ETC Installation Guide
ArcSystem Pro Multi-Cell
DMX System Control
ArcSystem RDM Systems can be controlled over wired DMX from a lighting console or ETC Net3
Concert software. Concert is available for free download at
etcconnect.com/Products/Networking/Software/Net3-Concert.aspx.
ArcSystem is compliant with DMX 512-A (ANSI E1.11-2008 (R2013)).
•
DMX loss behavior is hold last look.
•
Each fixture can be addressed to any one of the 512 DMX addresses up to the maximum device limit
of 32 devices on each DMX line. Wireless DMX control requires a TX1 Transmitter and fixtures with
the wireless ArcMesh transceiver. For wireless DMX installation,see the ArcSystem Installation
Manual , available from etcconnect.com.
RDM Values
Manufacturer ID: 0x6574 (Electronic Theatre Controls)
Model IDs
Product Type
ArcSystem Pro Multi-Cell
ArcSystem Pro Multi-Cell
Description
D4 Constant Current Emergency Driver
D4 Constant Voltage Emergency Driver
Pro Two-Cell
Pro Two-Cell Emergency
Pro Four-Cell Square
Pro Four-Cell Square Emergency
Pro Four-Cell Linear
Pro Four-Cell Linear Emergency
Pro Eight-Cell
Pro Eight-Cell Emergency
Pro Four-Cell Round
Pro Four-Cell Round Emergency
Page 19 of 24
Model ID
0x1304
0x1305
0x1207
0x1307
0x1208
0x1308
0x1209
0x1309
0x120C
0x130C
0x120A
0x130A
