C-COR Flex Max901e Equipment Manual page 121

Table B.4 Flex Max901e Trunk Amplifier, 1002MHz, 55/70 Split, 33dB Spaced, Different Tilt on Trunk
General
Passband, MHz
Housing, MHz
AC Current Passing, A
Ports 1, 3, 4, 6
Ports 2, 5 ("H" and "P" options)
Typical Operating Conditions
Operational Gain, dB
Channels, Number of NTSC
Operating Levels (recommended)
Frequency, MHz
Input, dBmV, min.
Output, dBmV
Performance Specifications @ Recommended Levels
(Temperature Range: –40 to 60°C)
Carrier-to-Interference Ratio, dB
Composite Triple Beat
Second Order Beat (F1 ± F2)
Cross Modulation
(per NCTA std.)
Third Order Beat (F1 ± F2 ± F3)
Composite 2IM
Composite Intermodulation Noise CIN
Composite Intermodulation Noise CIN
Noise, 4MHz, 75Ohms
Noise Figure, dB (without EQ)
Full Gain, dB (without EQ and ALC)
Factory Alignment (with ALC Reserve, without EQ)
Cable Loss, dB @ 1002MHz
Linear Equalization
Flat Loss, dB
Gain Slope, dB
Flatness (@ Gain Slope), ±dB
Return Loss, dB min., All Entry Ports
Testpoint Accuracy
–20 or –25dB Forward Input TP, dB
–20 or –25dB Forward Output TP, dB
–20 or –25dB Return In and Out TP, dB
1502154 Rev D
1, 2
3
4
5, 6
7
8
9
10
2
11
12
13
14, 15
16
and Bridger
FORWARD
Trunk 2 O/P Bridger
70–1002
1002
15
13
33 43
76 76
1002/870/750/550/70
9/8.4/8.4/7.6/9
42/41/39.5/37.5/33 52/49.5/47.5/44/35.5
84 75
— —
76 67
— —
79 73
80 66
86 72
59/59.4/59.4/57.6/57
8/7/7/8/10
38 48
13 13
— 7.1
21 31
–0.5 to 1.0 –1.0 to 1.0
0.75 1.0
16 16
±1.0
±0.5(70 to 550), ±1.0(551 to 1002)
—
RETURN
Trunk & 2 O/P Bridger
5–55
—
15
13
18
6
55/5
17/17
35/35
80
—
74
—
82
—
—
62
14
19
—
—
19
—
0.5
16
—
—
±0.5
Specifications B-11
B
