Bridger - C-COR Flex Max901e Equipment Manual

B
B-8 Flex Max901e 1GHz Trunk and Bridger Amplifiers
Table B.3 Flex Max901e Bridger Amplifier, 1002MHz, 42/54 Split
General
Passband, MHz
Housing, MHz
AC Current Passing, A
Ports 1, 3, 4, 6
Ports 2, 5 ("H" and "P" options)
Typical Operating Conditions
1, 2
Operational Gain, dB
3
Channels, Number of NTSC
Operating Levels (recommended)
Frequency, MHz
4
Input, dBmV, min.
5, 6
Output, dBmV
Performance Specifications @ Recommended Levels
(Temperature Range: –40 to 60°C)
Carrier-to-Interference Ratio, dB
Composite Triple Beat
Second Order Beat (F1 ± F2)
Cross Modulation (per NCTA std.)
Third Order Beat (F1 ± F2 ± F3)
Composite 2IM
Composite Intermodulation Noise CIN
Composite Intermodulation Noise CIN
2
Noise, 4MHz, 75Ohms
11
Noise Figure, dB (without EQ)
Full Gain, dB
(without EQ and ALC)
Factory Alignment (with ALC Reserve, without EQ)
Cable Loss, dB @ 1002MHz
Flat Loss, dB
Gain Slope, dB
12 13
Flatness (@ Gain Slope), ±dB
Return Loss, dB min.,
All Entry Ports
14
Testpoint
–20 or –25dB Forward Input TP, dB
–20 or –25dB Forward Output TP, dB
–20 or –25dB Return In and Out TP, dB
Powering Requirements, Max. /Typ.
AC Voltage, 60Hz
AC Power, Watts
AC Current, mA
DC Current, mA @ 24V ± 0.5V
FORWARD
2O/P Bridger
1002/870/750/550/54
9/8.1/7.8/7.4/10.1
52/49.5/47.5/44/35
7
8
9
10
59/58.1/57.8/58.4/59.1
8/8/8/7/9
–1.0 to 1.0
±0.5(54 to 550), ±1.0(551 to 1002)
15
54–1002
1002
15
13
43
79
75
—
67
—
73
73
79
48
23
21
±1.0
16
±1.0
—
With Active Return
@ 90V
45.5/41
670/630
1650/1475
RETURN
2O/P Bridger
5–42
—
15
13
18
6
42/5
17/17
35/35
80
—
74
—
82
—
—
64
12
19
—
19
—
0.5
16
—
—
±0.5
@ 60V
45/40
820/740
1650/1475
1502154 Rev D
