Appendix D: Applications and Switch Administration
Page D-36
this, the Trunk Group form (Screen D-14) is used and the entries
for a static trunk group are similar to that described in Trunk
Group Administration section for the Generic 1 in the switched
videoconferencing example with the following exceptions:
Comm Type: data. This indicates that only data is being
transmitted. Since ASDS is being used, any echo cancelers or
suppressors should be disabled in the trunk group. This is
accomplished by making the path "data ready."
TAC: 110. To directly access the trunk group over which the
permanent connection will be established, a Trunk Access
Code (TAC) will be used. This is done by prefixing the TAC
(110) onto the number of the destination. If a TAC is not used
then the trunk must be accessed through the switch's routing
software such as ARS. A benefit of using switch routing,
however, is that it could be used to choose an alternate
(switched) facility if the link through ASDS fails. For
simplicity the TAC will be used in this example.
Note that the Bit Rate, Synchronization, and Duplex fields at the
bottom of this form refer to modem pool applications and will not
affect this application.
Group Number: 10
Group Name: ASDS FEP
Direction: two-way Outgoing Display?
Dial Access: y
Queue Length: 0
Comm Type: data
TRUNK PARAMETERS
Trunk Type (in/out): wink/wink
Outgoing Dial Type: tone
Digit Treatment: ________
Connected to Toll: y
Incoming Dial Tone: y
Bit Rate:
Answer Supervision Timeout?
Generic 3 Trunk Group Administration
DEFINITY
DEFINITY High Speed Link
Page 1 of 9
Trunk Group
Group Type: tie SMDR Reports?
COR: 1
n
Busy Threshold: 99 Night Service:
Incoming Destination:
Auth Code? n
Incoming Rotary Timeout (sec):
Incoming Dial Type:
Disconnect Timing (msec):
STT Loss: normal DTT to DCO Loss:
Synchronization:
10
SCREEN D-14
Communications System
User´s Guide
Y
TAC: 110
___
__
BCC: 1
5
tone
500
Digits: ____
normal
Duplex:
