Page 2: Introduction
Introduction The following warning may be required by California law: CALIFORNIA Proposition 65 Warning WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 3 INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Ford may change the contents without notice and without incurring obligation. SPECIAL NOTICES...
Page 4 Introduction These are some of the symbols you may see on your vehicle. Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Brake System Brake Fluid - Non-Petroleum Based Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist Power Windows Front/Rear...
Page 5 Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Check fuel cap Vehicle Symbol Glossary Interior Luggage Compartment Release Symbol Engine Oil Engine Coolant Temperature...
Page 6: Instrumentation
Instrumentation Instrument panel dimmer switch (pg. 22) Headlamp control (pg. 21) CHECK ENGINE FUEL RESET Tilt steering wheel lever* (pg. 87) Parking brake release (pg. 156) * if equipped Instrument cluster (pg. 8) DOOR AJAR CHECK 60 70 GAGE 0 0 0 RPMx1000 0 0 0 0 0 0 Driver air bag...
Page 7 Electronic sound system (pg. 35) 4wd control* (pg. 168) BASS TREB SEEK SCAN TUNE Climate controls (pg. 22) Rear window/washer control (pg. 88) R. WIPE PUSH FADE TAPE SIDE 1 - 2 Fog lamp control* (pg. 21) Instrumentation Rear window defroster control (pg.
Page 8: Warning Lights And Chimes
Instrumentation WARNING LIGHTS AND CHIMES CHECK GAGE CHECK ENGINE CHECK FUEL CAP Check engine Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD II).
Page 9 3. The fuel cap may not have been properly installed and securely tightened. These temporary malfunctions can be corrected by filling the fuel tank with high quality fuel of the recommended octane and/or properly installing and securely tightening the gas cap. After three driving cycles without these or any other temporary malfunctions present, the Check Engine light should turn off.
Page 10 Instrumentation Air bag readiness Momentarily illuminates when the ignition is turned ON. If the light fails to illuminate, continues to flash or remains on, have the system serviced immediately. Safety belt Momentarily illuminates when the ignition is turned to the ON position to remind you to fasten your safety belts.
Page 11 Instrumentation Turn signal Illuminates when the left or right turn signal or the hazard lights are turned on. If one or both of the indicators stay on continuously or flash faster, check for a burned-out turn signal bulb. Refer to Bulbs in the Maintenance and care chapter. High beams Illuminates when the high beam headlamps are turned on.
Page 12 Instrumentation Four wheel drive low (if equipped) Momentarily illuminates when the ignition is turned to the ON/START position. Illuminates when four-wheel drive low is engaged. If the light continues to flash have the system serviced. Four wheel drive high (if equipped) Momentarily illuminates when the ignition is turned to the START position.
Page 13 Instrumentation Speed control This light comes on when either the SPEED SET/ACCEL or RESUME controls CONT are pressed. It turns off when the speed control OFF control is pressed, the brake or clutch (if equipped) is applied or the ignition is turned to the OFF position.
Page 14: Engine Coolant Temperature Gauge
Instrumentation GAUGES CHECK GAGE CHECK ENGINE CHECK FUEL Speedometer Indicates the current vehicle speed. Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H” and “C”). If it enters the red section, the engine is overheating.
Page 15: Trip Odometer
Never remove the coolant reservoir cap while the engine is running or hot. This gauge indicates the temperature of the engine coolant, not the coolant level. If the coolant is not at its proper level the gauge indication will not be accurate. Odometer Registers the total kilometers (miles) of the vehicle.
Page 16 Instrumentation Battery voltage gauge This shows the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range (as indicated), have the vehicle’s electrical system checked as soon as possible. Engine oil pressure gauge This shows the engine oil pressure in the system.
Page 17 The FUEL DOOR icon and arrow indicates which side of the vehicle the fuel filler door is located. MESSAGE CENTER (IF EQUIPPED) With the ignition in the ON position, the message center displays important vehicle information through a constant monitor of vehicle systems.
Page 18 Instrumentation For maximum accuracy of this display feature, the ignition should be in the OFF position during fueling. The display FUEL LEVEL ERROR indicates a problem with the fuel indication system. See your dealer or qualified service technician for system maintenance. Fuel status Press once to display the approximate amount of fuel...
Page 19 System check Press the system check control to display the status of the following systems: engine oil life left engine oil level voltage level engine coolant temperature washer fluid level fuel level The engine oil life left has two phases. The first display will indicate the oil change status (OK, SOON, REQUIRED).
Page 20 Instrumentation Oil change reset Press the OIL CHANGE RESET control to reset the oil life feature to 100% (or your personalized oil reset percentage) (at optimal driving conditions, 100% oil life is equivalent to a maximum of 12 000 kilometers [7 500 miles]). After you have the oil changed, you must press and hold the OIL CHANGE RESET control for five seconds.
Page 21: Controls And Features
HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to also turn on the headlamps. Foglamp control (if equipped) Turn on the low-beam headlamps or parking lamps and press the foglamp control to activate the foglamps.
Page 22 Controls and features Flash to pass Pull toward you to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlamp and parklamp operation. Rotate up to brighten. Rotate down to dim. Rotate to full up position (past detent) to turn on interior lamps.
Page 23 Temperature control knob Controls the temperature of the airflow inside the vehicle. Mode selector control Controls the direction of the airflow to the inside of the vehicle. The air conditioning compressor can operate in all modes except . However, the air conditioning will only function if the outside temperature is about 6°C (43°F) or higher.
Page 24 Controls and features (Panel and floor)-Distributes outside air through the instrument panel registers and the floor ducts. Heating and air conditioning capabilities are provided in this mode. For added customer comfort, when the temperature control knob is anywhere in between the full hot and full cold positions, the air distributed through the floor ducts will be slightly warmer than the air sent to the instrument panel registers.
Page 25 Remove any snow, ice or leaves from the air intake area (at the bottom of the windshield). If your vehicle has been parked with the windows closed during hot weather, the air conditioner will do a much faster job of cooling if you drive for two or three minutes with the windows open.
Page 26: Automatic Operation
Controls and features Turning the EATC on Press AUTOMATIC, any of the override controls or the fan speed control. The EATC will only operate when the vehicle is running. Turning the EATC off Press OFF. Automatic operation Press AUTOMATIC and select the desired temperature. The selected temperature and the word AUTO will appear in the display window.
Page 27 Temperature selection The display window indicates the selected temperature, function (AUTO or one of the override controls) and manual control of fan speed ( ) if automatic fan speed is not desired. To control the temperature, select any temperature between 18°C (65°F) and 29°C (85°F) by pressing the blue (cooler) or red (warmer) buttons.
Page 28 Controls and features Fan speed ( When AUTOMATIC is pressed, fan speed is adjusted automatically for existing conditions. You can override fan speed at any time. To control fan speed manually, use the thumbwheel or steering wheel control to cancel automatic fan speed operation.
Page 29 Controls and features MAX A/C-Uses recirculated air to cool the vehicle. The temperature will display 16°C (60°F). To exit, press AUTOMATIC or any other override controls. MAX A/C is noisier than normal A/C but more economical and will cool the inside of the vehicle faster. Airflow is from the instrument panel registers.
Page 30 Controls and features Rear fan off Press REAR FAN OFF to turn off the rear console fan. This overrides the rear console fan speed control. The EATC display window will indicate REAR FAN OFF. The rear console fan will remain off until REAR FAN OFF is pressed again.
Page 31 Remove any snow, ice or leaves from the air intake area (at the bottom of the windshield). If your vehicle has been parked with the windows closed during hot weather, the air conditioner will do a much faster job of cooling if you drive for two or three minutes with the windows open.
Page 32 Controls and features Turn the fan speed control to the - VOLUME + MODE desired position. SEEK MEMORY Select for air to flow through these vents: – VOLUME BAND SEEK MEMORY Select for air to flow through these vents: – VOLUME BAND SEEK...
Page 33 REAR WINDOW DEFROSTER The rear defroster control is located on the instrument panel. Press the rear defroster control to clear the rear window of thin ice and fog. A small LED will illuminate when the rear defroster is activated. The ignition must be in the ON position to operate the rear window defroster.
Page 34 Controls and features To help avoid personal injury, always use caution when in reverse and when using the reverse sensing system. This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle.
Page 35 The reverse sensing system is automatically enabled when the gear selector is placed in R (Reverse) and the ignition is ON. A reverse sensing control allows the driver to disable the reverse sensing system only when the ignition is ON, and the gear selector is in R (Reverse).
Page 36 Controls and features Volume/power control Press the control to turn the audio VOL - PUSH ON system on or off. Turn the control to raise or lower volume. VOL - PUSH ON If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 37 Tune adjust The tune control works in radio mode. Tune adjust in radio mode Press to move to the next frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly.
Page 38 Controls and features Setting memory preset stations 1. Select the frequency band with the AM or the FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected.
Page 39 Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. Tape select To enter tape mode while in radio mode, press the TAPE AMS control.
Page 40 Controls and features selection). The tape deck stops and returns to play mode when the AMS circuit senses a blank section on the tape. In order to ensure proper operation of the AMS feature, the tape MUST have a blank section of at least four seconds duration between programs. Rewind The rewind control works in tape mode.
Page 41 Setting the clock Press CLK to toggle between listening frequencies and clock mode while in radio mode. To set the hour, press and hold the CLK control and press the SEEK control: to decrease hours and to increase hours. To set the minute, press and hold the CLK control and press the TUNE control: to decrease minutes and...
Page 42 Controls and features When in clock mode, the media information will display for 10 seconds, when the radio is turned on, and then revert to clock information. Anytime that the media is changed, (new radio station, etc.), the media information will again display for 10 seconds before reverting back to the clock.
Page 43 Turn the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. AM/FM select The AM/FM select control works in radio and CD modes.
Page 44 Controls and features Tune adjust for CD changer (if equipped) Press to select the previous disc in the CD changer. (Play will begin on the first track of the disc unless the CD changer is in shuffle mode. Refer to Shuffle feature for more information.
Page 45 Controls and features Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the SCAN control again to stop the scan mode. Scan function in CD mode Press the SCAN control to hear a short sampling of all selections on the CD.
Page 46 Controls and features Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. CD select To begin CD play (if CD[s] are loaded), press the CD control.
Page 47 Fast forward The fast forward control works in CD mode. To fast forward in CD changer mode, press the CD control (preset Press the control again to deactivate fast forward mode. Eject function Press the control to stop and eject a Compression feature Compression adjust brings soft and loud CD passages together for a...
Page 48 Controls and features to decrease hours and to increase hours. To set the minute, press and hold the CLK control and press the TUNE control: to decrease minutes and to increase minutes. Premium AM/FM Stereo/Cassette/Single CD VOL PUSH ON SEEK TUNE SCAN DISC...
Page 49 Controls and features Volume/power control Press the control to turn the audio VOL - PUSH ON system on or off. Audio power can also be turned on by pressing the AM/FM select control or the tape/CD select control. Audio power is turned off by using the volume/power control.
Page 50 Controls and features Tune adjust The tune control works in radio or CD changer mode. Tune adjust in radio mode Press to move to the next frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly.
Page 51 Seek function in radio mode Press to find the next listenable station down the frequency band. Press to find the next listenable station up the frequency band. Seek function in tape mode Press to listen to the previous selection on the tape. Press to listen to the next selection on the tape.
Page 52 Controls and features Scan function in tape mode Press the SCAN control to hear a short sampling of all selections on the tape. (The tape scans in a forward direction. At the end of the tape’s first side, direction automatically reverses to the opposite side of the tape.) To stop on a particular selection, press the control again.
Page 53: Treble Adjust
Starting autoset memory preset 1. Select a frequency using the AM/FM select controls. 2. Press the AUTO control. 3. When the first six strong stations are filled, the station stored in memory preset control 1 will start playing. If there are less than six strong stations available on the frequency band, the remaining memory preset controls will all store the last strong station available.
Page 54: Speaker Balance Adjust
Controls and features Press the TREB control then press: to decrease the treble output to increase the treble output. Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Press the BAL control then press: to shift sound to the left and to shift sound to the right.
Page 55 Tape/CD select To begin tape play (with a tape loaded into the audio system) while in the radio or CD mode, press the TAPE control. Press the button during rewind or fast forward to stop the rewind or fast forward function. To begin CD play (if CD(s) are loaded), press the CD control.
Page 56 Controls and features Tape direction select Press SIDE 1–2 to play the alternate SIDE 1-2 side of a tape. Eject function Press the EJ control to stop and eject a tape. Press the EJ control to stop and eject a CD. Dolby noise reduction Dolby noise reduction operates in tape mode.
Page 57 Shuffle feature The shuffle feature operates in CD mode (if equipped) and plays all tracks on the current disc in random order. If equipped with the CD changer, the shuffle feature continues to the next disc after all tracks on the current disc are played. Press the SHUFFLE control to start this feature.
Page 58 Controls and features To set the minute, press and hold the CLK control and press TUNE: to decrease minutes and to increase minutes. If your vehicle has a separate clock module, (other than the digital radio display), the CLK button will not function in the above manner.
Page 59 Rear seat controls (if equipped) The Personal Audio System, a feature of the optional Premium AM/FM Stereo/Cassette/Single CD and the MACH Audio System with AM/FM Stereo/Cassette/Single CD, allows front and middle seat passengers to listen to different media sources (radio, cassette or CD) simultaneously.
Page 60 Controls and features Adjusting the volume Press the + control to increase volume. Press the - control to decrease volume. From the rear seat controls, volume control can be set no higher than the current radio setting unless the speakers are turned off. Refer to Turning speakers on and off.
Page 61 Mode select Push the MODE control to toggle between AM, FM1, FM2, tape, CD or CD changer (if equipped). Memory preset control Push the MEMORY control successively to allow rear seat passengers to scroll through the 6 memory presets in AM, FM1 or FM2.
Page 62 Controls and features MACH Audio System with AM/FM Stereo/Cassette/Single CD VOL - PUSH ON SEEK TUNE SCAN Volume/power control Press the control to turn the audio system on or off. Turn control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 63 volume level, turn the audio system off with the power control before switching off the ignition. AM/FM select The AM/FM select control works in radio, tape and CD modes. AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations.
Page 64 Controls and features Tune adjust for CD changer (if equipped) Press to select the previous disc in the CD changer. (Play will begin on the first track of the disc unless the CD changer is in shuffle mode. Refer to Shuffle feature for more information.
Page 65 Seek function for CD changer (if equipped) Press to seek to the previous track of the current disc. If a selection has been playing for three seconds or more and you press , the CD changer will replay that selection from the beginning.
Page 66 Controls and features Setting memory preset stations 1. Select the frequency band with the AM/FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected.
Page 67 to decrease bass output and to increase bass output. Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output. Press the TREB control then press: to decrease treble output and to increase treble output. Speaker balance adjust Speaker sound distribution can be adjusted between the right and left...
Page 68 Controls and features Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. Press the FADE control then press: to shift sound to the front to shift sound to the rear. Tape/CD/CD changer (if equipped) select To begin tape play (with a tape loaded into the audio system) while in the radio or CD mode,...
Page 69 In CD mode, pressing the REW control for less than three seconds results in slow rewind. Pressing the control for more than three seconds results in fast rewind. Fast forward The fast forward control works in tape and CD modes. In the tape mode, tape direction will automatically reverse when the end of the tape is reached.
Page 70 Controls and features Compression adjust Compression adjust brings soft and loud CD passages together for a more consistent listening level. Press the COMP control to activate and deactivate compression adjust. Shuffle feature The shuffle feature operates in CD mode and plays all tracks on the current disc in random order.
Page 71 To set the minute, press the clock/RDS control until SELECT MIN is displayed and press: to decrease minutes and to increase minutes. Radio Data System (RDS) feature This feature allows your audio system to receive text information from RDS-equipped FM radio stations.
Page 72 Controls and features RDS traffic announcement Press the RDS control until TRAFFIC is displayed. Use the SELECT control to select ON or OFF. With the feature ON, use the SEEK or SCAN control to find a radio station broadcasting a traffic report (if it is broadcasting RDS data).
Page 73 Classic Country Info Jazz/R&B Religious Rock Soft Top 40 RDS show With the RDS menu enabled, press the RDS control until SHOW is displayed. Use the SEL control to select TYPE, NAME, TEXT or NONE. When your radio is turned to a RDS station, RDS station TYPE, station NAME, or TEXT message will be displayed along with the...
Page 74 Controls and features Rear seat controls (if equipped) The Personal Audio System, a feature of the optional Premium AM/FM Stereo/Cassette/Single CD and the MACH Audio System with AM/FM Stereo/Cassette/Single CD, allows front and middle seat passengers to listen to different media sources (radio, cassette or CD) simultaneously.
Page 75 Adjusting the volume Press the + control to increase volume. Press the - control to decrease volume. From the rear seat controls, volume control can be set no higher than the current radio setting unless the speakers are turned off. Refer to Turning speakers on and off.
Page 76 Controls and features Mode select Push the MODE control to toggle between AM, FM1, FM2, tape, CD or CD changer (if equipped). Memory preset control Push the MEMORY control successively to allow rear seat passengers to scroll through the 6 memory presets in AM, FM1 or FM2.
Page 77 CD changer (if equipped) The CD changer is located in one of the following locations: in the trunk in the center console under the driver’s seat 1. Slide the door to access the CD changer magazine. 2. Press to eject the magazine. 3.
Page 78 Controls and features If you pull too hard on the disc holder, the disc holder may come completely out of the magazine. If this happens, reinsert the disc holder back into the magazine while pressing on the lever (A). 5. Line up the CD with the groove of the disc holder.
Page 79 The CD magazine may be inserted or ejected with the radio power off. ONLY use the magazine supplied with the CD changer, other types will damage the unit. Keep the CD changer door closed. Coins and foreign objects will damage the CD player and void your audio system warranty.
Page 80 Controls and features Do not insert more than one disc into each slot of the CD changer magazine. Do not insert any promotional (odd shaped or sized) discs, or discs with removable labels into the CD player as jamming may occur.
Page 81 Terrain. Hills, mountains and tall buildings between your vehicle’s antenna and the radio station signal can cause FM reception problems. Static can be caused on AM stations by power lines, electric fences, traffic lights and thunderstorms. Moving away from an interfering structure (out of its “shadow”) returns your reception to normal.
Page 82 Controls and features 4. ON, all electrical circuits operational. Warning lights illuminated. Key position when driving. 5. START, cranks the engine. Release the key as soon as the engine starts. SPEED CONTROL (IF EQUIPPED) To turn speed control on Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph).
Page 83 To set a speed Press SET/SET ACC/SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph). If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed.
Page 84 Controls and features You can accelerate with the accelerator pedal at any time during speed control usage. Releasing the accelerator pedal will return your vehicle to the previously programmed set speed. To set a lower set speed Press and hold CST/COAST. Release the control when the desired speed is reached or Press and release CST/COAST to...
Page 85 To disengage speed control Depress the brake pedal or Depress the clutch pedal (if equipped). Disengaging the speed control will not erase the previously programmed set speed. Pressing OFF will erase the previously programmed set speed. Controls and features...
Page 86 Controls and features To return to a previously set speed Press RES/RSM/RESUME. For RES/RSM/RESUME to operate, the vehicle speed must be faster than 48 km/h (30 mph). Indicator light This light comes on when either the SET ACCEL or RES controls are pressed.
Page 87 Controls and features TILT STEERING WHEEL (IF EQUIPPED) Pull the tilt steering control toward you to move the steering wheel up or down. Hold the control while adjusting the wheel to the desired position, then release the control to lock the steering wheel in position. Never adjust the steering wheel when the vehicle is moving.
Page 88 Controls and features Push (tap) the end of the stalk briefly for a single swipe (no wash). Push and hold for three swipes with wash. Push and hold for a longer wash (up to ten seconds). Speed dependent wipers When the windshield wiper control is set on the intermittent settings, speed-sensitive front wipers automatically adjust as the vehicle’s speed changes.
Page 89 STEERING WHEEL CONTROLS (IF EQUIPPED) These controls allow you to operate some radio and climate control features. Radio control features Press BAND/MODE to select AM, FM1, FM2, TAPE or CD (if equipped). In Radio mode: Press MEM/NEXT to select a preset station from memory.
Page 90 Controls and features OVERHEAD CONSOLE (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package. Storage compartment (if equipped) Press the OPEN control to open the storage compartment. The door will open slightly and can be moved to full open.
Page 91 Place the provided height adaptors onto the back of the GARAGE control as needed. Press the GARAGE control to activate the transmitter. Moon roof (if equipped) You can move the moon roof back to open the glass panel or tilt up to ventilate the vehicle.
Page 92 Controls and features Do not let children play with the moon roof. They may seriously hurt themselves. Electronic compass/temperature display (if equipped) Outside air temperature The outside temperature display is contained in the overhead console. The temperature display can be turned off and on by pressing the MODE control on the overhead console.
Page 93 Controls and features Compass zone adjustment 1. Determine which magnetic zone you are in by referring to the zone map. 2. Press and hold the MODE control until VAR appears in the display, then release. The display should show the current zone number. 3.
Page 94 Controls and features Compass calibration adjustment Perform this adjustment in an open area free from steel structures and high voltage lines: Press and hold the MODE control until CAL appears in the display (approximately eight seconds) and release. Drive the vehicle slowly (less than 5 km/h [3 mph]) in circles until CAL indicator turns off in about 2–3 complete circles.
Page 95 Programming 1. Prepare for programming the HomeLink Universal Transceiver by erasing the three factory default codes by holding down the two outside buttons until the red light begins to flash after 20 seconds. Release both buttons. 2. Hold the end of your hand-held transmitter 5–14 cm (2–5 inches) away from the HomeLink Universal Transceiver surface (located on your visor) while keeping the red light in view.
Page 96 Controls and features To program your hand-held transmitters: continue to hold the button on the HomeLink Universal Transceiver. press and re-press the hand-held transmitter button every two seconds until the red light changes from a slow to a fast flash. Operating the HomeLink Universal Transceiver Once programmed, the HomeLink Universal Transceiver can be used in...
Page 97 3. Press and release the programmed HomeLink button. Press and release the HomeLink button a second time to complete the training process. (Some garage door openers may require this procedure to be done a third time to complete the training). The 2nd or 3rd press from step 3 will activate the door.
Page 98 Controls and features Operating TravelNote TravelNote records and stores messages for up to three minutes in total length with simple controls. When you get an idea or remember something important while you’re driving, you don’t have to try to scribble it down or pull off the side of the road. All you have to do is push a button and begin speaking.
Page 99 To delete a message: 1. Press and release the DEL button while listening to a message or shortly after. The indicator light will flash green twice. 2. To delete all recorded messages, simultaneously press and release the PLAY and REC buttons at the same time. The indicator light will flash green twice.
Page 100 Controls and features 4. The autolamp automatically turns the lamps on and off. The indicator light will illuminate when the headlamps turn on. AUTOMATIC DIMMING REAR VIEW MIRROR The autolamp/automatic dimming mirror is equipped with an automatic dimming feature. This feature will change from the normal state to the non-glare “active”...
Page 101 One touch down Press AUTO completely down and release quickly. The driver’s window will open fully. Depress again to stop window operation. One touch down can be deactivated during operation by pushing down on the top part of the driver power window control.
Page 102 Controls and features CHILDPROOF DOOR LOCKS When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 103 Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place.
Page 104 Controls and features Use only soft cups in the cupholder. Hard objects can injure you in a collision. Auxiliary power point The power point is an additional power source for electrical accessories. Rear console features The rear console incorporates the following features: air vents audio system controls...
Page 105 CENTER ARMREST/REAR CUPHOLDER (IF EQUIPPED) Do not attempt to raise the console armrest when the rear cupholder is in use. If you find resistance when raising the armrest, make sure the cupholder is fully closed or else damage may occur to the armrest. POSITIVE RETENTION FLOOR MAT Position the floor mat so that the eyelet is over the pointed end of the...
Page 106 Controls and features The liftgate door and window should be closed before driving your vehicle. If not, possible damage may occur to the liftgate door lift cylinders and attaching hardware. Make sure that the liftgate door and/or window are closed to prevent exhaust fumes from being drawn into the vehicle.
Page 107 1. Remove the shade from the vehicle and extend it with the smooth grain facing you. 2. Wrap the vinyl around the roller tube twice. Tuck the edges of the vinyl inside the end cap with each wrap. 3. Fold the edges of the vinyl towards the center, making sure that the edges clear the end cap slots.
Page 108 Controls and features Unlocking the doors Press this control to unlock the driver’s door. The interior lamps will illuminate. Press the control a second time within five seconds to unlock all doors. Locking the doors Press this control to lock all doors. To confirm all doors are closed and locked, press the control a second time within five seconds.
Page 109 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Memory seat feature (if equipped) The remote entry system can also control the memory seat feature. Press the control once to unlock the driver’s door and move the memory seat feature to the corresponding memory position, just as if you had...
Page 110 Controls and features The memory feature will continue to work from the door control even when deactivated at the remote entry module. Replacing the battery The transmitter is powered by one coin type three-volt lithium battery CR2032 or equivalent. Typical operating range will allow you to be up to 10 meters (33 feet) away from your vehicle.
Page 111 Replacing lost transmitters If a remote transmitter has been lost and you would like to remove it from the vehicle’s memory, or you would like to purchase additional remote transmitters and have them programmed to your vehicle: Take all your vehicle’s transmitters to your dealer for programming, or Perform the programming...
Page 112 Controls and features Illuminated entry The interior lamps illuminate when the remote entry system is used to unlock the door(s) or sound the personal alarm. The system automatically turns off after 25 seconds or when the ignition is turned to the RUN or ACC position. The dome lamp control (if equipped) must not be set to the OFF position for the illuminated entry system to operate.
Page 113 Programming your own personal entry code 1. Enter the factory-set code (keypad will illuminate when pressed). 2. Press the 1/2 control within five seconds of step 1. 3. Enter your personal 5 digit code. Enter each digit within five seconds of the previous one.
Page 114 Controls and features To unlock all doors, enter the factory-set code or personal code (driver door unlocks) and press the 3/4 control within five seconds. Locking the doors with the keyless entry system To lock all the doors, press 7/8 and 9/0 at the same time.
Page 115 Controls and features 2. Press and release the 3/4 control while holding the 7/8 control. 7 8 9 0 3. Release the 7/8 control. The horn will chirp once if autolock was deactivated or twice (one short and one long chirp) if autolock was activated.
Page 116 If a problem occurs, turn the ignition OFF and restart the engine with all other objects on the key ring held away from the ignition key. Check to make sure the encoded ignition key is an approved Ford encoded ignition key.
Page 117 Theft indicator The theft indicator on the instrument cluster will operate as follows: When the ignition is OFF, the theft indicator will flash briefly every two seconds to indicate the SecuriLock vehicle. When the ignition is turned to ON or START, the theft indicator will light for three seconds and then go out.
Page 118 Controls and features 3. Within five seconds of turning the ignition to OFF, insert the second previously programmed SecuriLock key into the ignition and turn the ignition from OFF to ON (maintain ignition in ON for at least one second but no more than five seconds).
Page 119: Seating And Safety Restraints
SEATING Adjustable head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 120 Seating and safety restraints Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Reclining the seatback can reduce the effectiveness of the seat’s safety belt in the event of a collision. Lift handle to move seat forward or backward.
Page 121 Reclining the seatback can reduce the effectiveness of the seat’s safety belt in the event of a collision. The control is located on the outboard side of the seat cushion. Press front to raise or lower the front portion of the seat cushion. Press rear to raise or lower the rear portion of the seat cushion.
Page 122 Seating and safety restraints Memory seats (if equipped) This system allows automatic positioning of the driver seat to three programmable positions. The memory seat control is located on the driver door. To program position one, move the driver seat to the desired position using the seat controls.
Page 123 Seating and safety restraints Using the power lumbar support (if equipped) The power lumbar control is located on the outboard side of the seat. Press one side of the control to adjust firmness. Press the other side of the control to adjust softness.
Page 124 Seating and safety restraints 1. Press the lower release control downward to unlatch the seatback. 2. Rotate the seatback downward into the load floor position. 3. Press down on the top outboard area of the seatback until a click is heard.
Page 125 To return the seat to the upright position: Press downward on the upper corner of the seatback and hold. Pull the release handle upward to unlatch the seat. Rotate the seatback upward until the seatback latches in the upright position. The seatback will click when it is locked into position.
Page 126 Seating and safety restraints All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag SRS is provided. It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.
Page 127 After any vehicle collision, the safety belt system at all outboard seating positions (except driver, which has no “automatic locking retractor” feature) must be checked by a qualified technician to verify that the “automatic locking retractor” feature for child seats is still functioning properly.
Page 128 Seating and safety restraints The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat outboard safety belts have two types of locking modes described below: Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
Page 129 Grasp the shoulder portion and pull downward until the entire belt is extracted. Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the...
Page 130 Seating and safety restraints Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button and slide the height adjuster down.
Page 131 Conditions of operation If... The driver’s safety belt is not buckled before the ignition switch is turned to the ON position... The driver’s safety belt is buckled while the indicator light is illuminated and the warning chime is sounding... The driver’s safety belt is buckled before the ignition switch is turned to the ON position...
Page 132 3 of 4 fatal crashes occur within 25 miles of home. Ford designs its safety belts to enhance comfort. If you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible;...
Page 133 Reasons given... The people I’m with don’t wear belts I have an air bag I’d rather be thrown clear Do not sit on top of a buckled safety belt to avoid the Belt Minder chime. Sitting on the safety belt will increase the risk of injury in an accident.
Page 134 Seating and safety restraints the driver’s safety belt is unbuckled the parklamps/headlamps are in OFF position (If vehicle is equipped with Autolamps, the Autolamps feature MUST be turned off.) To reduce the risk of injury, do not deactivate/activate the Belt Minder feature while driving the vehicle.
Page 135 This information will assist Ford in the servicing of your vehicle and may help Ford better understand real world collisions and further improve the safety of future vehicles.
Page 136 Seating and safety restraints Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly or gently and the risk of injury from a deploying air bag is greatest close to the trim covering the air bag...
Page 137 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln Mercury dealer. Children and air bags...
Page 138 Seating and safety restraints How does the air bag supplemental restraint system work? The air bag SRS is designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates air bag inflation.
Page 139 Several air bag system components get hot after inflation. Do not touch them after inflation. If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
Page 140 Do not attempt to service, repair, or modify the air bag Supplemental Restraint System, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always...
Page 141 How does the side air bag system work? The side air bag system consists of the following: An inflatable nylon bag (air bag) with a gas generator concealed behind the outboard bolster of the driver and front passenger seatbacks. A special seat cover designed to allow airbag deployment.
Page 142 Seating and safety restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the side air bag has deployed, the air bag will not function again. The side air bag system (including the seat) must be inspected and serviced by a qualified technician in accordance with...
Page 143 Disposal of air bags and air bag equipped vehicles (including pretensioners) For disposal of air bags or air bag equipped vehicles, see your local dealership or qualified technician. Air bags MUST BE disposed of by qualified personnel. SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children.
Page 144 To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all applicable Federal motor vehicle safety standards. Belt-positioning booster seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child.
Page 145 (passenger side front and outboard rear seating positions) (if equipped). Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage. For more information on top tether straps, refer to Attaching safety seats with tether straps.
Page 146 Seating and safety restraints Installing child safety seats in combination lap and shoulder belt seating positions Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 147 Seating and safety restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 148 Seating and safety restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 149 The anchorbracket must be installed using the instructions provided with the kit. Tether anchorage hardware kits (part number 613D74) including instructions, may be obtained at no charge from any Ford or Lincoln/Mercury dealer. Tighten the anchor according to specifications. Otherwise, the safety seat may not be properly secured and the child may be injured in a sudden stop or collision.
Page 150 Starting PREPARING TO START YOUR VEHICLE Engine starting is controlled by the powertrain control system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
Page 151 2. Make sure the headlamps and vehicle accessories are off. If starting a vehicle with an automatic transmission: Make sure the parking brake is set. Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: Make sure the parking brake is set.
Page 152: Starting The Engine
Starting steering wheel is turned when getting in or out of the vehicle CHECK GAGE CHECK ENGINE <FUEL DOOR CHECK FUEL CAP Make sure the corresponding lights illuminate briefly. If a light fails to illuminate, have the vehicle serviced. If the driver’s safety belt is fastened, the STARTING THE ENGINE 1.
Page 153 Using the engine block heater (if equipped) An engine block heater warms the engine coolant, which improves starting, warms up the engine faster and allows the heater-defroster system to respond quickly. Use of an engine block heater is strongly recommended if you live in a region where temperatures reach -23°C (-10°F) or below.
Page 154 Starting Important ventilating information If the engine is idling while the vehicle is stopped in an open area for long periods of time, open the windows at least 2.5 cm (one inch). Adjust the heating or air conditioning (if equipped) to bring in fresh air. Improve vehicle ventilation by keeping all air inlet vents clear of snow, leaves and other debris.
Page 155: Driving
Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
Page 156 Driving ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the...
Page 157 The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the ignition is turned ON) until the parking brake is released. Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park) (automatic transmission) or in 1 (First) (manual transmission).
Page 158 Driving underinflated tire(s) on any wheel(s) high crown in center of road high crosswinds wheels out of alignment loose or worn components in steering linkage AIR SUSPENSION SYSTEM (IF EQUIPPED) The load leveling feature of the air suspension automatically keeps the vehicle at a constant level if a load is added or removed from the vehicle.
Page 159 In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Your vehicle has special design and equipment features to make it capable of performing in a wide variety of circumstances. These special design features, such as larger tires and increased ground clearance, give the vehicle a higher center of gravity than a passenger car.
Page 160 Driving 2. Insert the key and turn it to OFF. Apply the brake pedal and shift to N (Neutral). 3. Start the vehicle. If it is necessary to use the above procedure to move the gearshift lever, it is possible that a fuse has blown or the vehicle’s brakelamps are not operating properly.
Page 161 Understanding gearshift positions P (Park) Always come to a complete stop before shifting into P (Park). Make sure the gearshift lever is securely latched in P (Park). This position locks the transmission and prevents the rear wheels from turning. Always set the parking brake fully and make sure the gearshift lever is latched in P (Park).
Page 162 Driving The transmission control indicator light (TCIL) will illuminate on the instrument cluster. Drive – Not shown on the display. Activate by pressing the transmission control switch on the end of the gearshift lever with the gearshift in position. The O/D OFF indicator will illuminate on the instrument cluster.
Page 163 Forced Downshifts To gain acceleration in passing another vehicle, push the accelerator to the floor. The transmission will downshift to the appropriate gear: third, second or first gear. Driving with a 5–speed automatic transmission (if equipped) Your automatic transmission electronically controls the shift feel by using an adaptive learning strategy.
Page 164 Driving Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn off the ignition whenever you leave your vehicle. R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse).
Page 165 Drive – Not shown on the display. Activate by pressing the transmission control switch on the end of the gearshift lever with the gearshift in (Overdrive) position. The TCIL will illuminate on the instrument cluster. Transmission operates in gears one through four. Drive (O/D OFF) provides more engine braking than whenever driving conditions (i.e., city traffic, hilly terrain, etc.) cause the transmission to excessively shift between...
Page 166 Driving Driving a manual transmission (if equipped) Using the clutch Vehicles equipped with a manual transmission have a starter interlock that prevents Starting the engine unless the clutch pedal is fully depressed. When starting a vehicle with a manual transmission: 1.
Page 167 2. Engage the parking brake. 3. Shift into 1 (First). 4. Turn the ignition to Off. Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully. Recommended shift speeds (recommended for best fuel economy) Shift from:...
Page 168 Driving Shift from: 5 (Overdrive) - 4 4 - 3 3 - 2 2 - 1 Reverse Ensure that the vehicle is at a complete stop before shifting into R (Reverse). Failure to do so may damage the transmission. Put the gearshift lever into N and wait at least several seconds before shifting into R.
Page 169 Positions of the Control-Trac system The Control-Trac system functions in three modes: The 4WD AUTO mode provides four-wheel drive with full power delivered to the rear axle, and to the front axle as required for increased traction. This is appropriate for normal on-road operating conditions, such as dry road surfaces, wet pavement, snow and gravel.
Page 170 Driving tire could result in damage to driveline components and make the vehicle difficult to control. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 171 Shifting from 4WD LOW to 4WD AUTO or 4WD HIGH 1. Bring the vehicle to a stop. 2. Depress the brake. 3. Place the gearshift in N (Neutral) (automatic transmission) or depress the clutch (manual transmission). 4. Move the 4WD control to the 4WD AUTO or 4WD HIGH position.
Page 172 Driving Sand When driving over sand, try to keep all four wheels on the most solid area of the trail. Do not reduce the tire pressures but shift to a lower gear and drive steadily through the terrain. Apply the accelerator slowly and avoid spinning the wheels.
Page 173 When speed control is on and you are driving uphill, your vehicle speed may drop considerably, especially if you are carrying a heavy load. If vehicle speed drops more than 16 km/h (10 mph), the speed control will cancel automatically. Resume speed with accelerator pedal. If speed control cancels after climbing the hill, reset speed by pressing and holding the SET ACCEL button (to resume speeds over 50 km/h (30 mph).
Page 174 Driving Driving off-road with AWD Your vehicle is specially equipped for driving on sand, snow, mud and rough terrain and has operating characteristics that are somewhat different from conventional vehicles, both on and off the road. Maintain steering wheel control at all times, especially in rough terrain. Since sudden changes in terrain can result in abrupt steering wheel motion, make sure you grip the steering wheel from the outside.
Page 175 Driving When driving through water, determine the depth; avoid water higher than the bottom of the hubs (if possible) and proceed slowly. If the ignition system gets wet, the vehicle may stall. Once through water, always try the brakes. Wet brakes do not stop the vehicle as effectively as dry brakes.
Page 176 Driving Automatic transmissions may shift frequently while driving up steep grades. Eliminate frequent shifting by shifting out of D (Drive). Driving on snow and ice An AWD vehicle has advantages over 2WD vehicles in snow and ice but can skid like any other vehicle. Avoid sudden applications of power and quick changes of direction on snow and ice.
Page 177 GVWR (Gross Vehicle Weight Rating): Maximum total weight of the base vehicle, passengers, optional equipment and cargo. The GVWR is specific to each vehicle and is listed on the Safety Certification Label on the driver’s door pillar. GAWR (Gross Axle Weight Rating): Carrying capacity for each axle system.
Page 178 Driving to the front of your vehicle, (potentially including weight added to the cab), the weight added should not exceed the front axle reserve capacity (FARC). Additional frontal weight may be added to the front axle reserve capacity provided you limit your payload in other ways (i.e. restrict the number of passengers or amount of cargo carried).
Page 179 DRIVING THROUGH WATER Do not drive quickly through standing water, especially if the depth is unknown. Traction or brake capability may be limited and if the ignition system gets wet, your engine may stall. Water may also enter your engine’s air intake and severely damage your engine. If driving through deep or standing water is unavoidable, proceed very slowly.
Page 180 Driving Do not exceed the maximum loads listed on the Safety Compliance Certification label. For load specification terms found on the label, refer to Vehicle loading in this chapter. Remember to figure in the tongue load of your loaded vehicle when figuring the total weight. Trailer towing table (4x2 w/manual transmission) GCWR (Gross Combined Weight Rating)/Trailer weights Rear...
Page 181 Trailer towing table (4x4 w/manual transmission) GCWR (Gross Combined Weight Rating)/Trailer weights Rear Engine axle ratio 3.27 4.0L OHV 3.55 4.0L OHV 3.73 4.0L OHV 4.10 4.0L OHV 4.0L OHV 3.55 4.0L OHV 3.73 Notes: - For high altitude operation, reduce GCW by 2% per 300 meters (1 800 ft) elevation.
Page 182 Driving Trailer towing table (4x2 w/automatic transmission) GCWR (Gross Combined Weight Rating)/Trailer weights Rear Engine axle ratio 3.55 4.0L 3.73 4.0L OHV 4.0L 3.27 SOHC 4.0L 3.55 SOHC 4.0L 3.73 SOHC 3.55 4.0L OHV 3.73 4.0L OHV 4.0L 3.55 SOHC 4.0L 3.73 SOHC...
Page 183 Trailer towing table (4x2 w/automatic transmission) Notes: For high altitude operation, reduce GCW by 2% per 300 meters (1 000 ft) elevation. For definition of terms and instructions on calculating your vehicle’s load, refer to Vehicle loading in this chapter. Maximum trailer weights shown.
Page 184 Driving (4x4 and AWD with automatic transmission) 4.0L 3.73 SOHC 4.0L 4.10 SOHC 5.0L 3.55 5.0L 3.73 Notes: For high altitude operation, reduce GCW by 2% per 300 meters (1 000 ft) elevation. For definition of terms and instructions on calculating your vehicle’s load, refer to Vehicle loading in this chapter.
Page 185 Never connect any trailer lighting to the vehicle’s taillamp circuits, because it may damage the electrical system resulting in fire. Contact your local Ford dealership for assistance in proper trailer tow wiring installation. Additional electrical equipment may be required.
Page 186 Driving Driving while you tow When towing a trailer: Ensure that you turn off your speed control. The speed control may shut off automatically when you are towing on long, steep grades. Consult your local motor vehicle speed regulations for towing a trailer. Use a lower gear when towing up or down steep hills.
Page 187 Maximum distance is 80 km (50 miles). If a distance of 80 km (50 miles) or a speed of 56 km/h (35 mph) must be exceeded, you must disconnect the driveshaft. Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation.
Page 188 Driving Improper removal/installation of the driveshaft can cause transmission fluid loss, damage to the driveshaft and internal transmission components. RWD vehicles with 4x4 electronic shift transfer case or All Wheel Drive (AWD) vehicles with automatic transmissions Regarding recreational towing or having your vehicle towed, 4x4 vehicles with electronic shift on the fly and AWD vehicles cannot be towed with any wheels on the ground (with the exception of moving it as a disabled vehicle off the road out of traffic).
Page 189: Roadside Emergencies
GETTING ROADSIDE ASSISTANCE To fully assist you should you have a vehicle concern, Ford offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: 24–hours, seven days a week for the Basic warranty period (Canada) or New Vehicle Limited Warranty period (U.S.) of three years or 60,000 km (36,000 miles),...
Page 190 Roadside coverage beyond basic warranty In the United States, you may purchase additional roadside assistance coverage beyond this period through the Ford Auto Club by contacting your Ford or Lincoln Mercury dealer. Similarly in Canada, you may purchase additional coverage beyond the basic coverage period by consulting the Ford Roadside Assistance Club brochure or by calling 1–877–294–CLUB (1–877–894–2582).
Page 191 Roadside emergencies The fuel pump shut-off switch is located in the passenger’s foot well, by the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.
Page 192 Roadside emergencies Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. Standard fuse amperage rating and color Fuse Mini Rating Fuses Grey...
Page 193: Passenger Compartment Fuse Panel Fuses
Passenger compartment fuse panel The fuse panel is located on the left hand side of the instrument panel facing the driver’s side door. Pull the panel cover outward to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 194 Roadside emergencies The fuses are coded as follows: Fuse/Relay Location Fuse Amp Passenger Compartment Fuse Rating 7.5A Power Mirror Switch, Power Antenna, Memory Seat 7.5A Blower Motor Relay, Air Bag Diagnostic Monitor 7.5A Left Stop/Turn Trailer Tow Connector Left Headlamp Data Link Connector (DLC) 7.5A Rear Blower Motor (Without...
Page 195 Fuse/Relay Fuse Amp Location Roadside emergencies Passenger Compartment Fuse Rating Windshield Wiper Motor, Wiper Hi-Lo Relay, Wiper Run/Park Relay Cigar Lighter Drivers Unlock Relay, All Unlock Relay, All Lock Relay, Power Seats PCM Power Diode 7.5A RAP Module, Generic Electronic Module (GEM), Radio Flasher (Hazard) Auxiliary Power Socket...
Page 196: Power Distribution Box Fuses
Roadside emergencies Fuse/Relay Location Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses.
Page 197 MEGAFUSE The high-current fuses are coded as follows: Fuse/Relay Location Roadside emergencies Fuse Amp Power Distribution Box Rating 60A** I/P Fuse Panel 40A** Blower Motor Relay 50A** 4 Wheel Anti-Lock Brake System (4WABS) Module 30A** Power Windows, Power Moon Roof, Power Seat 50A** Ignition Switch, Starter Relay 20A**...
Page 198 Roadside emergencies Fuse/Relay Location * Mini Fuses ** Maxi Fuses Fuse Amp Power Distribution Box Rating — Not Used 10A* Powertrain Control Module 30A* 4 Wheel Anti-Lock System (4WABS) Module 15A* Rear Wiper Motor 20A* Fuel Pump Relay and RAP Module 15A* Horn Relay...
Page 199 CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed. Hold the steering wheel firmly and slowly move to a safe place on the side of the road. Spare tire information Your vehicle is equipped with a 15”...
Page 200 Roadside emergencies Removing the spare tire 1. Insert the jack handle into the rear bumper opening. The handle will stop moving and forward resistance to turning will be felt when properly engaged. 2. Turn the handle counterclockwise until tire is lowered to the ground, the tire can be slid rearward and the cable is slightly slack.
Page 201 1. Park on a level surface, activate hazard flashers and set the parking brake. 2. Place gearshift lever in P (Park) or in the reverse gear (manual transmission) and turn engine OFF. When one of the rear wheels is off the ground, the transmission alone will not prevent the vehicle from moving or slipping off the jack, even if the...
Page 202 Roadside emergencies On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle. 6. Turn OFF the air suspension switch (if equipped). Refer to Air suspension system in the Driving chapter. 7.
Page 203 To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire. Never use the front or rear differential as a jacking point.
Page 204 Roadside emergencies JUMP STARTING YOUR VEHICLE The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Do not push start your vehicle. You could damage the catalytic converter.
Page 205 Roadside emergencies Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 206 Roadside emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 207 Roadside emergencies 4.0L SOHC 5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts. Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed.
Page 208 Roadside emergencies Engines except 4.0L SOHC 4.0L SOHC...
Page 209 Roadside emergencies 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery.
Page 210 Roadside emergencies 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 211 It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 212: Maintenance And Care
Maintenance and care SERVICE RECOMMENDATIONS To help you service your vehicle: We highlight do-it-yourself items in the engine compartment for easy location. We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 213 3. Turn off the engine and remove the key. 4. Block the wheels to prevent the vehicle from moving unexpectedly. Working with the engine on Automatic transmission: 1. Set the parking brake and ensure the gearshift is securely latched in P (Park).
Page 214 Maintenance and care 2. Go to the front of the vehicle and release the auxiliary latch that is located in the center between the hood and the grill. 3. Lift the hood until the lift cylinders hold it open.
Page 215 Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.0L OHV V6 engine 1. Windshield washer fluid reservoir 2. Engine oil filler cap 3. Transmission fluid dipstick (automatic transmission) 4. Engine oil dipstick 5. Power steering fluid reservoir 6. Brake fluid reservoir 7.
Page 216 Maintenance and care 4.0L SOHC V6 engine 1. Windshield washer fluid reservoir 2. Automatic transmission fluid dipstick 3. Engine oil filler cap 4. Engine oil dipstick 5. Brake fluid reservoir 6. Power distribution box 7. Battery 8. Power steering fluid reservoir 9.
Page 217 Maintenance and care 5.0L V8 engine 1. Engine coolant reservoir 2. Windshield washer fluid reservoir 3. Engine oil filler cap 4. Automatic transmission fluid dipstick 5. Brake fluid reservoir 6. Power distribution box 7. Battery 8. Power steering fluid reservoir 9.
Page 218 Maintenance and care 3. Set the parking brake and ensure the gearshift is securely latched in P (Park) (automatic transmissions) or 1 (First) (manual transmissions). 4. Open the hood. Protect yourself from engine heat. 5. Locate and carefully remove the engine oil level indicator (dipstick). 4.0L V6 engines 5.0L V8 engine ADD 1QT...
Page 219 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. If the oil level is between the ADD and FULL marks or between the MIN and MAX marks (depending on application), the oil level is acceptable. DO NOT ADD OIL. If the oil level is below the ADD mark or MIN mark, add enough oil to raise the level within the...
Page 220 Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 221 MAX. Do not fill above this line. 4. Use only a DOT 3 brake fluid certified to meet Ford specifications. Refer to Lubricant specifications in the Capacities and specifications chapter. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 222 If the fluid level drops, refill the fluid level to the step in the reservoir. Use only a DOT 3 brake fluid designed to meet Ford specifications. Refer to Capacities and specifications. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 223 Washer fluid for the liftgate is supplied by the same reservoir as the windshield. ENGINE COOLANT Checking engine coolant Your engine’s cooling system has been factory-filled with a 50/50 mixture of distilled water and Ford G05 Engine Coolant (yellow in color) per ford specification WSS-M97B51–A1. Maintenance and care symbol.
Page 224 Maintenance and care A 50/50 mixture of distilled water and Ford G05 Engine Coolant provides: maximum cooling system efficiency. freeze protection down to -36° C (-34° F). boiling protection up to 129° C (265° F). protection against rust and other forms of corrosion.
Page 225 Canada, Motorcraft CXC-10) or a premium engine coolant that meets Ford specification ESE-M97B44-A. Use only Ford G05 Engine Coolant WSS—M97B51–A1 (in Canada, Motorcraft CXC-10) or a premium engine coolant that meets Ford specification ESE-M97B44-A. DO NOT USE Ford Extended Life Engine Coolant F6AZ-19544-AA (orange in color).
Page 226 4. When you are sure that all the pressure has been released, use the cloth to turn it counterclockwise and remove the cap. Recycled engine coolant Ford Motor Company recommends the use of a recycled engine coolant produced by Ford-approved processes. Not all coolant recycling processes produce coolant which meets Ford specification ESE-M97B44-A.
Page 227 Always dispose of used automotive fluids in a responsible manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids. Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in the Capacities and specifications chapter. Fill your engine coolant reservoir as outlined in Adding engine coolant in this chapter.
Page 228 Maintenance and care Vehicles driven year-round in non-extreme climates should use a 50/50 mixture of engine coolant and distilled water for optimum cooling system and engine protection. CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules.
Page 229 Maintenance and care 5.0L V8 engine 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C). 2. While the engine idles, turn the steering wheel left and right several times.
Page 230 Maintenance and care pulling a trailer, the vehicle should be turned off for about 30 minutes to allow fluid to cool before checking. 1. Drive the vehicle 30 km (20 miles) or until it reaches normal operating temperature. 2. Park the vehicle on a level surface and engage the parking brake. 3.
Page 231 High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition. Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used.
Page 232 Maintenance and care 2. Park the vehicle on a level surface and engage the parking brake. 3. With the parking brake engaged and your foot on the brake pedal, start the engine and move the gearshift lever through all of the gear ranges.
Page 233 The transmission fluid should be in this range if at ambient temperature (10°C-35°C [50°F-95°F]). High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage.
Page 234 4. Add enough fluid through the filler opening so that the fluid level is at the bottom of the opening. 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to the Capacities and specifications chapter.
Page 235 Use only fluid that meets Ford specifications. Refer to the Capacities and specifications chapter. DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication.
Page 236 Maintenance and care BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the scheduled maintenance guide for the service interval schedules.
Page 237 Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 238 Maintenance and care The vehicle may need to be driven to relearn the idle and fuel trim strategy. If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned.
Page 239 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it.
Page 240 Maintenance and care Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 241 SERVICING YOUR TIRES Checking the tire pressure Use an accurate tire pressure gauge. Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 5 km (3 miles).
Page 242 If you do not follow these precautions, your vehicle may not drive properly and safely. Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design (e.g., “All Terrain”, etc.), as originally offered by Ford.
Page 243 The tires on your vehicle have all-weather treads to provide traction in rain and snow. However, in some climates, using snow tires and traction devices may be necessary. Ford offers tire cables as a Ford approved accessory and recommends use of these or their equivalents. See your dealer or qualified service technician for more information on tire cables for your vehicle.
Page 244 Maintenance and care WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 245 Avoid inhaling fuel vapors. Inhaling too much fuel vapor of any kind can lead to eye and respiratory tract irritation. In severe cases, excessive or prolonged breathing of fuel vapor can cause serious illness and permanent injury. Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention.
Page 246 Maintenance and care Choosing the right fuel Use only UNLEADED FUEL. The use of leaded fuel is prohibited by law and could damage your vehicle. Do not use fuel containing methanol. It can damage critical fuel system components. Your vehicle was not designed to use fuel or fuel additives with metallic compounds, including manganese-based compounds containing MMT.
Page 247 World-wide Fuel Charter. In Canada, look for fuels that display the Auto Makers’ Choice Cleaner air Ford approves the use of reformulated “cleaner-burning” gasolines to improve air quality. These gasolines may contain oxygenates up to 10% ethanol or 15% MTBE.
Page 248 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 249 Filling the tank The advertised fuel capacity of the fuel tank on your vehicle is equal to the rated refill capacity of the fuel tank as listed in the Refill Capacities section of the Capacities and specifications chapter. The advertised capacity is the amount of the indicated capacity and the empty reserve combined.
Page 250 Maintenance and care 5. Follow one of the simple calculations in order to determine fuel economy: Multiply liters used by 100, then divide by total kilometers traveled. Divide total miles traveled by total gallons used. Keep a record for at least one month and record the type of driving (city or highway).
Page 251 Maintenance Keep tires properly inflated and use only recommended size. Operating a vehicle with the wheels out of alignment will reduce fuel economy. Use recommended engine oil. Refer to Lubricant Specifications. Perform all regularly scheduled maintenance items. Follow the recommended maintenance schedule and owner maintenance checks found in your vehicle scheduled maintenance guide.
Page 252 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 253 Please consult your “Warranty Guide” for complete emission warranty information. Readiness for Inspection/Maintenance (I/M) testing In some localities, it may be a legal requirement to pass an I/M test of the on-board diagnostics system. If your “Check Engine/Service Engine Soon” light is on, refer to the description in the Warning Lights and Chimes section of the Instrumentation chapter.
Page 254 Maintenance and care Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in OFF position, then lift hood and open the hinged headlamp cover. 2. Disconnect the electrical connector from the bulb by pulling rearward. 3.
Page 255 Maintenance and care If the bulb is accidentally touched, it should be cleaned with rubbing alcohol before being used. 1. With the flat side of the new bulb’s plastic base facing upward, insert the glass end of the bulb into the lamp assembly. You may need to turn the bulb left or right to align the grooves in the plastic base with the tabs in the lamp assembly.
Page 256 Maintenance and care Replacing tail lamp/turn/backup lamp bulbs The tail lamp/turn/backup lamp bulbs are located in the tail lamp assembly, one just below the other. Follow the same steps to replace either bulb: 1. Open the liftgate to expose the lamp assemblies.
Page 257 Maintenance and care Replacing license plate lamp bulbs 1. Remove two screws and the license plate lamp assembly from the liftgate. 2. Pull the bulb out from lamp assembly and push in the new bulb. 3. Install the lamp assembly on liftgate with two screws.
Page 258 Maintenance and care 4. Pull the bulb straight out of the socket and push in the new bulb. To complete installation, follow the removal procedure in reverse order. USING THE RIGHT BULBS Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.”...
Page 259 If your vehicle has been in an accident the alignment of your headlamps should be checked by a qualified service technician. CLEANING AND CARING FOR YOUR VEHICLE Refer to the Customer Assistance chapter for a list of Ford-approved cleaners, polishes and waxes. Washing your vehicle Wash your vehicle regularly with cold or lukewarm water.
Page 260 Ultra Touch Prep and Finishing Kit (#F7AZ-19K507–BA), Lacquer Touch-up Paint (#ALBZ-19500–XXXXA), or Exterior Acrylic Spray Lacquer (#ALAZ-19500–XXXXA) from the Ford Car Care Chemicals line. Please note that the part numbers (shown as XXXX above) will vary with your vehicle’s specific coloring. Observe the application instructions on the products.
Page 261 Maintenance and care 5.0L 4.0L SOHC...
Page 262 Maintenance and care 4.0L OHV Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. Cleaning the wheels Wash with the same detergent as the body of your vehicle. Do not use acid-based or alcohol-based wheel cleaners, steel wool, fuel or strong detergents.
Page 263 Cleaning the exterior lamps Wash with the same detergent as the exterior of your vehicle. If necessary, use a tar remover such as Ford Extra Strength Tar and Road Oil Remover (B7A-19520–AA). To avoid scratching the lamps, do not use a dry paper towel, chemical solvents or abrasive cleaners.
Page 264 For tougher soiling concerns, Ford recommends using the Deluxe Leather Care Kit F8AZ-19G253–AA, which is available from your Ford Dealer. This mild cleaner and special pad, cleans the leather and maintains its natural beauty. Follow the instructions on the cleaner label.
Page 265 Maintenance and care Do not use household cleaning products, alcohol solutions, solvents or cleaners intended for rubber, vinyl or plastics. Woodtone trim Wipe stains with a soft cloth and a multi-purpose cleaning solution. Inside windows Use Ultra-Clear Spray Glass Cleaner (E4AZ-19C507–AA) for the inside windows if they become fogged.
Page 266: Capacities And Specifications
** If a spark plug is removed for inspection, it must be reinstalled in the same cylinder. If a spark plug needs to be replaced, use only spark plugs with the service number suffix letter as shown on the engine decal. REFILL CAPACITIES Fluid Ford Part Name Brake fluid High Performance...
Page 267 Fluid Ford Part Name Transmission Motorcraft fluid MERCON ATF Motorcraft MERCON V Transfer case Motorcraft MERCON ATF Engine coolant Premium Engine Coolant Capacities and specifications Application 5-speed manual 4R70W Automatic with 5.0L V8 engine 5R55E Automatic with 4.0L OHV V6...
Page 268 Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in the Maintenance and Care chapter.
Page 269 The axle lubricant should be changed any time the axle has been submerged in water. Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118–A for complete refill of Traction-Lok axles. LUBRICANT SPECIFICATIONS...
Page 270 Capacities and specifications Ford Part Item Name or equivalent Engine coolant Ford Premium Engine Coolant Motorcraft SAE 5W-20 Super Premium Motor Engine oil MotorcraftSAE 5W-30 Super Premium Motor Motorcraft Automatic MERCON V transmission Power steering Motorcraft fluid MERCON ATF Ford...
Page 271 Washer Concentrate DO NOT USE Ford Extended Life Engine Coolant F6AZ-19544-AA, meeting Ford specification WSS-M97B44-D (orange in color) Refer to Adding engine coolant, in the Maintenance and Care chapter. Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.
Page 272 Capacities and specifications ENGINE DATA 4.0L OHV V6 Engine engine Cubic inches Required fuel 87 octane Firing order 1-4-2-5-3-6 Spark plug gap 1.3-1.4 mm (0.052-0.056 inch) Ignition system EDIS Compression 9.0:1 ratio VEHICLE DIMENSIONS Dimensions (1) Overall length (2) Overall width (3) Maximum height (4) Wheelbase...
Page 273 Capacities and specifications * Height includes roof rack...
Page 274: Certification Label
The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block, transmission, frame and transfer case (if equipped). MFD. BY FORD MOTOR CO. IN U.S.A. DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG FGAWR: XXXXXX/XXXXXXX...
Page 275: Customer Assistance
United States and Canada, provided by a network of more than 5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Please contact your dealer for further information.
Page 276 Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Assistance Center to find an authorized dealership to help you.
Page 277 Ford Motor Company of Canada, Limited P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Assistance Center: Your telephone number (home and business)
Page 278 Ford Motor Company vehicles The Dispute Settlement Board may not be available in all states. Ford Motor Company reserves the right to change eligibility limitations, modify procedures and/or to discontinue this service without notice and without incurring obligations per applicable state law.
Page 279 Ford Motor Company the names (if known) of all the people you contacted at the...
Page 280 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 281 UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 282 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 283 * May be sold with the Motorcraft name FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Ford accessories are available for your vehicle through your local authorized Ford, Lincoln Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs;...
Page 284 Customer assistance Travel equipment Automatic headlamps with daytime running lights (DRL) Daytime running lights (DRL) Factory luggage rack adaptors Fog lights Framed luggage covers Heavy-duty battery Home link visor Inside mirror, electrochromic compass (with and without temperature display) Luggage/cargo basket Neutral towing transfer case kit (Explorer 4.0L only) Removable luggage rack Removable luggage rack adapters...
Page 285 (Citizens band [CB] transceivers, garage door openers and other transmitters with outputs of five watts or less will not ordinarily affect your vehicle’s operation.) Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment. Customer assistance...
Page 286 Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3.
Page 287: Reporting Safety Defects
However, NHTSA cannot become involved in individual problems between you, your dealer or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (202–366–0123 in the Washington D.C.
Page 288: Index
Index Air bag supplemental restraint system ...135–136, 140 and child safety seats ...137 description ...136, 140 disposal ...143 driver air bag ...138, 141 indicator light ...10, 139, 142 operation ...138, 141 passenger air bag ...138, 141 side air bag ...140 Air cleaner filter ...266 Air conditioning ...22 automatic temperature...
Page 289 ...269, 272 Cruise control (see Speed control) ...82 Customer Assistance ...189 Ford accessories for your vehicle ...282 Ford Extended Service Plan ...275 Getting assistance outside the U.S. and Canada ...281 Getting roadside assistance ...189 Getting the service you need ...275 Ordering additional owner’s...
Page 290 Index Driving under special conditions ...172, 175 mud ...171–172, 174 sand ...172, 174 snow and ice ...171, 173–174, 176 through water ...172, 174, 179 Emergencies, roadside jump-starting ...204 Emission control system ...252 Engine ...272 check engine/service engine soon light ...8 cleaning ...260 coolant ...223 idle speed control ...236...
Page 291 odometer ...15 speedometer ...14 tachometer ...15 trip odometer ...15 GAWR (Gross Axle Weight Rating) ...176 calculating ...178 definition ...176 driving with a heavy load ...176 location ...176 GVWR (Gross Vehicle Weight Rating) ...176 calculating ...176, 178 definition ...176 driving with a heavy load ...176 location ...176 Hazard flashers ...190 Head restraints ...119, 123...
Page 292 Index fog lamps ...21 headlamps ...21 headlamps, flash to pass ...22 instrument panel, dimming ...22 replacing bulbs ...253–257 Lane change indicator (see Turn signal) ...81 Liftgate ...105 Lights, warning and indicator ...8 air bag ...10 anti-lock brakes (ABS) ...10, 156 anti-theft ...11 brake ...10 charging system ...11...
Page 293 Preparing to drive your vehicle ...158 Radio ...35 Relays ...191 Remote entry system ...107–108 illuminated entry ...112 locking/unlocking doors ...108 panic alarm ...108 replacement/additional transmitters ...111 replacing the batteries ...110 Reverse sensing system ...33 Roof rack ...188 Safety belts (see Safety restraints) ...13, 125–130 Safety defects, reporting ...287 Safety restraints ...125–130...
Page 294 Index Transmission ...159 fluid, checking and adding (automatic) ...229, 231 fluid, checking and adding (manual) ...234 fluid, refill capacities ...266 lubricant specifications ..269, 272 manual operation ...166 Trip odometer ...15 Turn signal ...11, 81 Vehicle dimensions ...272 Vehicle Identification Number (VIN) ...274 Vehicle loading ...176 Ventilating your vehicle ...154...
Page 295: Filling Station Information
Unleaded fuel only - 87 octane 66.2L (17.5 gallons) 75.5L (22.5 gallons) 4.7L (5.0 quarts). Use Motorcraft SAE 5W-30 Super Premium Motor Oil, Ford specification WSS-M2C153-G. 4.7L (5.0 quarts). Use Motorcraft SAE 5W-20 Super Premium Motor Oil, Ford specification WSS-M2C153-G.
Page 296 Filling station information Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in the Maintenance and Care chapter. Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.

This manual is also suitable for:

Explorer 2000Explorer sport 2000

Ford 2000 Explorer Owner's Manual

Quick Links

Related Manuals for Ford 2000 Explorer

Summary of Contents for Ford 2000 Explorer

This manual is also suitable for:

Table of Contents
