Figure 11: Tera Term Network Connection Settings using a Remote Network Server Port

5.2.1.2 Initial MPI Connection using the Telnet Remote Network Server Port

Once connected to the MPI with a Remote TCP/UDP network connection, press the Enter key
once to remove the maintenance lockout. The following prompt should be displayed:
•
RANGR-RX>
•
RANGR-XVR>

Figure 12: Example Tera Term Network Connection Settings using Telnet

FFS Copyright © 2020 All rights reserved.
FDL-DB-RX
FDL-DB-XVR
ADS-B FDL-DB Dual Band Series
Installation Manual
Document No. 88552 Rev A
5-21
