Connect the Maintained Input
1.
See Wire and Terminal Specifications on page 10
length. Prepare wires accordingly.
2. Remove the screws securing the wiring compartment cover to the fixture. The cover is
grounded to the enclosure by a tether. Set the screws aside.
3. Terminate ground.
a. Locate the WAGO connector on the ground wire (green) connected to the bottom of the
wiring compartment (
b. Run a ground wire (typically green/yellow) through conduit to a free position on the
WAGO connector.
c. Lift up the orange clip, insert the ground wire, and press the clip down onto the wire.
d. Tug gently to make sure the wire is secure.
4. Terminate neutral to the Maintained input.
a. Locate the WAGO connector on the neutral wire (white) from the input labeled
Maintained.
b. Run a neutral wire (typically white or grey) through conduit to a free position on the
WAGO connector.
c. Lift up the orange clip, insert the neutral wire, and press the clip down onto the wire.
d. Tug gently to make sure the wire is secure.
5. Terminate line (hot) to the Maintained input.
a. Locate the WAGO connector on the line (hot) wire (black) from the input labeled
Maintained.
b. Run a line (hot) wire through conduit to a free position on the WAGO connector.
Note:
brown, orange, or yellow.
c.
d.
Connect the Sense Input
1. Make sure power is off at the main circuit breaker.
2.
See Wire and Terminal Specifications on page 10
length. Prepare wires accordingly.
3. Terminate ground.
a. Locate the WAGO connector on the ground wire (green) connected to the bottom of the
wiring compartment.
a. Run a ground wire (typically green/yellow) through other conduit to a free position on the
WAGO connector.
b. Lift up the orange clip, insert the ground wire, and press the clip down onto the wire.
c. Tug gently to make sure the wire is secure.
4. Terminate neutral to the Sense input.
a. Locate the WAGO connector on the neutral wire (white) from the input labeled Sense.
b. Run a neutral wire (typically white or grey) through conduit to a free position on the
WAGO connector.
c. Lift up the orange clip, insert the neutral wire, and press the clip down onto the wire.
d. Tug gently to make sure the wire is secure.
ArcSystem Pro Multi-Cell
Line (hot) wire color varies based on voltage and region but is typically black,
Lift up the orange clip, insert the line wire, and press the clip down onto the wire.
Tug gently to make sure the wire is secure.
).
