C-COR Flex Max901e Equipment Manual page 24

2
2-4 Flex Max901e 1GHz Trunk and Bridger Amplifiers
Table 2.1 Testpoints, Plug-in Locations, Controls, and Connections (cont'd)
Item Label
24 BRIDGER EQ/PAD
(Trunk and bridger
amplifiers)
25 P5/P6 FWD PAD
26 POWER PLUG
27 TRANSPONDER
28 PORT 2/3 REV I/P TP
29 PORT 2/3 FWD O/P TP
30 PORT 3
31 PORT 3
32 DISTRIBUTION
33 STATION REV PAD
34 PORT 2
35 STATION REV EQ
36 Power Plug
37 Power Supply
Management Strap
Power Supply Mounting
38
Screws
1. Refer to functional block diagrams (Appendix C) and reference tables (Appendix D) for more information.
2. Refer to Factory-Shipped Configurations for Flex Max901e Trunk and Bridger Amplifiers on page 5-9 for more
information.
Function
Location on trunk amplifiers for installing:
a GEQL-1GHz-090 equalizer to optimize standard 1GHz
operation with different tilts on the trunk and bridger ports
(T:10dB, B:18dB).
Location on bridger amplifiers for installing:
an NPB-000 PAD to optimize 1GHz operation,
or
an NPB-020 PAD to optimize 750/870MHz operation.
Location for installing an NPB series PAD
Provides AC power to the HEPS and returns DC power to the RF
module.
Location to install transponder.
Directional testpoint for measuring inbound return RF signals.
Directional testpoint for measuring outbound forward RF signals.
Provides access to the Port 3 centerseizure screw (90° rotation).
Provides access to the Port 3 centerseizure screw.
Location for installing a distribution plug-in accessory for Port 2/3
Location for installing an NPB series PAD
Provides access to the Port 2 centerseizure screw.
Location for installing an equalizer footprint plug-in accessory
Provides AC power to the HEPS and returns DC power to the RF
module.
Required for securing the power plug cord in a non-rotated
configuration.
8-32x5/16 pan head screws (4) for mounting a power supply.
1
.
1
.
1
.
1
.
1502154 Rev D
