C G
ONNECT AS TO
Regulator Pressure Settings
Analyzer
Gemini
Exceeding the maximum recommended air pressure could cause personal injury or
damage the instrument.
Ensure the gas cylinder is closed before connecting the gas line to the analyzer.
1. Loosen, then remove the plug from the analysis port.
2. Insert the gas line into the port and hand tighten the connector nut. Use a 7/16 in. (11 mm)
wrench to tighten the nut until very snug.
3. If using helium, connect in the same manner.
Gemini VII 2390 Installation Instructions and Checklist
239-42870-02 Rev (B) — May 2021
A
NALYZER
Gauge should indicate
15-18 psig (103 - 124 kPag)

Connect Gas to Analyzer

6 - 5
