Bill Of Material For Fiscal Memory Module Pcb; Tab. 6.8: Bill Of Material For The Com5 Module Pcb - ELCOM EURO-2500 Service Manual

Service manual
Amount Signature
2 R8, R9
4 R1, R6, R7, R10
1 R5
2 R2, R4
1 R3
2 D1, D2
4 DT1, DT2, DT3, DT4
1 C10
5 C1, C2, C3, C31, C32
1 BD1
1 U2
1 U1
1 U3A
2 U31, U32
1 RS422CON
1 USB/UARTCON
1
Tab. 6.8: Bill of material for the COM5 module PCB. Notes: * - inset in the variant with two DS75176 converters; ** - inset in the
variant with DS8921 converter.
6.9 Bill of material for fiscal memory module PCB 6.9 Bill of material for fiscal memory module PCB
4 D B
1 D B
92
Description
47k
10k
1k
22k
120R
LL4148
BZW06-5V8
100u/10V
100n
EBM3216
74HC00
TL16C452
DS8921
DS75176
AVA 5400-4P-S
Connector pins
DPS 5thCom2500TXv1_2
D4
C13
U1
6 U
9 C 0 1 R
2 D B
4 1 C
1 C
Fig. 6.9: Fiscal memory PCB top and bottom overlay
