  • Page 1 DEFINITY and System 85 Wiring 555-104-630 Issue 2 June 1991 Communications SystemGeneric 2...
  • Page 2 Copyright ©1991 AT&T All Rights Reserved Printed in U.S.A. Notice While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of printing, AT&T can assume no responsibility for any errors. Changes and corrections to the information contained in this document may be incorporated into future reissues.

  • Page 3: Table Of Contents

    ABOUT THIS DOCUMENT INTENDED AUDIENCES PREREQUISITE SKILLS AND KNOWLEDGE ORGANIZATION OF THIS GUIDE HOW TO USE THIS DOCUMENT TRADEMARKS AND SERVICE MARKS RELATED RESOURCES HOW TO MAKE COMMENTS ABOUT THIS DOCUMENT 1. OVERVIEW: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES MAJOR COMPONENTS FOR SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES SYSTEM ADJUCTS...
  • Page 4 CONTENTS 3. ELECTRICAL PROTECTION: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES TYPES OF ELECIRICAL HAZARDS PROTECTING AGAINST HAZARD EXPOSURE PROTECTING THE SWITCH PROTECTING OTHER EQUIPMENT PRIMARY PROTECTION ENHANCED PRIMARY PROTECTION SECONDARY PROTECTION RECOMMENDED PROTECTORS PROTECTION MATRIX 4. PORT PACKS/DCP REPEATERS: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES PORT CIRCUIT PACKS DCP REPEATERS...
  • Page 5 7. MDF/IDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES RECOMMENDED TERMINAL BLOCKS RECOMMENDED FRAMES FOR TERMINAL BLOCKS DESIGNING THE MDF DESIGNING THE MDF FOR A RAISED FLOOR RECOMMENDATIONS FOR IDF DESIGNS INSERT LABELS 8. ELECTRICAL PROTECTION: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES RECOMMENDED PROTECTORS PROTECTION MATRIX 9.
  • Page 6 CONTENTS 13. FIBER OPTICS LCTT CONNECTORS PADDLEBOARD RANGE LIMITATIONS 14. INSERT LABELS GLOSSARY INDEX 13-1 13-1 13-1 13-1 14-1 GL-1 IN-1...
  • Page 7 Figure 1-1. System 85 and DEFINITY Generic 2 with Traditional Module Connectivity Figure 2-1. Maximum Column 1500 Pairs (Five 300-Pair Terminal Blocks) Figure 2-2. Jumper Placement Figure 2-3. Six Type-1 Frames with 18,000-Pair Capacity Figure 2-4. Seven Type-2 Frames with 16,800-Pair Capacity Figure 2-5.

  • Page 8: Contents

    viii CONTENTS Figure 7-5. Overall Equipment Wiring Plan: DEFINITY Generic 2 with Universal Modules Figure 7-6. CPC Wall Field Configuration Figure 7-7. Four-Area MDF Figure 7-8. Combined Trunk and Line Ports Figure 7-9. Separated Trunk and Line Ports Figure 7-10. Zone Arrangement of Type-1 Frame —...
  • Page 9 Figure 14-12. Insert Labels - Partial Reproductions Figure 14-13. Insert Labels - Partial Reproductions Figure 14-14. Insert Labels - Partial Reproductions CONTENTS 14-16 14-17 14-18...
  • Page 10 CONTENTS TABLE 2-1. 300-Pair Terminal Blocks TABLE 2-2. 100-Pair Terminal Blocks Type-1 Frame Ordering Information TABLE 2-3. TABLE 2-4. Mounting Methods TABLE 2-5. Module Allocation per Zone with Type-1 Frame TABLE 2-6. Module Allocation per Zone with Type-2 Frame TABLE 3-1. Loop Ranges for Protected Hybrid Terminals Loop Ranges for Protected Digital Terminals TABLE 3-2.

  • Page 11: Intended Audiences

    This document follows as closely as possible the guidelines of the AT&T premises distribution system (PDS) as presented in the Premises Distribtion Systems Phase 1. While the PDS covers all distribution media (copper and fiber), this document is concerned primarily with the simplified design of the main distribution frame (MDF) for AT&T System 85 and DEFINITY®...

  • Page 12: Prerequisite Skills And Knowledge

    ABOUT THIS DOCUMENT PREREQUISITE SKILLS AND KNOWLEDGE This document assumes that you are familiar with the PDS installation guidelines and hardware. If you are not, read the Premises Distribution System Design Guide (555-400-602) before you read this document.

  • Page 13: Installation Example: System 85 And Definity Generic 2 With Traditional Modules

    ORGANIZATION OF THIS GUIDE This document consists of the following chapters and appendixes: Chapter 1, Overview: System 8.5 and DEFINITY Generic 2 with Traditional Modules — A brief description of the System 85 and DEFINITY Generic 2 traditional modules’ principal components, including remote module interfaces (RMIs) and remote group interfaces (RGIs), and their operation Chapter 2, MDF/IDF Design: System 85 and DEFINlTY Generic 2 with Traditional Modules —...

  • Page 14: How To Use This Document

    ABOUT THIS DOCUMENT HOW TO USE THIS DOCUMENT Chapters 1 through 5 apply to System 85 and DEFINITY Generic 2 with traditional modules. Chapters 6 through 11 apply to DEFINITY Generic 2 with universal modules. Chapters 12 through 14 apply to adjunct power supplies, fiber-optics, and insert labels;...
  • Page 15 Telecommunication Electrical Protection (350-060). Information and training material for engineers responsible for the electrical protection of personnel and users of telecommunication networks, systems, and equipment from lightning and power surges, power-line contacts, induction, and ground potential rise. AT&T System 75 Wiring (555-200-111). A document for planning, designing, and installing a System 75 wiring installation using Z-100, 110, or 66 cross-connect systems.

  • Page 16: How To Make Comments About This Document

    ABOUT THIS D0CUMENT HOW TO MAKE COMMENTS ABOUT THIS DOCUMENT Reader comment cards are in the back of this document. While we have tried to make this document fit your needs, we are interested in your suggestions for improving it and urge you to fill one out. If the reader comment cards have been removed from this document please send your comments to: AT&T Technical Publications Department...
  • Page 17 1. OVERVIEW: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES AT&T System 85 and DEFINITY® Generic 2 Communications System (hereafter abbreviated to DEFINITY Generic 2 or Generic 2) with traditional modules are communications systems with multimodule architecture that provide integrated voice and data switching via a state-of-the-art communications processor (called the common control or CC), a time-multiplexed switch (TMS), and the communications modules.
  • Page 18 OVERVIEW: SYSTEM 85 AND DEFINlTY GENERIC 2 WITH TRADITIONAL MODULES The MC, or communications switching module, is the basic building block of the multimodular architecture. Each MC is capable of supporting up to 1536 analog ports and 256 simultaneous full- duplex conversations.

  • Page 19: Overview: System 85 And Definity Generic 2 With Traditional Modules

    OVERVIEW: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES The TMS is a time-multiplexed, space-division switch that connects modules for communications in a time-slot information between the modules and the TMS. The TMS processor, on command from the 501CC processor, directs the interconnections between the modules and the TMS. SYSTEM ADJUNCTS The installation of most System 85 and DEFINITY Generic 2 traditional modules is accompanied by one or more system adjuncts that provide the customer with administrative or application functions that...

  • Page 20: Cross-Connect Fields

    OVERVIEW: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES CROSS-CONNECT FIELDS Cross-connect fields are a major component in the installation of a System 85 or DEFINITY Generic 2 with a traditional module. They are the termination points for equipment cabling and distribution cabling.
  • Page 21 OVERVIEW: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES made from the network interface to the green field of the MDF. A cross-connection is made from the green field to the trunk section of the purple field. From the purple field, the path travels along a 25-pair cable to the backplane of a trunk port circuit at the switch.

  • Page 22: Figure 1-1. System 85 And Definity Generic 2 With Traditional Module Connectivity

    OVERVIEW: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Figure 1-1. System 85 and DEFINITY Generic 2 with Traditional Module Connectivity...

  • Page 23: With Traditional Modules

    OVERVIEW: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES GENERIC 2 WITH TRADITIONAL MODULE For purposes of this document System 85 and DEFINITY Generic 2 with traditional modules are treated the same for connectivity and sizing MDFs and IDFs. They are discussed concurrently in the first five chapters of this document.

  • Page 24: Mdf/Idf Design: System 85 And Definity Generic

    2. MDF/IDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 This chapter recommends the terminal blocks and frames best suited for constructing a main distribution frame (MDF) for AT&T System 85 and DEEFINITY Generic 2 (hereafter abbreviated to DEFINITY Generic 2 or Generic 2) with traditional modules, presents the guidelines for their design, presents some guidelines for the intermediate distribution frame (IDF) design, and briefly discusses labeling for the MDFs and IDFs.

  • Page 25: Table 2-1. 300-Pair Terminal Blocks

    MDF/lDF DESIGN: SYSTEM 85 AND DEFlNITY GENERlC 2 WITH TRADITIONAL MODULES Product Code 110AB1-300FT* 110AB1-300CT** 110AB1-300CTM† 110AB1-300CB‡ 110AB1-3OOCBM§ NOTE: codes are as follows: Field terminated ** Connectorized w/female connector † Connectorized w/male ‡ Connectorized bottom w/female connector § Connectorized bottom w/male Table 2-2, 100-Pair Terminal Blocks, gives the ordering information for the 100-pair terminal blocks: Product Code ll0AB1-l00FT*...

  • Page 26: Figure 2-1. Maximum Column 1500 Pairs (Five 300-Pair Terminal Blocks)

    DF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Height Requirement for Terminal-Block Columns When you lay out the columns of terminal blocks for the MDF, place no more than 1500 pairs (five 300-pair blocks in a column) for either frame- or wall-mounted installations. (See figure 2-1, Maximum Column 1500 Pairs (Five 300-Pair Terminal BIocks).) Higher columns are hard to reach and make connecting and disconnecting jumper wires difficult.

  • Page 27: Designing The Mdf

    MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Connecting Jumper Wires To facilitate cross-connections, connect jumper wires as follows: Use the layout and instructions shown in figure 2-2, Jumper Placement, for the 110A terminal blocks. (Figure 2-2 illustrates a layout for frame mounting, but the layout applies to wall mounting as well.) Use only the number of jumpers required for a connection.

  • Page 28: Recommended Frames For Terminal Blocks

    MDF/IDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES RECOMMENDED FRAMES FOR TERMINAL BLOCKS The extra large building entrance terminal (XLBET) frame, which is manufactured at the AT&T Los Angeles Service Center, can be used for the MDF. The frame comes in single- and double-sided versions that are 84 in.

  • Page 29: Figure 2-3. Six Type-1 Frames With 18,000-Pair Capacity

    MDF/IDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES LEGEND: G— GREEN, NETWORK FIELD Y — YELLOW, AUXILIARY Y AND MISCELLANEOUS FIELD W — WHITE. DISTRIBUTION FIELD P — PURPLE EQUIPMENT FIELD +— SPARE WITHOUT CROSS-CONNECT BLOCKS Figure 2-3. Six Type-1 Frames with 18,000-Pair Capacity Type-2 Frame The type-2 frame shown in figure 2-4, Seven Type-2 Frames with 16,800-Pair Capacity, is a special frame with added jumper capacity.

  • Page 30: Figure 2-4. Seven Type-2 Frames With 16,800-Pair Capacity

    MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES LEGEND: G — GREEN, NETWORK FIELD Y — YELLOW, AUXILIARY AND MISCELLANEOUS FIELD W — WHITE, DISTRIBUTION FIELD P — PURPLE EQUIPMENT FIELD S — SPARE WITH CROSS-CONNECT BLOCKS Figure 2-4.

  • Page 31: Table 2-3. Type-1 Frame Ordering Information

    MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Ordering The service center ships all frames with terminal blocks as one comcode. Frames ordered for 110A hardware come with 110AB1-300 terminal blocks, clear designation strips, and wireways installed. However, you must specify the 110C-4 connecting block, which is recommended for a System 85 or DEFINITY Generic 2 traditional system installation.

  • Page 32: Designing The Mdf For A Raised Floor

    MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES DESIGNING THE MDF Designing the MDF is a two-step process: first, determine the size of the MDF, second, construct the MDF. As you proceed with the design, keep in mind that function is more important than cost in reaching a final decision since it is possible for the final installation to be inexpensive but nonfunctional.

  • Page 33: Figure 2-5. Overall Equipment Wiring Plan

    2-10 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES COMMUNICATIONS Figure 2-5. Overall Equipment Wiring Plan...
  • Page 34 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Two factors govern the size of the MDF: the number of cable pairs to be terminated and the type of cross-connect hardware used. Since the recommended cross-connect hardware for System 85 and DEFINITY Generic 2 traditional system is the 110A, you only need to calculate the number of cable pairs that must terminate on the MDF and calculate the number of 110A cross-connect blocks needed to terminate those pairs to arrive at the size of the MDF.
  • Page 35 2-12 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES beyond these minimums as actual needs dictate. Equipment (Switch) Port Field The equipment port field, which uses purple labels, is where the cables from the equipment ports terminate. Two factors govern its size. The first is the type, usage, and number of port carriers; the second is module needs, since all ports from an equipment module must be colocated.
  • Page 36 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES NOTE: When a blue field is used, the blue field cross-connects directly to the purple field and not to the white field. Terminate only six 4-pair DIW cables to each index strip of a 110AB1-300 wiring block (the 25th pair is unused), which means that you can terminate a maximum of 72 four-pair DIW cables on each 300- pair wiring block.

  • Page 37: Table 2-4. Mounting Methods

    2-14 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES No. of Modules 1 - 5 6 - 1 0 10 & up Frame mounting of the terminal blocks for installations of all module sizes is desirable, but those of 10 modules or more must be frame mounted.
  • Page 38 MDF/IDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Add two more fields to the arrangement when 4-pair installation cables, spare cables, or cables dedicated PBXs other than System 85 or DEFINITY Generic 2 with traditional modules are terminated on the MDF.
  • Page 39 2-16 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Figure 2-7. Combined Trunk and Line Ports...
  • Page 40 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES LEGEND: G — GREEN. NETWORK FIELD Y — YELLOW, AUXILIARY AND MISCELLANEOUS FIELD W — WHITE, DISTIBUTION FIELD PT — PURPLE TRUNK FIELD PL — PURPLE LINE FIELD + — SPARE WITHOUT TERMINAL BLOCKS S —...

  • Page 41: Figure 2-10. Zone Arrangement Of Type-1 Frame — Front View, Zone 2

    MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES 2-18 Divide the terminations of the distribution cables among the zones in 100-pair increments. The type-1 frame (described under Recommended Frames for Terminal Blocks earlier in this chapter) may be used for a zoned MDF that is terminating up to 10 modules. Table 2-5, Module Allocation per Zone with Type-1 Frame, shows the number of modules allocated per zone when you design an MDF with a type-1 frame.
  • Page 42 2-19 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Figure 2-9. Zone Arrangement of Type-1 Frame — Plan View Figure 2-10. Zone Arrangement of Type-1 Frame — Front View, Zone 2...

  • Page 43: Figure 2-12. Zone Arrangement Of Type-2 Frame — Front View, Zone 2

    2-20 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Use the type-2 frame (described under Recommended Frames for Terminal Blocks earlier in this chapter) to design a zoned MDF that is terminating up to 16 modules. Table 2-6, Module Allocation per Zone with Type-2 Frame, shows the number of modules allocated per zone when you design an MDF with a type-2 frame.
  • Page 44 2-21 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Figure 2-11. Zone Arrangement of Type-2 Frame — Plan View LEGEND: — YELLOW, AUXILIARY MISCELLANEOUS FIELD W — WHITE, DISTRIBUTION FIELD P — PURPLE EQUIPMENT FIELD S — SPARE WITH CROSS-CONNECT BLOCKS Figure 2-12.
  • Page 45 2-22 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES In addition to the preceding guidelines, observe these rules when designing zones: Mount the hardware on frames. For one-zone installations, wall-mounted frames may be used. For two-zone installations, double-sided, self-supporting frames must be used. Divide the distribution cables (in 100-pair increments) as equally between zones as possible.
  • Page 46 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES NOTE: If station #2700 is located in module 04, the cross-connection in the closet goes to a pair in zone 1. Similarly, if #3001 is in module 07, the cross-connection in the closet goes to a pair in zone 2. Using this rule, it is possible to keep the jumpers short at the equipment room cross-connect field.

  • Page 47: Designing The Mdf For A Raised Floor

    2-24 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Use cross-connect hardware with connectors for equipment cables for systems of 1 to 5 modules. NOTE: The connector gender of the shielded cables supplied with System 85 R2V4 and earlier systems is male-to-male (M-M).
  • Page 48 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES The use of raised floor space as an air plenum. The National Electric Code (NEC) prohibits the placement of cables that use ordinary covering materials, such as polyvinyl chloride (PVC) or polyethylene, in the building air plenums.
  • Page 49 2-26 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES 18” Figure 2-14. Floor Template - 18 Inch Tile (L472366)
  • Page 50 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES 2-27 › ‹ 24" ˆ 2" 24" Figure 2-15. Floor Template - 24 Inch Tile (L472367)
  • Page 51 2-28 MDF/lDF DESIGN: SYSTEM 85 AND DEFINlTY GENERIC 2 WITH TRADITIONAL MODULES Figure 2-16. Floor Template - Cabinet Lineup (L472368)
  • Page 52 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Cable Routing Take special care to ensure that cables from different modules do not cross at the MDF and that distribution cables are not crossed over module cables. Make sure that the cables routed under the raised floor are dressed and that they are done so with a minimum of slack to prevent tangled cables that can obstruct access to other under-floor equipment.
  • Page 53 2-30 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES NOTE: Connector brackets can be placed on the floor for easy connecting. Figure 2-17. Floor-Secured Frame Installation...

  • Page 54: Recommendation For Idf Designs

    MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES RECOMMENDATIONS FOR IDF DESIGNS For System 85 and DEFINITY Generic 2 with traditional modules, IDFs serve as secondary cross- connect points between distribution cables and installation cables, which connect to the IOs. The IDFs usually are housed in closets.

  • Page 55: Insert Labels

    2-32 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES INSERT LABELS Insert labels identify the origins of cables that terminate on the MDF and on the IDFs. The labels are color-coded and come in sheets with 18 labels per sheet. The labels slip into the 1/2 in. by 8 in. clear plastic holders that snap between the horizontal index strips of the terminal blocks.
  • Page 56 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Figure 2-18. Example of Label Filled In The label sheets are stocked at the AT&T Customer Information Center and can be obtained by calling (800) 432-6600 or by writing to: AT&T Customer Information Center P.0.
  • Page 57 2-34 MDF/IDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES...

  • Page 58: Electrical Protection: System 85 And Definity Generic

    3. ELECTRICAL PROTECTION: SYSTEM 85 AND DEFINITY GENERIC 2 This chapter identifies the electrical hazards that can harm personnel, the switch, terminals, and building wiring; instructs you in how to evaluate the basic wiring design for real or potential electrical hazards; and describes the protective devices and methods used to minimize those hazards.

  • Page 59: Protecting The Switch

    ELECTRICAL PROTECTION: SYSTEM 85 AND DEFINITY GENERlC 2 WITH TRADITIONAL MODULES For more details on electrical protection, see Telecommunication Electrical Protection (350-060). Riser Cable Although riser cable (the distribution cable that stays within a building) rarely receives direct lightning strikes, instances of risers subjected to residual voltages as high as 5000V from lightning strikes on the buildings housing them have been observed.

  • Page 60: Figure 3-1. Placement Of Electrical Protectors On Co Side Of Switch

    ELECTRICAL PROTECTION: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES primary protector operates at a lower threshold. A secondary protector protects against currents and, in some cases, residual voltages that get past the primary protector. When analog circuit packs, analog voice terminals, and the distribution cables and cross-connect fields serving them are exposed to lightning, power crosses, and/or ground-potential rise, they require only overvoltage protection because they already have built-in, sneak-current protection in the circuit packs and terminals.

  • Page 61: Primary Protection

    ELECTRICAL PROTECTION: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES PRIMARY PROTECTION Primary protection is provided by a fusible link and an overvoltage device. The following are descriptions of these elements of primary protectors. Overvoltage Devices There are three types of overvoltage devices: carbon blocks, gas tubes, and solid-state devices. Carbon Blocks A carbon block is a device holding two or more small carbon electrodes gapped at a distance that allows a voltage power surge to arc across the gap to ground.

  • Page 62: Enhanced Primary Protection

    ELECTRICAL PROTECTION: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Sneak-Current Device: Fuse A sneak-current fuse is a fuse that melts when currents of .35A (for 4 hours) to 5.25A (for more than 10 seconds) reach it. Sneak-current fuses may be installed before or after the network interface (NI) in series with the primary protector.
  • Page 63 ELECTRICAL PROTECTION: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Enhanced Primary Protectors The following are enhanced primary protector units supplied by AT&T, Illinois Tool Works (ITW), and Porta Systems: AT&T 4C3S-75 (comcode 105581086; PEC 65543 and 65543A) — a semiconductor device and heat-coil protector unit that offers precise clamping, superior balanced performance, fail safe operation and no deterioration with age or number of operations.

  • Page 64: Protection Matrix

    ELECTRICAL PROTECTION: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES — SN270B (digital) circuit packs — 7400 series (digital) terminals Digital terminals protected by PDPs do not require local power if the terminals have no adjuncts attached. The terminals do require local power if adjuncts are attached. NOTE: Do not use the PDP with analog ports and terminals.

  • Page 65: Table 3-1. Loop Ranges For Protected Hybrid Terminals

    ELECTRICAL PROTECTION: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES TABLE 3-1. Loop Ranges for Protected Hybrid Terminals Terminal 7203 7205 *This is the recommended module protector. TABLE 3-2. Loop Ranges for Protected Digital Terminals Terminal Digital Set *This is the recommended module protector. Range Ft (M) Adjuncts Protector...

  • Page 66: Table 3-3. System 85 And Definity Generic 2 With Traditional Modules Protection Matrix

    ELECTRICAL PROTECTION: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES TABLE 3-3. System 85 and DEFINITY Generic 2 with Traditional Modules Protection Matrix Exposed AT&T Circuit Circuits/ System 85/ Packs/ On-Off Line G2 Traditional Circuit Premises ANN11/1 Yes/Both NOTES: The ANN11, 15, 16, and 35 all require channel service units (CSU) as the network interface (NI).
  • Page 67 3-10 ELECTRICAL PROTECTION: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES...

  • Page 68: Port Packs/Dcp Repeaters: System 85 And Definity Generic

    4. PORT PACKS/DCP REPEATERS: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES This chapter presents supplementary information on port circuit packs, loop distances for terminals, and digital communications protocol (DCP) repeaters that you may find useful in designing a wiring installation for System 85 and DEFINITY Generic 2 Communications Systems (hereafter abbreviated to DEFINITY Generic 2 or Generic 2) with traditional modules.
  • Page 69 PORT PACKS/DCP REPEATERS: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Pack Port Fcn ANN17 MFAT line port SN228 Off-premises station line On-premises station line SN229 MFET line port SN224 SN230 CO trunk Auxiliary trunk SN231 SN232 DID trunk SN233 Tie trunk SN238...
  • Page 70 PORT PACKS/DCP REPEATERS: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES TABLE 4-2. Terminals and Peripherals Served by Port Circuit Packs Port Fcn Pack ANN17B MFAT Off-premises station line SN228 SN229 On-premises station line SN224 MFET line port Tie trunk/attendant console SN233 SN238 SN243...

  • Page 71: Table 4-3. Voice Terminal Loop Ranges

    PORT PACKS/DCP REPEATERS: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES TABLE 4-3. Voice Terminal Loop Ranges Voice Terminal Analog All sets 2500 series 7100 series Hybrid 7203H 7205H 7303S 7305S Digital 740X Distance (Ft) 24AWG 26AWG Using SN229 circuit pack 5380 3500 18,460...

  • Page 72: Dcp Repeaters

    PORT PACKS/DCP REPEATERS: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES DCP REPEATERS When a digital voice terminal must be installed at a loop-length distance in excess of 5000 ft, a DCP repeater must be installed in its wiring path. The DCP repeater is a circuit board that has been designed for mounting on a 100-pair, 110A wiring block.
  • Page 73 PORT PACKS/DCP REPEATERS: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES...

  • Page 74: Installation Example: System 85 And Definity Generic 2 With

    5. INSTALLATION EXAMPLE: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES This chapter illustrates the design process for a hypothetical main distribution frame (MDF) using a seven-module system. The process consists of two steps: sizing the MDF and constructing the MDF. SIZING THE MDF Sizing is the determination of the number of 300-pair terminal blocks needed to construct the MDF.
  • Page 75 INSTALLATION EXAMPLE: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITlONAL MODULES Determining Block Quantities The following computations show how the field requirements are converted into terminal blocks. 1. Green Field A. Number of Cable pairs terminated = B. Number of cross-connect blocks required = 2.

  • Page 76: Constructing The Mdf

    INSTALLATION EXAMPLE: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADfTIONAL MODULES B. Computation of blocks: 7 blocks x 7 modules = module C. Computation of blocks: 300 pairs = 14,000 pairs + block 4. White Field A. Computation of blocks: 300 pairs = 14,000 pairs + block...

  • Page 77: Figure 5-1. 7-Module System Wall-Mounted On Type-1 Frame

    INSTALLATION EXAMPLE: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Figure 5-1. 7-Module System Wall-Mounted on Type-1 Frame Several problems arise from the arrangement shown in figure 5-1, 7-Module System Wall-Mounted on Type-1 Frame, that make it undesirable. First, because the module layouts are asymmetrical, cable terminations begin in a different location for each module.

  • Page 78: Figure 5-4. 7-Module System Mounted On Self-Supporting Type-2 Frame, Front

    INSTALLATION EXAMPLE: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITlONAL MODULES Figure 5-3. 7-Module System Mounted on Self-Supporting Type-1 Frame, Rear Frame arrangements. In this installation, although the block count shows that five frames are needed, the arrangement of the frames increases the need to seven. And, since this installation uses zones, the distribution cable is separated on the MDF.

  • Page 79: Figure 5-5. 7-Module System Mounted On Self-Supporting Type-2 Frame, Rear

    INSTALLATION EXAMPLE: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES Figure 5-4. 7-Module System Mounted on Self-Supporting Type-2 Frame, Front Figure 5-5. 7-Module System Mounted on Self-Supporting Type-2 Frame, Rear Cable connections to the MDF. In this example, all connections to the frames from the equipment are by connector cables.

  • Page 80: Overview: Definity Generic 2 With Universal Modules

    6. OVERVIEW: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES This chapter identifies the important differences between a DEFINITY® Generic 2 Communications System (hereafter abbreviated to DEFINITY Generic 2 or Generic 2) with universal modules and the systems described in chapter 1, Overview: System 85 and DEFINITY Generic 2 with Traditional Modules.
  • Page 81 OVERVIEW: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES CC Carrier (J58888AB) The CC carrier fulfills the same function for DEFINITY Generic 2 with universal modules that it does in System 85 and DEFINITY Generic 2 with traditional modules. TMS Carrier (J58888C) The TMS performs the same function in DEFINITY Generic 2 with universal modules that it does in System 85 and DEFINITY Generic 2 with traditional modules.

  • Page 82: System Adjuncts

    Remote Modules The UMC carrier can hold up to seven remote module interface (RMI) circuit packs (TN456). Remote modules are supported by System 85 and universal and traditional modules in the DEFINITY Generic 2 system. Call control uses fiber-optic links with a central-to-remote range of up to 25,000 ft. Remote modules with optically-remoted peripheral interfaces (ORPI) for attendant consoles have a maximum range of 13,000 ft.

  • Page 83: Cross-Connect Fields

    OVERVIEW: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES CROSS-CONNECT FIELDS The DEFINITY Generic 2 with universal modules uses System 75 port board technology and has 500 pairs per carrier and 3 carriers per module. This creates significant differences in wall-field design from that used in System 85 and DEFINITY Generic 2 with traditional modules.
  • Page 84 SCMCC (J58890P) The SCMCC provides module processing functions similar to those of the UMCC (universal module control cabinet) but can only be used as a remote module. Each SCMCC houses the universal module control and contains the equipment required to support one unduplicated or one duplicated module control complex.
  • Page 85 OVERVIEW: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES...

  • Page 86: Recommended Terminal Blocks

    7. MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES This chapter recommends the terminal blocks and frames best suited for constructing a main distribution frame (MDF) for the DEFINITY™ Generic 2 Communications System (hereafter abbreviated to DEFINITY Generic 2 or Generic 2) with universal modules, presents the guidelines for their design, presents some guidelines for the intermediate distribution frame (IDF) design, and briefly discusses labeling for the MDFs and IDFs.

  • Page 87: Table 7-1. 300-Pair Terminal Blocks

    MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Product Code ll0AB1-300FT* 110AB1-300CTM** 110AB1-300CBM† NOTE: The meanings for the alphabetic suffixes to the model codes are as follows: * Field terminated ** Connectorized w/male connector † Connectorized bottom w/male Table 7-2, 100-Pair Terminal Blocks, gives the ordering information for the 100-pair terminal blocks: Product Code ll0AB1-100FT* ll0AB1-100CT**...

  • Page 88: Mdf/Idf Design: Definity Generic 2 With Universal Modules

    Height Requirement for Terminal-Block Columns When you lay out the columns of terminal blocks for the MDF, place no more than 1500 pairs (five 300-pair blocks in a column) for either frame- or wall-mounted installations. (See figure 7-1, Maximum Column 1500 Pairs (Five 300-Pair Teminal Blocks).) Taller columns are hard to reach and make connecting and disconnecting jumper wires difficult.

  • Page 89: Figure 7-2. Jumper Placement

    MDF/lDF DESlGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Connecting Jumper Wires To facilitate cross-connections, connect jumper wires as follows: Use the layout and instructions shown in figure 7-2, Jumper Placement, for the 110A terminal blocks. (Figure 7-2 illustrates a layout for frame mounting, but the layout applies to wall mounting a s w e l l .

  • Page 90: Recommended Frames For Terminal Blocks

    FOR TERMINAL BLOCKS RECOMMENDED FRAMES The extra-large building entrance terminal (XLBET) frame, which is manufactured at the AT&T Los Angeles Service Center, can be used for the MDF. The frame comes in single- and double-sided versions that are 84 in. high, 10 in, deep (single-sided) to front edge of wireway with rear foot removed, 20 in.

  • Page 91: Figure 7-3. Six Type-1 Frames With 18,000-Pair Capacity

    MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Figure 7-3. Six Type-1 Frames with 18,000-Pair Capacity Type-2 Frame The type-2 frame shown in figure 7-4, Seven Type-2 Frames with 16,800-Pair Capacity, has added jumper capacity. You may terminate 2400 pairs on each of its sides. Cross-connections on the type-2 frame can be made either from top to bottom or from side to side, depending on the size and shape of the installation.

  • Page 92: Figure 7-4. Seven Type-2 Frames With 16,800-Pair Capacity

    MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Figure 7-4. Seven Type-2 Frames with 16,800-Pair Capacity...

  • Page 93: Table 7-3. Type-1 Frame Ordering Information

    MDF/IDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Ordering The service center ships all frames with terminal blocks as one comcode. Frames ordered for 110A hardware come with 110AB1-300 terminal blocks, clear designation strips, and wireways installed. You must order insert labels and ladder racks separately. Order type-1 and type-2 frames and connectors according to table 7-3, Type-1 Frame Ordering Information, and table 7-4, Type-2 Frame Odering Information.

  • Page 94: Designing The Mdf

    TABLE 7-4. Type-2 Frame Ordering Information Comcode 105 689 491 105 689 483 105 730 212 105 730 113 DESIGNING THE MDF Designing the MDF is a two-step process. First, determine the size of the MDF. Second, construct the MDF. As you proceed with the design, keep in mind that function is more important than cost in reaching a final decision since it is possible for the final installation to be inexpensive but nonfunctional.

  • Page 95: Modules

    7-10 MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Figure 7-5. Overall Equipment Wiring Plan: DEFINITY Generic 2 with Universal Modules...
  • Page 96 Two factors govern the size of the MDF: the number of cable pairs to be terminated and the type of cross-connect hardware used. Since the recommended cross-connect hardware for Generic 2 with universal modules is the 110A, you need only to calculate the number of cable pairs that must terminate on the MDF and the number of 110A cross-connect blocks needed to terminate those pairs to arrive at the size of the MDF.
  • Page 97 7-12 MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Equipment (Switch) Port Field The equipment port field uses purple labels; it terminates equipment port cables. Two factors govern its size. The first is the type, usage, and number of port carriers. The second is module needs, since all ports from an equipment module must be colocated.

  • Page 98: Figure 7-6. Cpc Wall Field Configuration

    Figure 7-6. CPC Wall Field Configuration Distribution Field The distribution field uses white labels; it is where all distribution cables terminate. Distribution cables are the cables that run from the MDF in the equipment room to the IDF in the closets. (They are sometimes called "house,"...
  • Page 99 7-14 MDF/lDF DESIGN: DEFINlTY GENERIC 2 WITH UNIVERSAL MODULES NOTE: When a blue field is used, the blue field cross-connects directly to the purple field and not to the white field. Terminate only six 4-pair DIW cables to each index strip of a 110AB1-300 wiring block (the 25th pair is unused), which means that you can terminate a maximum of 72 4-pair DIW cables on each 300-pair wiring block.

  • Page 100: Table 7-5. Mounting Methods

    Mounting the Terminal Blocks You can mount the MDF hardware in one of the following three ways: Directly to a wall On a wall-mounted frame On a self-supported frame Table 7-5, Mounting Methods. is a mounting guide for the number of modules appropriate for each mounting method.

  • Page 101: Figure 7-7. Four-Area Mdf

    7-16 MDF/IDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Network Services When 4-pair installation cables and spare cables or cables dedicated to systems terminated on the MDF other than Generic 2 with universal modules are terminated on the MDF, add two more fields to the arrangement.

  • Page 102: Figure 7-8. Combined Trunk And Line Ports

    7-17 MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Figure 7-8. Combined Trunk and Line Ports...

  • Page 103: Figure 7-9. Separated Trunk And Line Ports

    7-18 MDF/lDF DESIGN: DEFINlTY GENERIC 2 WITH UNIVERSAL MODULES Figure 7-9. Separated Trunk and Line Ports Zone Configurations. When a large number of frames are required to construct an MDF, the task of connecting and disconnecting jumper wires can become difficult for two reasons. First, jumper wires of awkwardly long lengths are needed to make cross-connections between the extreme ends of the frame lineup.

  • Page 104: Table 7-6. Module Allocation Per Zone With Type-1 Frame

    Divide the terminations of the distribution cables among the zones in 100-pair increments. (described earlier in this chapter under Recommended Frames for Terminal Blocks) may be used for a zoned MDF that is terminating up to 10 modules. Table 7-6, Module Allocation per Zone with Type-1 Frame, shows the number of modules allocated per zone when you design an MDF with a type-1 frame.

  • Page 105: Figure 7-11. Zone Arrangement Of Type-1 Frame — Front View, Zone 2

    7-20 MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES ZONE 1 FRAME NUMBER ZONE 2 Figure 7-10. Zone Arrangement of Type-1 Frame — Plan View LEGEND: Y— YELLOW, AUXILIARY AND MISCELLANEOUS FIELD W — WHITE, DISTRIBUTION FIELD P — PURPLE EQUIPMENT FIELD S —...

  • Page 106: Figure 7-12. Zone Arrangement Of Type-2 Frame — Plan View

    Use the type-2 frame (described earlier in this chapter under Recommended Frames for Terminal Blocks) to design a zoned MDF that is terminating up to 16 modules. Table 7-7, Module Allocation per Zone with Type-2 Frame, shows the number of modules allocation per zone when you design an MDF with a type-2 frame.

  • Page 107: Figure 7-13. Zone Arrangement Of Type-2 Frame — Front View, Zone 2

    7-22 MDF/lDF DESIGN: DEFINlTY GENERIC 2 WITH UNIVERSAL MODULES Figure 7-13. Zone Arrangement of Type-2 Frame — Front View, Zone In addition to the preceding guidelines, observe these rules when designing zones: Mount the hardware on frames. For 1-zone installations, wall-mounted frames may be used. For 2- zone installations, double-sided, self-supporting frames must be used.

  • Page 108: Figure 7-14. Closet Cross-Connects Using Type-1 Frames

    IO number for an extension Equipment line location (ELL) number for that extension Module number for that ELL NOTE: If station #2700 is located in module 04, the cross-connection in the closet goes to a pair in zone 1. Similarly, if #3001 is in module 07, the cross-connection in the closet goes to a pair in zone 2.

  • Page 109: Designing The Mdf For A Raised Floor

    7-24 MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Use cross-connect hardware without connectors (for field terminations) for distribution cables. Use cross-connect hardware without connectors (for field terminations) for equipment cables for systems over five modules. Use cross-connect hardware with connectors for equipment cables for systems of one to five modules.
  • Page 110 If you are required to design a raised-flooring MDF, use the following guidelines. Before designing the layout of an MDF over a raised floor, take into account the following three issues that can affect the design: The use of raised floor space as an air plenum. The National Electric Code (NEC) prohibits the placement of cables that use ordinary covering materials, such as polyvinyl chloride (PVC) or polyethylene, in the building air plenums.

  • Page 111: Figure 7-15. Floor Template - 18 Inch Tile (L472366)

    7-26 MDF/lDF DESIGN: DEFINlTY GENERIC 2 WITH UNIVERSAL MODULES ‹ › 18" ˆ 2" 18" Figure 7-15. Floor Template -18 Inch Tile (L472366)

  • Page 112: Figure 7-16. Floor Template - 24 Inch Tile (L472367)

    7-27 MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Figure 7-16. Floor Template - 24 Inch Tile (L472367)

  • Page 113: Figure 7-17. Floor Template - Cabinet Lineup (L472368)

    7-28 MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Figure 7-17. Floor Template - Cabinet Lineup (L472368)
  • Page 114 Cable Routing Take special care to ensure that cables from different modules do not cross at the MDF and that distribution cables are not crossed over module cables. Make sure that the cables routed under the raised floor are dressed and that they are done so with a minimum of slack to prevent tangled cables that can obstruct access to other under-floor equipment.

  • Page 115: Figure 7-18. Floor-Secured Frame Installation

    7-30 MDF/lDF DESIGN: DEFINlTY GENERIC 2 WITH UNIVERSAL MODULES Figure 7-18. Floor-Secured Frame Installation...

  • Page 116: Recommendations For Idf Designs

    RECOMMENDATIONS FOR IDF DESIGNS For Generic 2 with universal modules, IDFs serve as secondary cross-connect points between distribution cables and installation cables, which connect to the IOs. The IDFs usually are housed in closets. Along with the IDF, these closets frequently house the auxiliary power units that some telephones require.

  • Page 117: Insert Labels

    7-32 MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES INSERT LABELS Insert labels identify the origins of cables that terminate on the MDF and on the IDFs. The labels are color-coded and come in sheets with 18 labels per sheet. The labels slip into the ½-in. by 8-in. clear plastic holders that snap between the horizontal index strips of the terminal blocks.

  • Page 118: Figure 7-19. Example Of Label Filled In

    Figure 7-19. Example of Label Filled In The label sheets are stocked at the AT&T Customer Information Center and can be obtained by calling (800) 432-6600 or by writing to: AT&T Customer Information Center P.0. Box 19901 Indianapolis, Indiana 46219 Include the following information when ordering: Name and address Geographic location number (such as CO81OO)
  • Page 119 7-34 MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES...

  • Page 120: Electrical Protection: Definity Generic

    8. ELECTRICAL PROTECTION: DEFINITY GENERIC 2 This chapter describes the protection scheme for DEFINITY® Communications System Generic 2 (hereafter abbreviated to DEFINITY Generic 2 or Generic 2) with universal modules. Basic protection concepts apply to both the DEFINITY Generic 2 with universal modules, System 85, and DEFINITY Generic 2 with traditional modules.

  • Page 121: Protection Matrix

    ELECTRICAL PROTECTION: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Enhanced Primary Protector The 4C3S-75 (PEC 65543 and 65543A), ITW LP2-100-068 (PEC 65541 and 65541A), and Porta Systems Corp., Delta Protector (PDP) (PEC 65540) are the three devices available for providing vulnerable port packs with enhanced primary protection. (See table 8-1.) Select the ITW LP2-100-068 for installations with a type 66 mounting.

  • Page 122: Table 8-1. Generic 2 With Universal Modules Protection Matrix

    ELECTRICAL PROTECTION: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES TABLE 8-1. Generic 2 with Universal Modules Protection Matrix Circuit Exposed Circuits/ Line Packs/ On-Off Prem Circuit T N 7 2 / 8 Yes/Both TN46/16 No/On TN746B/16 No/On TN762B/8 No/On Yes/Both TN754/8 TN754B/8 Yes/Both Yes/Both...
  • Page 123 ELECTRICAL PROTECTION: DEFINlTY GENERIC 2 WITH UNIVERSAL MODULES...

  • Page 124: Port Packs: Definity Generic 2 With Universal Modules

    9. PORT PACKS: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES This chapter presents supplementary information on port circuit packs, and loop distances for terminals that you may find useful in designing a wiring installation. Digital communications protocol (DCP) guidelines for DEFINITY® Generic 2 Communications System (hereafter abbreviated to DEFINITY Generic 2 or Generic 2) with universal modules are the same as those for System 85 and DEFINITY Generic 2 with traditional modules.
  • Page 125 PORT PACKS: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Pack Port Fcn DS1 Packet Adjunct PRI TN555 TN767 ISDN-BRI TN556 Data Line TN726 MET Line TN735 TN742 ONS Analog Line or OFS Analog Line TN746 Analog Line ONS CO Trunk TN747B DID Trunk TN753 Digital Line...
  • Page 126 TABLE 9-2. Terminals and Peripherals Served by Port Packs Ckt Pack Port Fcn TN556 ISDN-BRI TN726 TN753 MET Line TN742 Analog Line ONS/OFS TN746 Analog Line ONS TN754 Digital Line TN754B Digital Line Tie Trunk/Attendant Console TN760C TN762B Hybrid Line PORT PACKS: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Term/Periph Served 750X-BRI —...

  • Page 127: Dcp Repeaters

    PORT PACKS: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES TABLE 9-3 Voice Terminal Loop Ranges Terminal Type 24 AWG Analog 20000 500/2500 500/2500 3100 15200 710X Hybrid 730X 1000 2000 Digital 740X 3000 2400 B R I 750X 1900 DCP REPEATERS Basic guidelines for DCP repeaters are the same for DEFINITY Generic 2 with universal modules as they are for System 85 and DEFINITY Generic 2 with traditional modules.

  • Page 128: With Universal Modules

    10. lNSTALLATlON EXAMPLE: DEFINITY GENERIC 2 This chapter illustrates the design process for a hypothetical main distribution frame (MDF) using a seven-module system. The process consists of two steps: sizing the MDF and constructing the MDF. SIZING THE MDF Sizing is the determination of the number of 300-pair terminal blocks needed to construct the MDF. First, assess the requirements of the four principle fields.
  • Page 129 10-2 INSTALLATION EXAMPLE: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Determining Block Quantities The following computations show how the field requirements are converted into terminal blocks. 1. Green Field A. Number of Cable pairs terminated = B. Number of cross-connect blocks required = 2.

  • Page 130: Constrcuting The Mdf

    INSTALLATION EXAMPLE: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES 4. White Field A. Computation of blocks: x 1 block 12,000 pairs 300 pairs 5. All Fields 4+42+40 The total number of blocks required to construct the MDF is 86. CONSTRUCTING THE MDF The construction of the MDF is based on the block counts made above and on the factors listed below.

  • Page 131: Figure 10-1. 7-Module System Wall-Mounted On Type-1 Frames

    10-4 lNSTALLATlON EXAMPLE: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Figure 10-1. 7-Module System Wall-Mounted on Type-1 Frames Figure 10-2, 7-Module System Wall-Mounted on Type-2 Frames, shows a possible arrangement for a type-2 wall-mounted configuration requiring 12 frames. This arrangement has greater jumper capacity and room to add another cabinet.

  • Page 132: Figure 10-3. 7-Module System Mounted On Self-Supporting Type-1 Frame, Front

    INSTALLATION EXAMPLE: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES — Self-supporting frames. Mounting the terminal blocks on self-supporting frames requires seven type-1 frames or seven type-2 frames. Figure 10-3, 7-Module System Mounted on Self-Supporting Type-1 Frame, Front, and figure 10-4, 7-Module System Mounted on Self-Supporting Type-1 Frame, Rear, display the front and rear of a type-1 frame.

  • Page 133: Figure 10-4. 7-Module System Mounted On Self-Supporting Type-1 Frame, Rear

    10-6 lNSTALLATION EXAMPLE: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Figure 10-4. 7-Module System Mounted on Self-Supporting Type-1 Frame, Rear — Frame arrangements. Figure 10-5, 7-Module System Mounted on Self-Supporting Type-2 Frame, Front, and figure 10-6, 7-Module System Mounted on Se/f-Supporting Type-2 arrangement requiring seven type-2 frames.
  • Page 134 10-7 INSTALLATION EXAMPLE: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES Figure 10-5. 7-Module System Mounted on Self-Supporting Type-2 Frame, Front Figure 10-6. 7-Module System Mounted on Self-Supporting Type-2 Frame, Rear...
  • Page 135 10-8 INSTALLATION EXAMPLE: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES...

  • Page 136: 11. Bri: Definity Generic 2 With Universal Modules

    11. BRI: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES The integrated services digital network (ISDN) basic rate interface (BRI) provides ISDN service between voice and data terminals and the switch. The TN556 is the new BRI port pack; it provides 12 ISDN ports and is housed in the common port carrier (CPC) of DEFINITY®...

  • Page 137: Figure 11-1. Special Isdn Wiring For Satellite Closet

    11-2 BRI: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES BRI uses pairs 1 and 3 of the DIW cable as shown in figure 11-1, Special ISDN Wiring for Satellite Closet. Figure 11-1. Special ISDN Wiring for Satellite Closet BRI POWER SUPPLIES BRI terminal power can be installed in either the satellite closet or the workstation.

  • Page 138: Table 11-1. Power Supply Distance Limits

    346A bulk power supply — Four 10-watt outputs of -48 VDC each; located in the satellite closet and not limited to powering BRI terminals. The 346A is switch-selectable and can also supply two outputs of 20 watts each. 329A — One 25-watt output at -48 VDC. It can be located in the satellite closet or at the workstation.
  • Page 139 11:4 BRI: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES...

  • Page 140: 12. Adjunct Power Supplies

    12. ADJUNCT POWER SUPPLIES This chapter describes the power supplies for adjuncts such as speakerphones, display modules, or voice terminals. It further describes the adjuncts served by each supply and the AC power requirements of each power supply. These power supplies serve adjuncts for both System 85 and DEFINITY® Generic 2 Communications Systems (hereafter abbreviated DEFINITY Generic 2 or Generic 2).

  • Page 141: Bulk Power Supply

    12-2 ADJUNCT POWER SUPPLIES KS22911 — A power supply that plugs into three-prong 120 VAC outlets at the workstation. The KS22911 supplies -48 VDC up to 150 ft for any one adjunct and a speakerphone or headset. When the KS22911 is used at the workstation, it provides power through the connecting cord to a terminal. When small numbers of terminals require adjunct power, the KS22911 power supply can be installed in the satellite closet.

  • Page 142: 13. Fiber-Optics

    Fiber-optic cables connect the TMS to module control (MC) carriers. Fiber-optic cables also connect remote module interface (RMI) circuits in remote modules to RMI circuits at the central location. In a multimodule system, each MC carrier has a fiber-optic transmitter and a fiber-optic receiver that interfaces with a two-fiber cable.
  • Page 143 13-2 FIBER-OPTICS TABLE 13-1. System 85 and DEFINITY Generic 2 Fiber-Optic Paddleboard Ranges Application Generic 2 (traditional module) — as a central-location module, a nearby remote module, or containing an RMI seining a nearby module Generic 2 (traditional module) — as a distant remote module or containing an RMI serving a distant remote module Generic 2 TMS...
  • Page 144 TABLE 13-1. System 85 and DEFINITY Generic 2 Fiber-Optic Paddleboard Ranges (Continued) .“ — in a central location System 85 RMI module, or an RMI carrier, connecting to an RMI in the remote module System 85 TMS — connecting to a central location module System 85 TMS —...

  • Page 145: 14. Insert Labels

    14. INSERT LABELS This chapter shows partial reproductions of the upper third of each insert label sheet. Table 14-1, Numerical List of Insert Labels, lists the labels in numerical order. The representations are grouped by the following color coding that indicates the source of the terminating leads as follows: Green: network services central office (CO) trunks Purple: equipment ports Yellow: auxiliary cabinet and miscellaneous field...

  • Page 146: Table 14-1. Numerical List Of Insert Labels

    14-2 INSERT LABELS TABLE 14-1. Numerical List of Insert Labels Select Code 801-l00 801-101 801-102 801-103 801-104 801-105 801-106 801-107 801-108 801-109 801-110 801-111 801-112 801-113 Label Title 1 Pair, Ports (Purple) 1 Pair, Ports (Purple) 1 or 3 Pair, Ports (Purple) 1 or 3 Pair, Ports Mix (Purple) 3 Pair, Ports (Purple) 3 Pair, Ports (Purple)
  • Page 147 TABLE 14-1. Numerical List of Insert Labels (continued) Select Label Title Code 801-114 2 Pair, Link (White) 801-115 3 Pair, Link (White) 801-116 3 Pair, Link (White) 3 Pair, Link (White) 801-117 801-118 3 Pair, Link (White) 3 Pair, Link (Blue) 801-119 4 Pair, Jack (Blue) 801-120...
  • Page 148 14-4 INSERT LABELS TABLE 14-1. Numerical List of Insert Labels (continued) Select Code 801-128 801-129 801-130 801-131 801-132 801-133 801-134 801-135 801-136 801-137 801-138 801-139 801-140 801-141 Label Title Pair Count, 1-900 (Yellow) Pair Count, Generic (White) Pair Count, 1-900 (White) Pair Count, 901-1800 (White) Pair Count, 1801-2700 (White) 1 Pair, Ports (Purple)

  • Page 149: Figure 14-1. Insert Labels - Partial Reproductions 1

    Insert Labels 110 Hardware 1 Pair, Ports Purple Insert Labels l l 0 H a r d w a r e 1 Pair, Ports Purple Insert Labels 110 Hardware 1 or 3 Pair, Ports P u r p l e Figure 14-1.

  • Page 150: Figure 14-2. Insert Labels - Partial Reproductions 1

    14-6 INSERT LABELS Figure 14-2. Insert Labels - Partial Reproductions Insert Labels SELECT CODE 110 Hardware 8 0 1 - 1 0 3 1 or 3 Pair, Ports Mix Purple Insert Labels SELECT CODE 110 Hardware 8 0 1 - 1 0 4 3 Pair, Ports Purple Insert Labels...

  • Page 151: Figure 14-3. Insert Labels - Partial Reproductions 1

    Insert Labels 110 Hardware 2 Pair, Ports Purple Insert Labels 110 Hardware 2 Pair, Ports Purple Insert Labels 110 Hardware 3 Pair, Misc Purple Figure 14-3. Insert Labels - Partial Reproductions 14-7 INSERT LABELS SELECT CODE 8 0 1 - 1 0 6 SELECT CODE 8 0 1 - 1 0 7 SELECT CODE...
  • Page 152 14-8 INSERT LABELS Figure 14-4. Insert Labels 110 Hardware 4 Pair, Misc Purple Insert Labels 110 Hardware Pair Count, Generic Purple Insert Labels 110 Hardware 3 Pair, Misc White Insert Labels - Partial Reproductions SELECT CODE 8 0 1 - 1 0 9 SELECT CODE 8 0 1 - 1 2 5 SELECT CODE...

  • Page 153: Figure 14-5. Insert Labels - Partial Reproductions 1

    Insert Labels 110 Hardware 2 Pair, Link White Insert Labels 110 Hardware 2 Pair, Link White Insert Labels 110 Hardware 3 Pair, Link White Figure 14-5. Insert Labels - Partial Reproductions 14-9 INSERT LABELS SELECT CODE 8 0 1 - 1 1 3 SELECT CODE 8 0 1 - 1 1 4 SELECT CODE...

  • Page 154: Figure 14-6. Insert Labels - Partial Reproductions

    14-10 INSERT LABELS Figure 14-6. Insert Labels - Partial Reproductions Insert Labels 110 Hardware 3 Pair, Link White Insert Labels SELECT CODE 110 Hardware 8 0 1 - 1 1 7 3 Pair, Link White Insert Labels SELECT CODE 110 Hardware 8 0 1 - 1 1 8 3 Pair, Link White...

  • Page 155: Figure 14-7. Insert Labels - Partial Reproductions

    Insert Labels 110 Hardware Pair Count, Generic White Insert Labels 110 Hardware Pair Count, 1-900 White Insert Labels 110 Hardware Pair Count, 901-1800 White Figure 14-7. Insert Labels - Partial Reproductions 14-11 INSERT LABELS SELECT CODE 8 0 1 - 1 2 9 SELECT CODE 8 0 1 - 1 3 0 SELECT CODE...

  • Page 156: Figure 14-8. Insert Labels - Partial Reproductions

    14-12 INSERT LABELS Figure 14-8. Insert Labels - Partial Reproductions Insert Labels 110 Hardware Pair Count, 1801-2700 White Insert Labels SELECT CODE 110 Hardware 8 0 1 - 1 1 9 3 Pair, Link Blue Insert Labels SELECT CODE 110 Hardware 8 0 1 - 1 2 0 4 Pair, Jack Blue...

  • Page 157: Figure 14-9. Insert Labels - Partial Reproductions

    Insert Labels l l 0 H a r d w a r e 4 Pair, Jack 1-216 Blue Insert Labels 110 Hardware 4 Pair, Jack 217-432 Blue Insert Labels 110 Hardware Pair Count, Generic Blue Figure 14-9. Insert Labels - Partial Reproductions 14-13 INSERT LABELS SELECT CODE...

  • Page 158: Figure 14-10. Insert Labels - Partial Reproductions

    14-14 INSERT LABELS Figure 14-10. Insert Labels - Partial Reproductions Insert Labels SELECT CODE 110 Hardware 8 0 1 - 1 1 0 3 Pair, Misc Yellow Insert Labels SELECT CODE 8 0 1 - 1 2 4 110 Hardware Pair Count, Generic Yellow Insert Labels...

  • Page 159: Figure 14-11. Insert Labels - Partial Reproductions

    Insert Labels 110 Hardware 3 Pair, Link Gray Insert Labels 110 Hardware Pair Count, Generic Green Insert Labels 110 Hardware Pair Count, 1-900 Green Figure 14-11. Insert Labels - Partial Reproductions 14-15 INSERT LABELS SELECT CODE 8 0 1 - 1 1 2 SELECT CODE 8 0 1 - 1 2 3 SELECT CODE...

  • Page 160: Figure 14-12. Insert Labels - Partial Reproductions

    14-16 INSERT LABELS Figure 14-12. Insert Labels - Partial Reproductions Insert Labels SELECT CODE 110 Hardware 8 0 1 - 1 3 3 1 Pair, Ports Purple Insert Labels SELECT CODE 110 Hardware 8 0 1 - 1 3 4 2 or 1 Pair, Ports Purple Insert Labels...

  • Page 161: Figure 14-13. Insert Labels - Partial Reproductions

    Insert Labels 110 Hardware 3 or 1 Pair, Ports Purple Insert Labels 110 Hardware 1 or 3 Pair, Ports Purple Insert Labels 110 Hardware 2 or 1 Pair, Ports Purple Figure 14-13. Insert Labels - Partial Reproductions 14-17 INSERT LABELS SELECT CODE 8 0 1 - 1 3 6 SELECT CODE...

  • Page 162: Figure 14-14. Insert Labels - Partial Reproductions

    14-18 INSERT LABELS Figure 14-14. Insert Labels - Partial Reproductions Insert Labels SELECT CODE 8 0 1 - 1 3 9 110 Hardware 1 or 2 Pair, Ports Purple Insert Labels SELECT CODE 8 0 1 - 1 4 0 110 Hardware 3 or 1 Pair, Ports Purple...

  • Page 163: Glossary

    ADFTC AIOD applications processor (AP) asynchronous data unit (ADU) AT&T Audio Information Exchange (AUDIX) avalanche diode backbone cable backplane Basic Rate Interface (BRI) GLOSSARY analog/digital facility test circuit asynchronous data module asynchronous data unit Automatic Identification of Outward Dialing A computer designed for running applications that both manage and enhance the capabilities of a communications system.
  • Page 164 GL-2 GLOSSARY black cable building entrance facility (BEF) bulk power supply bulk power unit call coverage module campus cable carbon block central office (CO) circuit pack combination protection See distribution cable. basic modular telephone The cross-connect field (which may or may not be enclosed) where cables from the central office (CO) terminate for cross-connection to the network interface (NI).
  • Page 165 comcode common control (CC) communication module communications processor coupled bonding conductor (CBC) cross-connect block cross-connect field customer participation data-link transformer Delta The nine-digit identification number for AT&T’s equipment and parts. The master controller of the communications system. See module. See common control. A conductor that is connected between a PBX single-point ground and the protector ground terminal.
  • Page 166 GL-4 GLOSSARY designation strip digital circuit packs digital communications protocol (DCP) digital service level-1 (DS1) digital signals cross-connect (DSX) digital terminal digital terminal data module (DTDM) direct inward dialing (DID) display module distributed communications system (DCS) A clear plastic strip installed between the terminal strips of the 110A-type cross-connect blocks to hold and protect insert labels.
  • Page 167 distribution cable The cable that connects the main distribution frame (MDF) to an intermediate distribution frame (IDF., When the cable is run between floors in the same building, it is caIled riser, house, or backbone cable. When the cable runs from the MDF in one building to an IDF in another building, it is called campus cable.
  • Page 168 GL-6 GLOSSARY hard-wired headset heat coil homerun horizontal subsystem hybrid circuit packs hybrid terminal information outlet (IO) IROB insert labels Wired directly from the main distribution frame (MDF) to an information outlet (IO) that bypasses an intermediate distribution frame (IDF). A device, substituting for a handset, that combines an earphone and mouthpiece in an arrangement to be worn on the user’s head.
  • Page 169 installation cable integrated services digital network (ISDN) intermediate distribution field (IDF) ISDN jumper wire main distribution frame (MDF) modular processor data module (MPDM) modular trunk data module (MTDM) module Usually a four-pair cable that connects an information outlet (IO) to an intermediate distribution frame (IDF).
  • Page 170 GL-8 GLOSSARY multibutton electronic telephone (MET) multimodule ORPI patchcords port Porta Data System power cross power induction premises distribution system (PDS) premises services consultant (PSC) price element code (PEC) A telephone manufactured for the AT&T DIMENSION® PBX. Some of its features operate with the AT&T System 85 or DEFINITY™...
  • Page 171 primary protector purple field remote group remote group interface (RGI) remote module residual voltages riser riser subsystem satellite closet self-supporting frame single carrier module The protector installed on one or both ends of exposed cabling to protect against high-voltage surges caused by lightning, power crosses, and ground-potential rise.
  • Page 172 GL-10 GLOSSARY single carrier module control cabinet (SCMCC) single carrier port cabinet (SCPC) sneak current sneak-current fuse speakerphone standard serial interface (SSI) star configuration stringer system supplementary protection surge synchronization clock system adjuncts A single cabinet containing all hardware necessary to support one unduplicated or one duplicated module control complex for a single carrier module.
  • Page 173 terminating leads time-multiplex switch (TMS) trunk/aux field universal port carrier white field wiring block workstation XLBET zone concept The individual wires in a cable. The AT&T System 85 or DEFINITY® Generic 2 processor that controls timing and communications among the system modules. The section of the main distribution frame (MDF) where cables from the central office (CO) and from auxiliary equipment termiate for cross-connection to the switch.
  • Page 174 GL-12 GLOSSARY...

  • Page 175: Index

    110 system 2-1 110A 2-1, 2-11, 2-23, 7-1, 7-4 110AB1-100 2-1, 7-1 110AB1-300 2-1, 7-1 110P 2-1,2-12, 2-15 2012D power supply 12-1 329A power supply 12-1 346A power supply 12-2 3B5 AP 1-3 501CC 1-3 66 system 2-1 7500 terminals 11-1 A25D 6-2, 6-4, 7-24 ADFTC 1-7 adjunct power supplies 12-1...
  • Page 176 IN-2 INDEX connecting block 2-1, 7-1 connectivity 1-4 Generic 2 with traditional module 1-6 Generic 2 with universal module 6-4 System 85 1-6 connectors 2-23, 7-24 coupled bonding conductor (CBC) 3-2 cross-connect design 2-14, 7-15 Generic 2 6-4 satellite closet 2-23 type-1 frame 2-5, 7-5 type-2 frame 2-6, 7-6 cross-connections 2-4, 2-17, 2-22, 7-4, 7-15,...
  • Page 177 lightning 3-1 line ports 2-9, 7-9 Linx LP2-100-068 3-6 loop ranges 3-6, 3-7, 3-8, 4-1, 4-4, 8-3, 9-1 main distribution frame xi, 1-4, 2-1 thru 2-33, 7-1 thru 7-33 Marketing Branch Organization 4-1 MBO 4-1 module single carrier 6-4 MS-DOS xiii multimodule 1-1 network services field 2-11, 5-1, 7-11, 10-1 ORPI 1-2, 6-3, 13-1...
  • Page 178 IN-4 INDEX type-2 frame — Contd 2-20 zone configuration universal module control (UMC) carrier 6-1 wall installation 2-3 white field 1-5 wiring block 2-1, 7-1 XLBET frame 2-5, 7-5 zone arrangement 2-18, 7-21 configurations 2-17, 7-18...

This manual is also suitable for:

Definity 6219Definity 6221Definity 6402dDefinity 6211Definity 6408d+Definity 7401 ... Show all

Table of Contents
