7. Annex

Frame thickness
[mm]
10
27
35
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Rev. 10.09.19
End clip
Item number
Grey Black
100-4130 100-4930
100-4131 100-4931
100-4132 100-4932
100-4133 100-4933
100-4134 100-4934
100-4135 100-4935
100-4136 100-4936
100-4137 100-4937
100-4138 100-4938
100-4139 100-4939
100-4140 100-4940
100-4141 100-4941
100-4142 100-4942
100-4143 100-4943
100-4144 100-4944
100-4145 100-4945
100-4146 100-4946
100-4147 100-4947
100-4150 100-4950
MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS
Mounting screw
Mounting screw - Mounting screw -
High base
100-6555 (55mm) 100-6555 (55mm)
100-6560 (60mm) 100-6560 (60mm)
100-6563 (63mm) 100-6563 (63mm)
100-6570 (70mm) 100-6570 (70mm)
100-6575 (75mm) 100-6575 (75mm)
Mounting screw
Low base - Low base with
extension
100-6563 (63mm)
100-6570 (70mm)
100-6575 (75mm)
100-6580 (80mm)
100-6585 (85mm)
23
