EN
MANUAL
FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS
FlatFix Fusion
Flat roof mounting system for solar panels
in a dual landscape setup
Rev. 10.09.19
© ESDEC BV 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlatFix Fusion and is the answer not in the manual?

Questions and answers

Summary of Contents for ESDEC FlatFix Fusion

  • Page 1 MANUAL FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS FlatFix Fusion Flat roof mounting system for solar panels in a dual landscape setup Rev. 10.09.19 © ESDEC BV 2019...
  • Page 2: Table Of Contents

    The manufacturer denies any responsibility for damage or injury as a result of a failure to carefully follow these installation instructions, and failure to take common precautions in the transport, mounting and use of the FlatFix Fusion mounting system. As a result of our continuous pursuit of improvement, it may occur that the product deviates in detail from that which is described in this manual.
  • Page 3: Introduction

    Always carry out the actions in the correct order. Store the manual in a safe and dry location. If you lose the manual, you may always request a copy from Esdec BV or download it from www.esdec.com. Where there is a reference to the construction plan, we also refer to the FlatFix Calculator that allows you to generate a construction plan.
  • Page 4 The aluminium base profiles are fastened to the base elements using a click system. Use combination pliers to dismantle the base profile. Warranty The warranty is subject to the warranty conditions and the general conditions of Esdec BV. These can be found on our website www.esdec.com. Liability...
  • Page 5: Product Description

    Placing ballast The FlatFix Fusion system is not fixed to the roof and only rests on the surface. Only when the roof pitches above 3° (2° for PVC) should the roof supports be sealed to the roof. Take note of the processing instructions of the sealant and the roofing material in reference to the compatibility.
  • Page 6: Parts List

    20. Roof support adapter 8. End clip Item no: 100-7011 Item no: 100-41__ *optional For type, see Annex section 7 21. Self-tapping screw 6,0x25 see section 6.7 Item no: 100-3010 Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 7: Mounting Preparation

    Water pump pliers Metal saw for roof pitch > 2º/3º Safety helmet Safety goggles Protective clothing Safety shoes Dust mask Ear protection Safety gloves Scaffold or stable safe ladder Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 8: Determining And Measuring Position Of Solar Panels

    Ensure that the place where the solar panels are to be placed on the roof is clean, dry and flat. The presence of grit, sand, stones, algae, dust, etc. can lead to instability of the system and/or damage to the roof. Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 9: Installation

    The optional TPO protective mat can be used to protect the TPO roofing material. Bend the three rubber lips of the protective mat open and place the roof support under the lips of the protective mat. Ensure that the roof support is fully enclosed by the rubber lips. Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 10: Levelling And Mounting Base Profile To Base Elements

    3. Place the earthing device in the grooves of the low base element before clicking the base profile in the low base element. 4. Slide the low base element (incl. roof support) to the other tip of the base profile until it clicks into place. 5. One side of the FlatFix Fusion segment is ready. CLICK! CLICK! Rev.
  • Page 11 8. Slide the low base element (incl. roof support) to the other tip of the base profile until it clicks into place. 9. The first FlatFix Fusion segment is ready. Repeat the steps above until you have enough FlatFix Fusion segments to fit the first two rows of solar panels.
  • Page 12: Positioning Flatfix Fusion Segments

    2 m apart (see calculator for distance). Use the chalk or marker to mark out on the roof where the FlatFix Fusion segments are to be fitted. Ensure the FlatFix Fusion segments are aligned with each other.
  • Page 13 Place the second ballast holder between the FlatFix Fusion segments in such a way that it overlaps the first ballast holder and that the fitted holes of the ballast holder are positioned over the upright ridges of the high base elements.
  • Page 14: Perimeter Ballast (Optional)

    The ballast tray must then be screwed to the base profile using the self-tapping screw 6.0x25 (Item no. 100-3010) through one of the pre-punched holes in the ballast tray. Where two ballast trays positioned beside each other overlap, one screw is enough. CLICK! Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 15: Mounting 1 St Solar Panel

    ATTENTION! The torque of the screw connection is 4.5Nm (max. 6.5Nm). Do not overtighten the mounting screws in the base element. Consult the manual for your tool to set it to the correct torque. Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 16: Levelling And Mounting Remaining Solar Panels

    ATTENTION! The torque of the screw connection is 4.5Nm (max. 6.5Nm). Do not overtighten the mounting screws in the base element. Consult the manual for your tool to set it to the correct torque. Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 17: Mounting Optimisers & Cables

    5. The plugs of the solar panel can be fastened to the high base element in the cable guide. Optional: Click the optional optimiser onto the cable clip. Click! Ø25mm Option Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 18: Levelling Of Multiple Rows (Optional)

    1. Place the multi-core cable to one side of the system. The multi-core cable can easily be clamped into the FlatFix Fusion cable clip. To connect the multi-core cable to the solar panel, a loop must be made to the solar panel.
  • Page 19: Levelling Ballast Holders (Optional)

    The earthing cable for grounding the rows can also be used to ground the ballast holder. Place an earthing clip on each first and last ballast holder of a row to ground all rows separately. 0,24 in 6 mm Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 20: Placing Ballast

    If your roof is higher than 12 metres, we recommend you contact your supplier. They will then determine the correct weight as per your situation. Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 21: Mounting And Levelling Stabilisers

    Do not overtighten the mounting screws in the base element. Consult the manual for your tool to set it to the correct torque. Repeat the steps above for the remaining intermediate stabilisers. Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 22: Mounting Second Row Of Solar Panels

    Consult the manual for your tool to set it to the correct torque. 6.15 Mounting second row of solar panels You may now mount the second row of solar panels. Follow the mounting steps in sections 6.8 & 6.9. Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 23: Mounting Wind Deflectors Left/Right

    Use the pre-drilled hole beside the lower sun lock in the wind deflector as reference. The side wind deflectors are now grounded and secured. And the first row of solar panels is now ready! Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 24: Multiple Rows In Succession

    6.17 Multiple rows in succession If you want to mount multiple rows of solar panels in succession, you must first make further FlatFix Fusion segments (see Section 6.1) and connect these to the base profile of the already mounted panel field.
  • Page 25: Annex

    100-4940 100-4141 100-4941 100-4142 100-4942 100-6570 (70mm) 100-6570 (70mm) 100-6580 (80mm) 100-4143 100-4943 100-4144 100-4944 100-4145 100-4945 100-4146 100-4946 100-4147 100-4947 100-6575 (75mm) 100-6575 (75mm) 100-6585 (85mm) 100-4150 100-4950 Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 26 Stabiliser 1200 1170 1310 100-7208 Stabiliser 1500 1475 1615 100-7203 Stabiliser 1600 1550 1690 100-7211 Stabiliser 1700 1655 1795 100-7214 Stabiliser 1900 1830 1970 100-7087 Stabiliser 2000 1940 2080 Rev. 10.09.19 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS...
  • Page 27 When determining the edge and corner zones of a building, the current regulations must be factored in. When an edge or corner zone is indicated by Esdec, this relates to the minimum edge or corner zone. Placing solar panels in the edge or corner zone of a building is always at your own risk and is strongly discouraged.
