ETC Installation Guide
ArcSystem Pro Multi-Cell
Fuses
Some ArcSystem fixtures have a user-serviceable fuse located in the power switch. Consult the table
below for your fixture type. All emergency fixtures, 100–277 V fixtures, and fixture types that are not
listed do not have user-serviceable fuses.
Voltage
100–240 V
Emergency Operation and Test
It is important to test ArcSystem emergency systems regularly because they are life safety devices.
NOT SELF-TESTING PER ANSI/NFPA 101 - This equipment is not self-testing in conformance with
the Life Safety Code, ANSI/NFPA 101. ANSI/NFPA 101 Life Safety Code requires testing of life
safety devices every 30 days.
To test the emergency functionality of this device, disconnect the sense circuit.
WARNING:
system before installation, maintenance, cleaning, or any other system modification could
result in serious injury or death.
AVERTISSEMENT :
débrancher toutes les sources d'alimentation du système avant l'installation, l'entretien, le
nettoyage ou toute autre modification du système peut causer des blessures graves ou la
mort.
De-energize main feed to ArcSystem and follow appropriate Lockout/Tagout procedures as
mandated by NFPA 70E. It is important to note that electrical equipment such as breaker
panels can present an arc flash hazard if improperly serviced. This is due to the high
amounts of short-circuit current available on the electrical supply to this equipment. Any
work must comply with OSHA Safe Working Practices.
CAUTION:
risk of electric shock, disconnect both normal and emergency sources within this unit before
servicing any equipment connected to this unit.
ATTENTION :
les risques de décharge électrique, débrancher les sources d'alimentation normale et de
secours dans l'unité avant de faire l'entretien d'un équipement branché à cette unité.
Test the ArcSystem emergency system as described:
1. Turn off power at the normal circuit breaker.
2. Test the system per ANSI/NFPA 101 Life Safety Code.
ArcSystem Pro Multi-Cell
Fixture Fuse Quantity
Pro Two-Cell
Pro Four-Cell Square
Pro Four-Cell Linear
Pro Four-Cell Round
Pro Eight-Cell
RISK OF DEATH BY ELECTRIC SHOCK! Failure to disconnect all power to the
RISQUE DE MORT PAR DÉCHARGE ÉLECTRIQUE! Négliger de
This equipment is provided with more than one supply source. To reduce the
Cet équipement possède plus d'une source d'alimentation. Pour réduire
1 3.150 A, 250 V, class T 5x20 mm
Page 23 of 24
Fuse
