CHANGING A BULB

WARNINGS
Switch the lights and the ignition
off.
Let the bulb cool down before
CAUTIONS
Do not touch the glass of the bulb.
Only fit bulbs of the correct
specification. Refer to the Bulb
Specification Chart later in this section.
Note: The following instructions
describe how to remove the bulbs.
Fit replacements in the reverse order
unless otherwise stated.
You may notice fogging or small water
droplets in the lamp units from time to
time. This does not affect the function of
the lamp, and will clear when the lamps
are turned on and the vehicle is driven.
Note: If in any doubt about any of the
following bulb replacement procedures,
please have the bulb replaced by your
authorised Ford dealer.
Headlamps
WARNING
Headlamp lenses become hot
during and for a short time after
headlamp operation. To avoid personal
injury, allow the headlamp lens time to
cool before touching.
CAUTION
Handle a halogen headlamp bulb
carefully. Do not touch the glass. The
Lighting
oil from your hand may cause the bulb
to break the next time the headlamps
are operated. If the bulb is accidentally
touched, it should be cleaned with
alcohol before being used.
C
A Headlamp high beam bulb -
HB3/60W.
B Headlamp low beam bulb -
HIR2LL/55W.
C Front indicator bulb -
WY21W/21W.
Low or High Beam
Note: Ensure when replacing bulbs,
that the correct bulb is assigned to
the correct socket. The low and high
beam bulbs are different in size and
specification. Consult the bulb usage
table at the end of this section for correct
bulb types.
7. Switch off the lights and allow to
cool.
8. Open the bonnet.
9. Remove the low-beam bulb, rotate
the bulb with the connector quarter
turn anti-clockwise when looking
from back of the lamp.
10. Pull out bulb from the lamp.
Disconnect connector from the
bulb and insert replacement bulb in
connector.
11. Insert bulb with the connector in the
lamp and turn clockwise to lock.
-54-
A
B
