Printed testing output:
TEST 966.1

5.10.6.2 Test of data writing into FM

5.10.6.2 Test of data writing into FM
This test diagnoses the possibility of writing into the FM.
During the test, bytes '55' and 'AA' are written into the FM test
area. First writing of the '55' byte is at the address 1FF00 and
first writing of the 'AA' byte at the address 1FF40. Next test
shifts these values by one. There are maximum 64 tests pos-
sible.
Procedure:
Look up "Write Test" in the FM test submenu using arrows or
enter code 2 and press OK E
966.FM Tests
2.Write Test
Testing procedure:
1. FM memory is read for checking data and verifies them.
2. From the address 1FF00 (7FF00 for 512 kB version) the first
free byte is located and the value '55' is written there.
3. From the address 1FF40 (7FF40 for 512 kB version) the first
free byte is located and the value 'AA' is written there.
4. The test summary is both printed and displayed.
Printed testing output:
TEST 966.2
Note: If the FM testing area is full the ECR displays this fact
on the display.

5.10.6.3 Test of data reading from FM

5.10.6.3 Test of data reading from FM
The FM data reading tests allow the checking the data writ-
ten in the FM. Reading from the whole FM is possible or it is
also possible to read small blocks of memory (8 kB for 128 kB
version or 32 kB for 512 kB version).
Procedure for reading the whole FM:
Look up "Read Test" in the FM test submenu using arrows or
enter code 3 and press OK E
specify the read range. For the whole FM, enter 0.
Euro 2500
TX
OK
(N E ).
NTER UM NTER
|
OK
(N E ). The ECR asks to
NTER UM NTER
Area Address space
1 00000–01FFF
2 02000–03FFF
3 04000–05FFF
4 06000–07FFF
5 08000–09FFF
6 0A000–0BFFF
7 0C000–0DFFF
8 0E000–0FFFF

Tab. 5.25: Area codes and ranges for 128kB FM modules.

Area Address space
1 00000–07FFF
2 08000–0FFFF
3 10000–17FFF
4 18000–1FFFF
5 20000–27FFF
6 28000–2FFFF
7 30000–37FFF
8 38000–3FFFF

Tab. 5.26: Area codes and ranges for 512kB FM modules.

966.FM Tests
3.Read Test
Select area
Testing procedure:
1. Entire FM is read for data
2. All read data is printed on the ECR printer.
Procedure for reading the FM segments:
Look up "Read test" in the FM test submenu using arrows or
enter code 3 and press OK E
to specify the read range. Enter the number of the segment
within 1–16.
966.FM Tests
3.Read Test
Select area
Testing procedure:
1. FM is read for data from the specified 8 kB/32 kB seg-
ment.
2. All read data is printed on the ECR printer.
Service manual
Area Address space
9 10000–11FFF
10 12000–13FFF
11 14000–15FFF
12 16000–17FFF
13 18000–19FFF
14 1A000–1BFFF
15 1C000–1DFFF
16 1E000–1FFFF
Area Address space
9 40000–47FFF
10 48000–4FFFF
11 50000–57FFF
12 58000–5FFFF
13 60000–67FFF
14 68000–6FFFF
15 70000–77FFF
16 78000–7FFFF
<
0
E
(N ). The ECR asks
NTER UM NTER
<
