Labels 016 or 031 control only Squawk Code and IDENT.
Labels 233 – 236, if present, control Call Sign.
203
210
212
314
Table 13. ADC & AHRS Format Input ARINC Labels
203
210
212
314

5.1.1.4 ARINC 429 Port Output Configuration

The ARINC 429 output data formats and speed configuration settings are described in the
following tables:
FFS Copyright © 2020 All rights reserved.
Table 11. ADC Format Input ARINC Labels
Label
Pressure Altitude
Airspeed
Altitude Rate
Table 12. AHRS Format Input ARINC Labels
Label
True Heading
Label
Pressure Altitude
Airspeed
Altitude Rate
True Heading
Table 14.Traffic Format Input ARINC Labels
Label
TCAS Output – Receiver health in System Status
274
Fault Summary – Traffic Advisory (TA) only mode
350
set in Resolution Instruction (RI) field
314
Request to Send (RTS) and (End of Transmission)
357
ETX words for Intruder File
130
131
132
ADS-B FDL-DB Dual Band Series
Document No. 88552 Rev A
Description
Description
Description
Description
True Heading
Intruder Range
Intruder Altitude
Intruder Bearing
Installation Manual
5-13
