1.6 Parts and Equipment

1.6.1 FDL-DB Series Items

The FDL-DB Series and optional installation kit part numbers are listed below:
Part Number
87334-00-FX00
87334-10-FX10
87334-00-FR00
87334-10-FR10
88133-00
87349
86964
87002-20
87003-00
87004-00
87360-10
87360-00
87024-20
88110-00
88110-01
FFS Copyright © 2020 All rights reserved.
Qty
1 FDL-DB-XVR Transceiver with GPS
1 FDL-DB-XVR Transceiver without GPS
1 FDL-DB-RX Receiver with GPS
1 FDL-DB-RX Receiver without GPS
1 FDL-DB-XVR/RX Installation Kit (optional)
1 TC978 Controller (optional)
1 TC978 Installation Kit (optional)
Personality Module Installation Kit – Dualband (optional)
1
1 Blade Type Antenna Installation Kit (optional)
1 Ball and Stick Type Antenna Installation Kit (optional)
1 TSO-C144 AERO ANT GPS Type Antenna Installation Kit
(optional)
1 TSO-C190 SENSOR SYS GPS Type Antenna Installation
Kit (optional)
1 TSO-C190 RAMI GPS Type Antenna Installation Kit
(optional)
1 FDC-485, RS-232 to RS-485 Converter (optional)
1 FDC-422, RS-232 to RS-422 Converter (optional)
ADS-B FDL-DB Dual Band Series
Installation Manual
Document No. 88552 Rev A
Description
1-11
