Tools and Materials

The following tools and materials may be used to complete the procedures in this chapter.
7
7-2 Flex Max901e 1GHz Trunk and Bridger Amplifiers
Tools/Equipment
Tools
Signal level meter (SLM)
Signal generator
Multimeter
Flat blade screwdrivers
Needlenose pliers
Wire cutters
Nutdriver or wrench
1
Phillips screwdriver
Phillips screwdriver 2
Torque wrench/driver
2
Torx ® or Torx PLUS ® driver
Drill and drill bits
Tuning wand
Fuse puller
Materials
Heat gun or approved torch
and heatshrink tubing, or
weathersealing tape or
compound
1/4-20 UNC bolts and shims
Dust caps
Anti-seize compound
1. An 11mm tool can normally be used for a 7/16-inch bolt unless the tool is manufactured to minimum, and the
bolt head to maximum, "across the flat" dimensions.
2. Small, hold-down screws may be Phillips head screws or Torx PLUS
3. C-COR recommends torquing all bolts and screws to the specified values.
Table 7.1 Tools and Materials
Required Specifications
5MHz to 1002MHz, –35 to
60dBmV (25 to 120dBµV)
5 to 100MHz, 10 to 60dBmV (70 to
120dBµV)
True RMS, AC-coupled;
ranges: 0 to 200V , 0 to 200V
DC
and 0 to 200mV
AC
1/4 inch, 5/16 inch
—
—
7/16 inch (11mm)
#1
#2
Up to 66 in-lbs (7.5N·m), with
interchangeable 7/16 inch or 11mm
hex socket, Phillips, flat blade, and
Torx ® or Torx PLUS ® bits
T15 (Torx ® ) or 15 I.P. (Torx PLUS
9/32 inch (7mm)
Non-conductive
Non-conductive
(C-COR P/N FP-1)
—
—
C-COR P/N MX0008
—
Uses
Input and output signal testing during
forward and return balancing
Signal input during return balancing
Power supply testing
,
AC
May be required for small fasteners
Jumper removal
Trim coaxial cable center conductor;
jumper cutting
Housing opening and closing
Attaching grounding bracket to
transponder
Centerseizure and module faceplate
screws; power supply screws, and
transponder grounding screw
Strand mounting, housing closing,
tightening various fasteners
® ) May be required for small fasteners
Wall or pedestal mounting
Adjust ALC sensitivity/modulation depth
Fuse removal and installation
Weatherproofing RF cable connectors
Wall mounting
Cover unused ports
RF cable attachment
head screws. Use the appropriate driver.
®
3
