Usb Interface; Ethernet Interface; Mpi Pinout - FreeFlight ADS-B FDL-DB Dual Band Series Installation Information

ADS-B FDL-DB Dual Band Series
Installation Manual
Document No. 88552 Rev A
The table below shows the MPI DE-9F connections to Port 5 on the FDL-DB Series.
An FFS fixed installation Serial-to-Wi-Fi Transceiver (P/N 86943-00) can be connected to Port
5. The MPI functionality can then be accessed wirelessly using the ADS-B MPI app.
When Port 5 is configured and interfaced to other equipment (e.g. displays etc.)
the connections to the configured device must be temporarily disconnected to use
the port for MPI purposes.
2.5.10.1

USB Interface

The standard USB interface that can be used as an MPI Only for connection to a computer's
USB connection.
PIN SIGNAL
J1-16 USB VBUS
J1-38 USB D-
J1-37 USB D+
J1-35 GND
2.5.10.2

Ethernet Interface

The 10/100 Ethernet interface is a standard interface that connect to a computer Ethernet port,
Ethernet Switch/Router, Ethernet to Wi-Fi module, non-certified Ethernet compatible display,
etc. The Ethernet interface is uncertified and therefore an only connect to devices supporting
non-certified functionality such as MPI or un-certified traffic and FIS-B information display on
portable devices.
PIN SIGNAL
J1-21 Ethernet RX+
J1-20 Ethernet RX-
J1-42 Ethernet TX+
J1-41 Ethernet TX-
2-28
Table 1. MPI Pinout
MPI Connector
PIN SIGNAL
2 Tx
3 Rx
5 GND
USB Interface
ELECTRICAL I/O DESCRIPTION
+5VDC Pwr USB +5VDC
USB/Serial I/O USB Data- or U5 TX (TTL Serial)
USB/Serial I/O USB Data+ or U5 RX (TTL Serial)
Ground G USB Ground
Ethernet Interface
ELECTRICAL I/O DESCRIPTION
Ethernet I Ethernet Port Receive +
Ethernet I Ethernet Port Receive -
Ethernet O Ethernet Port Transmit +
Ethernet O Ethernet Port Transmit -
Port 5 (DB-62)
PIN SIGNAL
J1-54 232 TxD5
J1-32 232 RxD5
J1-9 SGND4
