xStatus MediaChannels Call [1..n] Caller IncomingAudioChannel [1..n] Transport RTP Remote Port
xStatus MediaChannels Call [1..n] Caller OutgoingAudioChannel [1..n] Transport RTP Remote Port
xStatus MediaChannels Call [1..n] Callee IncomingAudioChannel [1..n] Transport RTP Remote Port
xStatus MediaChannels Call [1..n] Callee OutgoingAudioChannel [1..n] Transport RTP Remote Port
Shows the remote uDP port number of the Real-time transport Protocol (RtP) port for the incoming or outgoing audio, on the
connection between the ISDN Link and the calling party (Caller) or between the ISDN Link and the called party (Callee).
Format: Integer.
xStatus MediaChannels Call [1..n] Caller IncomingAudioChannel [1..n] Transport RTCP Local IpAddress
xStatus MediaChannels Call [1..n] Caller OutgoingAudioChannel [1..n] Transport RTCP Local IpAddress
xStatus MediaChannels Call [1..n] Callee IncomingAudioChannel [1..n] Transport RTCP Local IpAddress
xStatus MediaChannels Call [1..n] Callee OutgoingAudioChannel [1..n] Transport RTCP Local IpAddress
Shows the local IP address of the Real-time transport Control Protocol (RtCP) port for the incoming or outgoing audio, on the
connection between the ISDN Link and the calling party (Caller) or between the ISDN Link and the called party (Callee).
Format: String.
xStatus MediaChannels Call [1..n] Caller IncomingAudioChannel [1..n] Transport RTCP Local Port
xStatus MediaChannels Call [1..n] Caller OutgoingAudioChannel [1..n] Transport RTCP Local Port
xStatus MediaChannels Call [1..n] Callee IncomingAudioChannel [1..n] Transport RTCP Local Port
xStatus MediaChannels Call [1..n] Callee OutgoingAudioChannel [1..n] Transport RTCP Local Port
Shows the local uDP port number of the Real-time transport Control Protocol (RtCP) port for the incoming or outgoing audio, on the
connection between the ISDN Link and the calling party (Caller) or between the ISDN Link and the called party (Callee).
Format: Integer.
xStatus MediaChannels Call [1..n] Caller IncomingAudioChannel [1..n] Transport RTCP Remote IpAddress
xStatus MediaChannels Call [1..n] Caller OutgoingAudioChannel [1..n] Transport RTCP Remote IpAddress
xStatus MediaChannels Call [1..n] Callee IncomingAudioChannel [1..n] Transport RTCP Remote IpAddress
xStatus MediaChannels Call [1..n] Callee OutgoingAudioChannel [1..n] Transport RTCP Remote IpAddress
Shows the remote IP address of the Real-time transport Control Protocol (RtCP) port for the incoming or outgoing audio, on the
connection between the ISDN Link and the calling party (Caller) or between the ISDN Link and the called party (Callee).
Format: String.
