Line-Out 3.5 mm Stereo Jack
4 RCA Jacks for Audio Input
8 RCA Jacks for Audio Output
• Analog Devices AD1852 192 kHz Auxiliary DAC
• Crystal Semiconductor CS8414 96 kHz SPDIF Receiver
Optical and Coaxial Connectors for SPDIF Input
• Flash Memory
512K x 8-bits
• Interface Connectors
14-Pin Emulator Connector for JTAG Interface
SPORT Connectors
Link Port 0 and Link Port 1
External Port Connectors (not populated)
• General-Purpose IO
4 Push Button Flags
3 Push Button Interrupts
6 LED Outputs
• Analog Devices ADP3338 and ADP3339 Voltage Regulators
• Breadboard area with typical SMT footprints
The EZ-KIT Lite board has a flash memory device that can be used to
store user-specific boot code. By configuring the jumpers for EPROM
boot, the board can run as a stand-alone unit. The ADSP-21161N
EZ-KIT Lite package contains a flash programmer utility, which allows
you to program the flash memory. The
described on page
ADSP-21161N EZ-KIT Lite Evaluation System Manual
1-12.
"Flash Programmer Utility"
