ADS-B FDL-DB Dual Band Series
Installation Manual
Document No. 88552 Rev A
Type
Controller
GPS Input
ADS/Altitude Input
Display Output
Non-Cert Display Output
Discrete Inputs
Discrete Outputs
GPS Output

1.5.2 TC978 Controller

Specification
ENVIRONMENTAL COMPLIANCE
TSO COMPLIANCE
ETSO COMPLIANCE
SOFTWARE
PHYSICAL DIMENSIONS
Height
Width
Depth
WEIGHT
OPERATING TEMPERATURE
ALTITUDE
POWER REQUIREMENTS
Interfaces:
Type
Controller
Altitude Output
1-10
Avionics Interface
I/O
Input/ Output 7 VDC power output, remote on/off discrete input, RS-485
serial interface to the TC978
Serial (RS-232, RS-422, or RS-485) or ARINC 429 (ARINC
Input
743A/B) and PPS (ARINC 743A/B)
Input Serial (RS-232, RS-422, or RS-485) or ARINC 429
Output Serial (RS-232, RS-422, or RS-485) or ARINC 429
Output 10/100 Ethernet
Input 3 (Air/Ground, Traffic Test, and Anonymous Mode)
Output 2 (Transmit Suppression and UAT Status)
Output Serial RS-232– Internal GPS models only (P/N 87334-00-FX00,
and 87334-00-FR00)
See SECTION 3
C154c (Incomplete System)
C88b
C88a
RTCA/DO-178B Level B
1.8 in [45.3 mm]
2.5 in [61.0 mm]
2.8 in [71.1 mm]
0.11 lbs [49.9 g]
-4°F to +131°F [-20°C to +55°C]
35,000 feet
5.5 – 10 Volts DC, 0.3A max @ 6.5VDC, powered by FDL-DB -XVR
I/O
RS-485 Input/ Output
RS-232 Output
Description
Characteristics
