DEFINITY Communications System
DEFINITY High Speed Link
User´s Guide
Appendix D: Applications and Switch Administration

Access Endpoint Administration

To create a permanent connection between a Generic 3 HSL and
the DSU, an access endpoint must be established. The access
endpoint is a single member DS0 trunk group from the Generic 3
that the switch creates internally and is used to access ASDS and
connect to the DSU. As a result, a trunk group does not need to be
created when administering a DS0 access endpoint, but the DS0
access endpoint cannot be included in another trunk group.
Once the connection is established, the signaling for that DS0 is
disabled which makes the switch transparent to any information
sent from the ASDS network or the DSU. This allows the HSL to
respond to all ASDS and DSU control commands without causing
the switch to drop the call.
To administer the access endpoint, the Access Endpoint form
should be used and populated in the following manner:
Extension - 4000. To create an AC with an access endpoint, the
switch uses this extension. This extension should be
compatible with the existing numbering plan.
Port - This field should be entered with the DS0 port on the
DS1 circuit pack that will be connected through ASDS to the
DSU.
Communication Type - 56K-data. To indicate 56 Kbps data.
The access endpoint has now been administered and can be used
in
an AC.
Administered Connection Administration
The administration of an AC defines the two endpoints of the
connection. In this example two ACs are required.
In the PBX to PBX AC, the HSL extension (5000) on the Generic 3
is the originator and extension 3000 on the Generic 2 is the
destination. To administer this, the Administered Connection
form (Screen D-15) must be populated as follows:
Connection Number - 1. This defines which AC is being
administered.
Originator - 5000. This is the originating extension on the
Generic 3.
Destination - 110,3000. This is the destination on the Generic
2. 110 is the TAC as defined in the trunk group form on the
Generic 3, the comma inserts a delay, and 3000 is the
destination extension on the Generic 2.
The other fields in the Administered Connection form can be
populated with information regarding scheduling and
Page D-37
