Figure 7.1
Location of the
Jumper and Return
Switch in the
Flex Max901e Trunk
and Bridger
Amplifiers
Figure 7.2
Return Switches
Installed in the
Flex Max901e Trunk
and Bridger (shown)
Amplifier
1502154 Rev D
Jumper W18 for Return Switch RS2
Return Switch RS2
Trunk Amplifier: Install RS1, RS2, and RS3
Bridger Amplifier: Install RS2 and RS3
Jumper W17 for Return Switch RS1
Jumper W19 for Return Switch RS3
Return Switch RS1 (not installed)
Return Switch RS3
Maintenance
7
7-5
