6.2. Mechanical specifications

6.2.1 . Palletizing Solution (without AirPick Vacuum Gripper)
Specifications
Product weight (without robot and gripper)
Base weight
Column weight
Maximum box weight
Minimum box dimensions
Pallet dimensions- Width
Pallet dimensions- Depth
Pallet height (empty)
Pallet height (filled)
Shipping crate dimensions
Shipping weight (Gross weight)
Maximal acceleration in operating condition
Maximum box throughput
Maximum number of box patterns
Energy source
*Depends on box weight, dimensions, surface, pallet dimensions and layouts.
Fig. 6-4: Mechanical Specifications of the Robotiq Palletizing Solution
Metric Units
155 kg
45 kg
110 kg
Up to 8 kg
50mm x 50mm x 50mm
From 300mm to 1016mm
From 300mm to 1219mm
Min 25mm
Max 2200mm
[2380, 950, 1250 ] mm
(L, W, H)
317 kg
Up to 13 boxes/min *
Electricity
Imperial Units
340 lbs
98 lbs
242 lbs
Up to 17.5 lbs
[2 x 2 x 2] in
From 12 in to 40 in
From 12 to 48 in
Min 2 in
Max 87 in
[93-7/8'', 37-3/8'', 49-1/16''] in
(L, W, H)
697 lbs
2 g
2
