The following tools and materials may be used to complete the procedures in this chapter.
5
5-2 Flex Max901e 1GHz Trunk and Bridger Amplifiers
Tools/Equipment Required Specifications
Signal level meter (SLM) 5MHz to 1002MHz, –35 to +60dBmV
(25 to 120dBµV)
Signal generator 5 to 100MHz, 10 to 60dBmV (70 to
120dBµV)
Multimeter True RMS, AC-coupled; ranges: 0 to
200V
200mV
Flat blade screwdrivers 1/4 inch, 5/16 inch
Wire cutters
Nutdriver or wrench 7/16 inch (11mm)
1
2
Phillips screwdriver #2
Torque wrench/driver Up to 66 in-lbs (7.5N·m), with
interchangeable 7/16 inch or 11mm hex
socket, Phillips, flat blade, and Torx
Torx PLUS
Torx ® or Torx PLUS ® T15 (Torx
2
driver
Tuning wand Non-conductive
Fuse puller Non-conductive
(C-COR P/N FP-1)
1. An 11mm tool can normally be used for a 7/16-inch bolt unless the tool is manufactured to minimum, and the
bolt head to maximum, "across the flat" dimensions.
2. Small, hold-down screws may be Phillips head screws or Torx PLUS
3. C-COR recommends torquing all bolts and screws to the specified values.
Table 5.1 Tools and Materials
, 0 to 200V , and 0 to
DC AC
AC
—
®
® bits
® ) or 15 I.P. (Torx PLUS ® )
Uses
Input and output signal testing during
forward and return balancing
Signal input during return balancing
Power supply testing
May be required for small fasteners
Jumper cutting
Housing opening and closing
Centerseizure screws; power supply
and transponder hold-down screws
Strand mounting, housing closing,
tightening various fasteners
or
May be required for small fasteners
Adjust ALC sensitivity and modulation
depth
Fuse removal and installation
head screws. Use the appropriate driver.
®
1502154 Rev D
