Page 12: Introduction

    6541 SHDSL 2-Wire/4-Wire NTU, DC Powered 1230009E1 6542 SHDSL 2-Wire/4-Wire NTU, Span or DC Powered Note: The 6540 and 6541 model sets are separate AC or DC powered versions of the same base product (for example, P/Ns 1230001 and 1230002; 1230007 and 1230008). 61230001E1-5E...

  • Page 13: Description

    Data Terminal Equipment (DTE). It supports applications such as LAN-to-LAN bridging, Frame Relay circuit, and PABX termination. The SHDSL 2-Wire/4-Wire NTU can be used as either of the following: ® • remote unit to the ADTRAN Total Access 3000 multiservice platform (see Figure 1), or •...

  • Page 14: Shdsl 2-Wire/4-Wire Mode, Line Rate

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide SHDSL 2-Wire/4-Wire Mode, Line Rate The SHDSL 2-Wire/4-Wire NTU supports multi-rate line operation (refer to Table Table 3. 2-Wire/4-Wire Multi-Rate Operation Data Rate Type 2-Wire Mode 4-Wire Mode 200 kbps to 2.312 Mbps (N  64 400 kbps to 4.624 Mbps (N ...

  • Page 15: Features

    Nx64k Port V.36 using the V.35 (34-pin male) to V.36 (ISO 4902 37-pin female) 12 • • • • inch adapter cable, ADTRAN P/N 1225004L1; V.11, V.10 electrical Local Management Port (DB-9 female, SELV; V.28 electrical) • • • •...

  • Page 16: Industry Standards Compliance

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Table 4. Product Feature Set Matrix (Continued) Model Number DC Power (5.08 mm (0.2 inc.) 4-pin terminal block shrouded male (MOLEX/ • • • BEAU 861904 or equivalent) Power 100-240 VAC, 50/60Hz, 100 mA •...

  • Page 17: Safety And Regulatory Compliance

    Safety and Regulatory Compliance Safety and Regulatory Compliance Avis sur la sécurité et la conformité à la réglementation Konformitätserklärung zur Sicherheit und Einhaltung von Normen WARNING AVERTISSEMENT WARNUNG • • • Read all warnings and cautions before installing or servicing this equipment.

  • Page 18: Figure 3. Compliance Labels

    1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by ADTRAN could void the user’s authority to operate this equipment. 61230001E1-5E...

  • Page 19: Installation

    HANDLING PRECAUTIONS REQUIRED After unpacking any SHDSL 2-Wire/4-Wire NTU, inspect it for damage. If damage has occurred, file a claim with the carrier, then contact ADTRAN Customer Service. Refer to Appendix A, “Warranty and Customer Service” for further information. If possible, keep the original shipping container for returning the unit for repair or for verification of shipping damage.

  • Page 20: Front Panel Push Buttons

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Front Panel Push Buttons There are four push buttons on the SHDSL 2-Wire/4-Wire NTU front panel (refer to Table The push buttons are recessed to avoid accidental actuation and can be disabled, either individually or as a group, using the management interface.

  • Page 21: Front Panel Leds

    Figure 5 illustrate the two possible front panel configurations. Express 6500 Series 6540 Front Panel Figure 4. Front Panel for 6540 and 6541 Models Express 6500 Series 6542 Front Panel Figure 5. Front Panel for 6542 Model Table 6. LED Indicator Functionality...
  • Page 22 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Table 6. LED Indicator Functionality Label Status Description RLSD/I Nx64K port is inactive or when active, V.35/V.36 “Receive Line Signal  Detector” and X.21 “Indication” control line from the NTU is off. Green V.35/V.36 “Receive Line Signal Detector”...

  • Page 23: Push Button And Led Indicator Interaction

    Installation Push Button and LED Indicator Interaction The following is a further explanation of the required interaction between the front panel pushbuttons and LEDs. When no port has been selected, (no flashing port LEDs) only the PORT SELECT push button is enabled, and the LLOOP, RLOOP, and BERT LEDs indicate the status (refer to Table Table 7.

  • Page 24: Connections

    Terminal Block (DC) 35-80 VDC, 250 mA • • Terminal Block (Span or DC) 35-80 VDC, 250 mA • Nx64K X.21 100-240VAC 50/60Hz 100mA V.35/V.36 SHDSL G.703 CONTROL V.28 6540 Rear Panel Figure 6. Rear Panel for Model 6540, AC Powered 61230001E1-5E...

  • Page 25: Figure 7. Rear Panel For Model 6540, Dc Powered

    Connections Nx64K X.21 V.35/V.36 5-80VDC 250mA SHDSL G.703 CONTROL V.28 6540 Rear Panel Figure 7. Rear Panel for Model 6540, DC Powered Nx64K X.21 100-240VAC 50/60Hz 100mA V.35/V.36 G.703 SHDSL CONTROL V.28 6541 Rear Panel Figure 8. Rear Panel for Model 6541, AC Powered Nx64K X.21...

  • Page 26: Power Supply

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Power Supply The various models support one of the following power schemes: • Local AC powered only • Local DC powered only • Span powered with local DC power auto-switchover NOTICE No adjustments, strapping, or configuration changes are necessary to power the units.

  • Page 27: Shdsl Pinout

    Connections SHDSL Pinout The SHDSL port uses a TNV-3 rated, 135W impedance, RJ-45 connection with signals and pinouts (refer to Table 10). Table 10. SHDSL Port RJ-45 Pinout Circuit Name Function Tip 2 4-Wire Loop, 2 Pair Tip Ring 2 4-Wire Loop, 2 Pair Ring Not Connected Tip 1...

  • Page 28: Nx64K Port V.35, Iso 2593, 34-Pin Female Pinout

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Nx64K Port V.35, ISO 2593, 34-pin Female Pinout Table 12 lists the V.35 pinout information. Table 12. Nx64k Port V.35 34-Pin Pinout Interchange Circuit V.35 (M34 Winchester) Electrical To/From Name Function Characteristics PGND Protective Ground...

  • Page 29: V.36 Pinout

    This product supports a 37-pin (DB-37) female connection through a 12-inch V.35-to-V.36 adapter cable that complies to ISO 4902 pinouts (ADTRAN P/N 1225004L1). This cable connects to the NTU rear panel V.35 M34 Winchester female connector and provides ID pins to automatically set the Nx64K type to V.36.
  • Page 30 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Table 13. V.35 to V.36 Adapter Cable Pinouts (Continued) Interchange Circuit V.35 V.36 (M34 (DB-37 Electrical Winchester) Female) Name Function From Characteristics TC-B Element Timing V.11 From RC-A Receive Signal V.11 From Element Timing RC-B...

  • Page 31: Pinout

    Connections X.21 Pinout The SHDSL 2-Wire/4-Wire NTU Product Series rear panel provides a 15-pin female connection that complies with ISO 4903 pinouts. The X.21 interface implementation is intended to be for leased lines with no end-to-end signaling or byte timing. Refer to Table 14 for the X.21 pinouts.

  • Page 32: Optioning

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Optioning Timeslot Cross-Connect Map The SHDSL 2-Wire/4-Wire NTU Product Series supports the configuration of multiple services. A service is comprised of an arbitrary collection of timeslots from the SHDSL interface that are configured through the management interface.

  • Page 33: Timeslot Allocation

    Optioning Timeslot Allocation The SHDSL timeslots are individually mapped to the required G.703/G.704 and Nx64k service timeslots on a one-to-one basis. As illustrated in Figure 11 Figure 12 on page 24, both contiguous and non-contiguous service allocations are allowed, as long as the chrono- logical transmission ordering of timeslots is maintained.

  • Page 34: Timing Sources

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide P o r t ( E 1 ) G . 7 0 3 G . 7 0 4 F r a m i n g ( 1 0 x 6 4 k ) ( 5 x 6 4 k ) E 1 S e r v i c e N T U G e n e r a t e d...

  • Page 35: Menu Tree

    Optioning Menu Tree The User Interface for the SHDSL 2-Wire/4-Wire NTU Product Series consists of a number of menu screens designed to aid in maintenance and troubleshooting. The SHDSL 2-Wire/4- Wire NTU menu tree (see Figure 14 ) is a visual map that can be used to locate configuration information and provisioning options.

  • Page 36: Figure 14. 6500 Series Menu Tree

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide 1. LTU 1. NT 1. Unit Information 1. Unit Mode 2. NTU 2. LT 2. Cross-Connect Map 1. Internal Clock 3. Clock Source 1. Unit Options 2. Nx64 ETC(113)/X 4. Circuit ID Main Menu 3.

  • Page 37: Troubleshooting

    Troubleshooting Troubleshooting For troubleshooting, the SHDSL 2-Wire/4-Wire NTU provides loopback tests, an internal Bit Error Rate Tester, and bad splice detection. Local and Remote Loopbacks for Ports and Services For troubleshooting purposes, the SHDSL 2-Wire/4-Wire NTU provides five types of loopback tests for each interface port and each data service.

  • Page 38: Table 15. Loopback Test Summary

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Table 15. Loopback Test Summary Initiating Source SHDSL Port G.703 Port G.703 Service Nx64k Port/Service Proprietary EOC Local Loopback Request Mes- sage ACTIVATE (Initiates one of five loop- back types, regardless of the associated Loopback Type Option setting.) Proprietary EOC Local...
  • Page 39 Troubleshooting Table 15. Loopback Test Summary (Continued) Initiating Source SHDSL Port G.703 Port G.703 Service Nx64k Port/Service VT100 Remote Loopback Single propriet -ary (Initiates a Remote Loop- back using proprietary request EOC request messages, message regardless of remote unit's associated Loopback Type Option setting.) VT100 Remote Loopback Front Panel Pushbuttons...
  • Page 40 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Table 15. Loopback Test Summary (Continued) Initiating Source SHDSL Port G.703 Port G.703 Service Nx64k Port/Service RL (Circuit 140) ON Sends (Initiates a Remote Loop- Inband back by sending an inband Signal signal.

  • Page 41: Bit Error Rate Tester (Bert)

    Troubleshooting Table 16. KEY to Symbols used in Table Loopbacks Directions No Loop Dual Sided If an NTU: Network (to LTU) Network Transparent Customer Transparent Customer (to NTU) Network Non-Transparent Customer Non-Transparent If an LTU: Customer (to NTU) Customer Transparent Network Transparent Network (to LTU) Customer Non-Transparent...

  • Page 42: Searching For Pattern

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Searching for Pattern The SHDSL 2-Wire/4-Wire NTU is able to reset the BERT counters when requested to do so by an NMS or VT100 test screen. Injection of a single bit error from the NMS, VT100 test screen, or front panel BERT push button is also possible.

  • Page 43: Bad Splice Detection (Tscan)

    Troubleshooting Bad Splice Detection (TScan) The SHDSL 2-Wire/4-Wire NTUs provide bad splice protection using the ADTRAN propri-  etary Runtime TScan 2.0 splice protection feature. TScan splice detection is a non-intrusive algorithm that enables SHDSL 2-Wire/4-Wire NTUs to detect anomalies (bad splices) in the copper pair.

  • Page 44: Restart Bad Splice Detector Screen

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide • If two or more count register exceed the threshold and are of equal count, then the distance count closest to the unit displays as a bad splice because the detector is more accurate the closer the anomaly is to the unit.

  • Page 45: Figure 18. Restart Bad Splice Detector Screen

    Troubleshooting Unit Mode: 21-Nov-06 11:01:32 Circuit ID: Terminal Mode: Local Restart Bad Splice Detector Are you sure you want to restart the bad splice detector and lose all 24 hour count history (Y/N)? Selection: System Help Figure 18. Restart Bad Splice Detector Screen The Restart Bad Splice Detector screen options are shown in Table Table 18.

  • Page 46: Bad Splice Detection (Tscan) 24 Hour Counts Screen

    SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide Bad Splice Detection (TSCAN) 24 Hour Counts Screen Provisioning The Bad Splice (TSCAN) 24 Hour Counts screen displays the history register. If the unit is handshaking or training, the splice loop rates and count registers do not update. If the unit is trained, it updates the splice current day data registers.

  • Page 47: Specifications

    Height: 2.215 inches (5.63 cm) Width: 9.25 inches (23.5 cm) Depth: 6.625 inches (16.8 cm) Weight: Less than 1 pound (0.45 kg) Part Numbers 6540 SHDSL 2-Wire/4-Wire NTU, AC: 1230001E1 6540 SHDSL 2-Wire/4-Wire NTU, DC: 1230002E1 6541 SHDSL 2-Wire/4-Wire NTU, AC: 1230007E1...
  • Page 48 SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide 61230001E1-5E...

  • Page 49: Warranty And Customer Service

    Appendix A Warranty and Customer Service Warranty ADTRAN will replace or repair this product within the warranty period if it does not meet its published specifications or fails while in service. Warranty information can be found at www.adtran.com/warranty. Refer to the following subsections for sales, support, Customer and Product Service (CAPS) requests, or further information.
  • Page 50 Carrier Networks Division 901 Explorer Blvd. Huntsville, AL 35806 U.S.A. http://www.adtran.com ADTRAN CUSTOMER CARE From within the U.S. 1.800.726.8663 From outside the U.S. +1 256.963.8716 PRICING AND AVAILABILITY 1.800.827.0807...
