C-COR Flex Max901e Equipment Manual page 125

Table B.5 Flex Max901e Trunk Amplifier, 1002MHz, 55/70 Split, 32dB Spaced, Same Tilt on Trunk
Level Control
Range, dB @ 1002MHz
Accuracy (–40 to 60°C)
Output Level Range
Pilot Frequency Band
Gain Control
Plug-in PAD
Equalization to Compensate for Cable Loss
Plug-in Equalizers for Additional Equalization
Chrominance/Luminance Delay, Max.
Channel 5, ns/3.58MHz
Channel 6, ns/3.58MHz
Return Group Delay, Max.
5.5–7MHz, ns
10–11.5MHz, ns
52–53.5MHz, ns
53.5–55MHz, ns
70–71.5MHz, ns
71.5–73MHz, ns
Hum Modulation (Time Domain @ 15A)
5–10MHz, –dBc
11–750MHZ, –dBc
751–1002MHz, –dBc
1. Spacing at highest frequency with Forward EQ installed. Return spacing includes losses due to housing, diplex
filters, and MEQ–55–X.
2. The specifications are based on the amplifier configured (with two SPB–0) as a 2–output bridger with distribution
outputs on Ports 3 and 6. When using distribution plug-ins SS–1000–2, SDC–1000–8 or SDC–1000–12, levels
should be derated accordingly based on the accessory specifications.
3. NTSC video channels occupying the appropriate frequency spectrum per specified number of channels.
4. Recommended minimum forward input levels at 870MHz including loss due to equalizer.
5. Recommended maximum return output level at 55MHz including loss due to equalizer.
6. Bridger output: At specified operational tilt, the maximum output level for 870MHz loading is 56.5dBmV @ HF.
7. Forward trunk output levels achieved by installing an NPB-010 in the interstage PAD location and a
GEQC-1GHz-090 in the O/P EQ location. Forward bridger output levels are achieved by installing an NPB-000 in
the Bridger EQ/PAD location.
8. Distortion performance is derated accordingly to take into account the influence of the digitally compressed
channels operating at levels 6dB below equivalent video channels.
9. Cross modulation specification number indicates typical cascade performance.
10. Systems operating with digitally compressed channels or equivalent broadband noise from 550 to 1002MHz at
levels 6dB below equivalent video channels will experience a composite distortion (CIN) appearing in the 70 to
550 frequency spectrum.
1502154 Rev D
and Bridger (cont'd)
18
(from nominal)
19
(recommended)
FORWARD
Trunk 2 O/P Bridger
+4/–5dB
±0.5dB
+5/–3dB
499.25MHz (Single Channel)
NPB–XXX
SEQ-750-XX
SEQ–870–XX
SEQ-1G-XX
14
9
—
—
—
—
21
15
—
60
55
Specification Document Number 1502465 Rev B
RETURN
Trunk & 2 O/P Bridger
—
—
—
—
NPB–XXX
MEQ–55–XX
—
—
52
7
21
36
—
—
55
60
—
Specifications B-15
B
