ETC Installation Guide
ArcSystem Pro Multi-Cell
Installing 100–277 V Emergency Multi-Cell Fixtures
Instructions for installing 100–277 V emergency fixtures are below. See
Multi-Cell Fixtures on page 10
Two-cell
fixture
B
C
Four-cell
square fixture
B
C
With the exception of power input terminations, ArcSystem 100–277 V emergency system
installation requirements are the same as those of ArcSystem 100–277 V non-emergency systems.
Complete the installation as follows, referencing these sections for installation details:
1. Complete the steps of
2. Install conduit hardware at the knockout or second hole in the side of the wiring
compartment.
Note:
Cell fixtures.
ArcSystem Pro Multi-Cell
for instructions on installing 100–277 V standard fixtures.
A
A
A wiring compartment
B conduit entry for 1/2 in conduit
C DMX in and thru
D knockout for 1/2 in conduit
Installing 100–277 V Multi-Cell Fixtures on page 10
Use flexible metal conduit when installing and focusing 277 V Emergency Pro Multi-
Four-cell
linear fixture
C
D
B
Eight-cell
fixture
C
D
B
Page 15 of 24
Installing 100–277 V
A
A
.
