ADS-B FDL-DB Dual Band Series
Installation Manual
Document No. 88552 Rev A
Table 18: Network Server Port Connection Settings
Setting
ip
local_port
remote_addr
remote_port

5.1.1.6 Network Server Port Input Configuration Details

The following table defines the network server port input data formats:
Table 19: Network Server Port Input Configuration Settings
Setting
cntrl enable

5.1.1.7 Network Server Port Functionality Configuration Details

The following table defines the network server port output data formats:
Table 20: Network Server Port Output Configuration Settings
Setting
Traffic-Alert
5-16
Interface
Network TCP or UDP protocol selection
Server
Network TCP or UDP Server port.
Server
Network UDP Client IP address
Server
remote_addr = 0.0.0.0
UDP
Send output to IP address/port of most recently received
client
remote_addr = 255.255.255.255
Send output to Broadcast IP
remote_addr = Other
Send output to remote_addr:remote_port
Network UDP Client IP port
Server
UDP
Interface
Control Squawk Code, IDENT, Call Sign, and mode (standby/alt
Input inhibit). Enables display control from a GMX-200, or other
displays using the GDL/FDL protocol. The corresponding
network server output port must be configured to Traffic-
Alert to enable display control input.
Interface
Display Ownship data, traffic reports, and FIS-B data. Format for
Output the Aspen, GMX-200, Chelton displays, or other displays
using the GDL/FDL protocol. The corresponding network
port input can be configured to "cntrl enable" to enable
display control input.
Description
Description
(2) (6)
Description
