ETC Installation Guide
ArcSystem Pro Multi-Cell
Parameter
DMX Start Address
DMX Personality
Identify Device
Minimum Level
Maximum Level
Curve
Curve Description
Output Response Time
Output Response Time
Down
Output Response Time
Description
Modulation Frequency
Modulation Frequency
Description
Restore Factory Defaults
Software Version Label
Bootloader Version Label
ArcSystem Pro Multi-Cell
RDM PID Value
0x00F0 Range = 001 to 512
0x00E0 1 or 2
0 for stop identify, 1 for start
0x1000
identify
0x0341 0 to 255
0x0342 0 to 255
0x0343 1, 2, or 3
0x0344
0x01 1000 ms/100 steps
0x0345
•
0x02 900 ms/90 steps
•
0x03 800 ms/80 steps
•
0x04 700 ms/70 steps
•
0x05 600 ms/60 steps
•
0x06 500 ms/50 steps
•
0x8030
0x07 400 ms/40 steps
•
0x08 300 ms/30 steps
•
0x09 250 ms/25 steps
•
0x0A 200 ms/20 steps
•
0x0B 100 ms/10 steps
•
0x0C 50 ms/5 steps
•
0x0D 0 ms/0 steps
•
0x0346
32-bit unsigned integer
0x0347
representation of the frequency
in Hz
300 for 300 Hz
•
600 for 600 Hz
•
1200 for 1.2 kHz
•
19200 for 19.2 kHz
•
0x0348
0x0090
0x00C0
0x00C2
Page 21 of 24
Notes
Default is 001. The upper limit for multi-cell fix-
tures is 512-N, where N is the number of channels
DMX Personality
in the fixture profile. See
the supported multiple-channel configuration for
each multi-cell fixture type.
Default is 2. This parameter does not affect the
operation of single-cell fixtures. See
DMX Personality for the supported multiple-
channel configuration for each multi-cell fixture
type.
Set to 1 sets DMX personality to multi-channel.
•
Set to 2 sets DMX personality to single-channel.
•
Set to 1 causes output(s) and LEDs of the unit to
blink in a one second on, one second off pattern.
Default is 99%. The fixture will not accept a Min-
imum Level that is higher than the Maximum
Level.
Default is 100%. The fixture will not accept a Max-
imum Level that is lower than the Minimum Level.
Set to 1 is the Default Tungsten Curve (aka
•
D04A)
Set to 2 is Linear
•
Set to 3 is Square Law
•
Get returns an ASCII text string.
Default is 500ms/50 steps. This parameter con-
trols dimming up in level.
Default is 500 ms/50 steps. This parameter con-
trols dimming down in level. Set 0x00 to set the
Output Response Time Down to the same setting
as Output Response Time.
Get returns an ASCII text string.
Default is 300 Hz.
Get returns an ASCII text string.
Set resets the fixture configuration to default set-
tings.
Get returns the current software version as an
ASCII text string.
Get returns the current bootloader version as an
ASCII text string.
