- Page 1 2016 FOCUS ST owner.ford.com ford.ca August 2015 First Printing Supplement Focus ST Litho in U.S.A. preproduction model shown GM5J 19A285 AA...
- Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2015 All rights reserved. Part Number: 20150710054236...
-
Page 4: Table Of Contents
Table of Contents Introduction Warranty Terms and Conditions About This Supplement.........3 Base Warranty..........30 Product History..........4 At a Glance At a Glance............5 Instrument Cluster Gauges..............9 Transmission Manual Transmission........11 Stability Control Using Stability Control........13 Driving Hints Engine Overspeed...........15 Engine Overboost...........15 Roadside Emergencies Roadside Assistance........16 Maintenance Under Hood Overview - 2.0L... - Page 5 Focus (CDH) ST, Canada/Mexico/United States of America, enUSA, First Printing...
-
Page 6: About This Supplement
Although performance significant interior and exterior is at the heart of every Ford Performance enhancements. developed vehicle, we go much further. Our goal is to deliver a comprehensive,... -
Page 7: Product History
Owner’s Manual and provides information Team RS traces its roots back nearly 60 specific to the Focus ST. By referring to the years from the Lotus Ford Cortina and Twin pages listed in this supplement, you can Cam Escorts of the mid 1960’s, through identify those features, recommendations the first RS branded Escorts of the 1970’s... -
Page 8: At A Glance
• ST-tuned 2.5 in (63.5 mm) center exit • ST-tuned electric power assisted exhaust system. steering. • Getrag-Ford MMT6 6-speed manual • AdvanceTrac® stability enhancement transaxle. system with three modes: Normal, • Active sound symposer. Sport and Disabled. - Page 9 At a Glance • P235/40-18 Pirelli P-Zero Nero • Leather wrapped ST sport steering performance all-season tires wheel with improved grip contour. (optional). • ST-unique instrument panel appliques, • ST-engineered front and rear fascias shift knob, shift boot and pedal pads. and rear wing.
- Page 10 At a Glance Item Description 1.952 4.063 1.321 4.063 1.321 4.063 1.129 2.955 0.943 2.955 Reverse 4.600 2.955 Engine Specifications Item Description Configuration Transversely mounted I4, cast aluminum cylinder block and cylinder heads Bore x stroke 3.4 in (87.5 mm) bore x 3.2717 in (83.1 mm) stroke Displacement 122 in³...
- Page 11 At a Glance Item Description Turbo Single scroll / 21 psi max boost* Exhaust system 2.5 in (63.5 mm) diameter * SAE Certified Performance ratings are achieved with 19.5 psi, but up to 21 psi can be delivered to maximize power depending on fuel quality and atmospheric conditions. Suspension Specifications Item Description...
-
Page 12: Instrument Cluster
Instrument Cluster GAUGES E194323 Tachometer. Fuel gauge. Coolant temperature gauge. Speedometer. Focus (CDH) ST, Canada/Mexico/United States of America, enUSA, First Printing... - Page 13 Instrument Cluster If the engine oil pressure drops below the normal range, the oil pressure gauge pointer drops into the red section of the gauge scale and the engine oil pressure warning lamp in the main instrument cluster illuminates. Stop the vehicle as soon as safely possible and switch off the engine immediately.
-
Page 14: Transmission
Transmission 2. Press the clutch pedal to the floor, then MANUAL TRANSMISSION put the transmission in neutral (N). 3. Start the engine, then press the brake pedal and release the parking brake. 4. Move the transmission to position 1 , then slowly release the clutch pedal while slowly pressing on the accelerator. - Page 15 Transmission Before operating your vehicle at high speeds: • Verify correct tire pressures. See Tires (page 20). • Inspect wheels and tires for wear and damage. Replace any wheels or tires that have damage. • Do not operate your vehicle at high speeds with more than two passengers or while carrying cargo.
-
Page 16: Stability Control
Stability Control USING STABILITY CONTROL The AdvanceTrac® system includes traction control and electronic stability control. See the Traction Control and Stability Control chapters of the Owner's Manual for more information. Never switch off stability control or select sport mode when an emergency wheel or compact wheel is fitted as spare wheel. - Page 17 Stability Control Enhanced Torque Vectoring Control Enhanced torque vectoring control is comprised of two elements: • Torque vectoring control, which applies brake torque on the inner wheel in a curve for better traction and less understeer. • Cornering understeer control which controls the yaw response of the vehicle under braking and acceleration on high and low friction surfaces.
-
Page 18: Driving Hints
Driving Hints ENGINE OVERSPEED Note: Always wait until the engine is properly warmed up before running high engine speeds. Your vehicle has an over-rev feature to increase the performance range. The standard maximum engine speed of 6500 RPM is indicated by a narrow red line on the tachometer face. -
Page 19: Roadside Emergencies
Towing — independent service contractors, if not prohibited by state, To fully assist you should you have a local or municipal law, shall tow Ford vehicle concern, Ford Motor Company of eligible vehicles to an authorized dealer Canada, Limited offers a complimentary within 35 mi (56 km) of the roadside assistance program. - Page 20 U.S. coverage. For complete program coverage details you may contact your dealer, you can call us in Canada at 1-800-665-2006, or visit our website at www.ford.ca. Focus (CDH) ST, Canada/Mexico/United States of America, enUSA, First Printing...
-
Page 21: Maintenance
Maintenance UNDER HOOD OVERVIEW - 2.0L ECOBOOST E180866 Engine coolant reservoir. Engine oil dipstick. Engine oil filler cap. Brake fluid and clutch fluid reservoir. Battery. Engine compartment fuse box. Engine air cleaner. Washer fluid reservoir. Focus (CDH) ST, Canada/Mexico/United States of America, enUSA, First Printing... -
Page 22: Engine Oil Dipstick
Maintenance ENGINE OIL DIPSTICK E169062 Minimum. Maximum. Focus (CDH) ST, Canada/Mexico/United States of America, enUSA, First Printing... -
Page 23: Wheels And Tires
Wheels and Tires TIRES Tires Standard Optional Goodyear Eagle F1 Pirelli P-Zero Nero Size 235/40-18 235/40-18 Speed rating Load rating Usage Summer only All season Wheels 18 in. x 8.0 in., 55 mm offset aluminum wheels • Inspect your tires for damage on a As standard, your ST vehicle is equipped regular basis. -
Page 24: Using Winter Tires
They are not designed for maintain it properly. Tire pressure can winter use on ice or snow and you cannot diminish over time and fluctuate with use them with snow chains. Ford does not temperature. recommend using the original equipment Optional All-Season Tires tires when temperatures drop to approximately 41°F (5°C) or below... -
Page 25: Technical Specifications
Wheels and Tires Please call the Ford Performance Info for specific winter tire recommendations. Center at 1-800-FORD-SVT (367-3788) TECHNICAL SPECIFICATIONS WHEELS Wheel Specification Diameter and width 18 inches x 8.0 inches Offset 2.2 in (55 mm) Backspacing 6.7 in (16.949 cm) Center bore 2.5 in (63.5 mm) -
Page 26: Ations
Wheels and Tires Spare tire Continental ContiProContact Usage All Season Wheel 17 in. x 7.5 in, 52.5mm offset steel wheel See the Wheels and Tires chapter of your owner's manual for instructions on changing a road wheel. Your ST vehicle is equipped with a full-size, dissimilar spare tire assembly. Although the spare is a traditional, full size tire (as opposed to a mini-spare), it is different in both size and handling characteristics from the standard Focus ST performance tire. -
Page 27: Engine Specifications
Capacities and Specifications ENGINE SPECIFICATIONS Engine 2.0L EcoBoost engine Cubic inches Required fuel Minimum 87 octane Firing order 1–3–4–2 Ignition system Coil on plug Compression ratio 9.3:1 Spark plug gap 0.027-0.031 in (0.70-0.80 mm) A. Long drivebelt is on the first pulley Drivebelt Routing groove closest to the engine. -
Page 28: Capacities And Specifications
WW-2803 (passenger side) WW-1295 (rear) We recommend Motorcraft replacement parts available at your Ford dealer or at fordparts.com for scheduled maintenance. These parts meet or exceed Ford Motor Company’s specifications and are engineered for your vehicle. Use of other parts may impact vehicle performance, emissions and durability. -
Page 29: Transmission Code Designation
Capacities and Specifications TRANSMISSION CODE DESIGNATION Description Code Getrag-Ford Transmission (GFT) Six-speed manual transmission (MMT6) Focus (CDH) ST, Canada/Mexico/United States of America, enUSA, First Printing... -
Page 30: Capacities And Specifications
Capacities and Specifications Capacities Item Capacity Engine oil 5.7 qt (5.4 L) Engine coolant 5.3 qt (5.0 L) Brake fluid Between MIN and MAX on brake fluid reservoir Manual transmission fluid 1.8 qt (1.7 L) Approximate dry fill capacity. Actual amount may vary during fluid changes. Specifications Materials Name... -
Page 31: Focus (Cdh) St, Canada/Mexico/United States Of America, Enusa, First Printing
Capacities and Specifications Name Specification Engine coolant (Canada): WSS-M97B44-D2 Motorcraft Orange Antifreeze/Coolant Prediluted CVC-3DIL-B Brake fluid: WSS-M6C65-A2 Motorcraft DOT 4 Low Viscosity (LV) High Perform- ance Motor Vehicle Brake Fluid PM-20 Manual transmission fluid: WSS-M2C200-D2 Motorcraft Dual Clutch Transmission Fluid XT-11-QDC If you use oil and fluids that do not meet the defined specification and viscosity... -
Page 32: Focus (Cdh) St, Canada/Mexico/United States Of America, Enusa, First Printing
Capacities and Specifications Note: Ford recommends using DOT 4 Low Viscosity (LV) High Performance Brake Fluid or equivalent meeting WSS-M6C65-A2. Use of any fluid other than the recommended fluid may cause degraded brake performance and not meet the Ford performance standards. Keep brake fluid clean and dry. - Page 33 Ford Focus models. This information is covered in its entirety in the warranty information. You can obtain warranty service for your ST vehicle or any ST vehicle at any Ford dealer nationwide. Ford Global Performance does not recommend modifying or racing ST, SVT...
- Page 34 About This Supplement.........3 Fuel Economy.............11 At a Glance............5 Using the Clutch.............11 Engine Specifications..........7 Motorcraft Parts..........24 Suspension Specifications.........8 Vehicle Specifications...........6 Product History..........4 Ford Performance..........4 Base Warranty..........30 Team RS History............4 Capacities and Specifications....27 Roadside Assistance........16 Capacities..............27 Vehicles Sold in Canada: Getting Roadside Specifications............27 Assistance............16 Vehicles Sold in Canada: Roadside Assistance Program Coverage.....17...
- Page 35 Index Under Hood Overview - 2.0L EcoBoost ............18 Using Stability Control........13 Enhanced Torque Vectoring Control....14 Using Winter Tires...........21 Warranty Terms and Conditions....30 Wheels and Tires...........20 Technical Specifications........22 Winter Tires See: Using Winter Tires........21 Focus (CDH) ST, Canada/Mexico/United States of America, enUSA, First Printing...
