ESDEC FlatFix Fusion Manual page 26

Rev. 10.09.19
Item number
Grey
100-7021 100-7621
100-7037 100-7637
100-7055 100-7655
100-7075 100-7675
100-7094 100-7694
* Standard length in the FlatFix Fusion calculator
Item number
100-7215
100-7207
100-7202
100-7210
100-7213
100-7086
Item number
100-7216
100-7208
100-7203
100-7211
100-7214
100-7087
MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS
Description
Black
Base profile 210 mm
Base profile 370 mm
Base profile 550 mm
Base profile 750 mm
Base profile 940 mm
Description
Ballast holder 1200
Ballast holder 1500
Ballast holder 1600
Ballast holder 1700
Ballast holder 1900
Ballast holder 2000
Description
Stabiliser 1200
Stabiliser 1500
Stabiliser 1600
Stabiliser 1700
Stabiliser 1900
Stabiliser 2000
Row distance dual
[mm]
2110
2270 *
2450
2650
2840
Panel length [mm]
Minus Max.
1170 1310
1475 1615
1550 1690
1655 1795
1830 1970
1940 2080
Panel length [mm]
Minus Max.
1170 1310
1475 1615
1550 1690
1655 1795
1830 1970
1940 2080
24
