Network status
xStatus Network [1..1] Ethernet MacAddress
Shows the MAC (Media Access Control) address for the ISDN Link.
Format: String.
xStatus Network [1..1] Ethernet Link Network
Shows the ethernet link status for the LAN port on ISDN Link. this port is used for connecting
the ISDN Link to the network (LAN).
"No LAN": there is no connection.
"10half": the ethernet speed is 10 Mbps half-duplex.
"10full": the ethernet speed is 10 Mbps full-duplex.
"100half": the ethernet speed is 100 Mbps half-duplex.
"100full": the ethernet speed is 100 Mbps full-duplex.
"1000full": the ethernet speed is 1 Gbps full-duplex.
xStatus Network [1..1] Ethernet Link Endpoint
Shows the ethernet link status for the endpoint port on ISDN Link. this port is used for
connecting the ISDN Link to a telePresence endpoint.
"No LAN": there is no connection.
"10half": the ethernet speed is 10 Mbps half-duplex.
"10full": the ethernet speed is 10 Mbps full-duplex.
"100half": the ethernet speed is 100 Mbps half-duplex.
"100full": the ethernet speed is 100 Mbps full-duplex.
"1000full": the ethernet speed is 1 Gbps full-duplex.
xStatus Network [1..1] IPv4 Address
Shows the IPv4 address that uniquely identifies this system.
Format: String.
D14954.04 ISDN Link Administrator Guide IL1.1.2, MARCH 2015.
Getting started Software upgrade
xStatus Network [1..1] IPv4 SubnetMask
xStatus Network [1..1] IPv4 Gateway
xStatus Network [1..1] IPv4 DNS Domain Name
xStatus Network [1..1] IPv4 DNS Server [1..3] Address
xStatus Network [1..1] IPv6 Address
xStatus Network [1..1] IPv6 Gateway
xStatus Network [1..1] MTU
41
Status information Status information
Shows the subnet mask which determines which subnet an IPv4 address belongs to.
Format: String.
Shows the address of the IPv4 gateway.
Format: String.
Shows the domain name.
Format: String.
Shows the IP address of the DNS server.
Format:
String.
Shows the IPv6 address that uniquely identifies this system.
Format: String.
Shows the address of the IPv6 gateway.
Format: String.
Shows the Mtu (Maximum transmission unit) size for the network.
Format: Integer.
