ETC Installation Guide
ArcSystem Pro Multi-Cell
Installing 100–277 V Multi-Cell Fixtures
This section provides the information needed to install 100-277 V Multi-Cell fixtures.
Supplies
The following supplies are required for installation, but not provided:
½ in flex conduit and conduit fittings
•
Appropriate strain relief connectors for the installation type, as needed
•
Phillips head screw driver
•
120Ω RJ45 terminator for DMX termination. See
•
Note:
conduit hardware, and all cable required for installation.
Electrical and Wiring Specification
Install ArcSystem 100–277 V fixture on a power distribution system with reliably identified earthed
neutral and install a maximum 20 A circuit breaker on the line conductor.
ArcSystem 100–277 V fixtures and drivers accept 100–277 VAC, 50/60 Hz. ETC recommends
installing all wiring in grounded metal conduit.
Wire and Terminal Specifications
Fixture Type
Pro Two-Cell,
Pro Four-Cell Square,
Pro Four-Cell Linear,
Pro Eight-Cell
Note:
line with a 120 Ω resistor. To purchase an RJ45 terminator, please contact your ETC
customer service representative and request part number N4086.
ArcSystem Pro Multi-Cell
Mounting hardware and installation location must support the weight of the fixture,
Terminal / Conduit
Connector Entry
Power Input -
½ in conduit
line/neutral/ground
DMX In/Thru
N/A
RJ45 Connectors
ArcSystem fixtures are not self-terminating. You must terminate the last fixture in
Terminate DMX on page 13
Wire Range / Specification
0.2–4 mm
(24–12 AWG)
Cat5e (or better) minimum 24
AWG conductors terminated
to T568B standard
Page 10 of 24
.
Strip Length
11 mm (0.43 in)
N/A
