ADS-B FDL-DB Dual Band Series
Installation Manual
Document No. 88552 Rev A
Label
111
120
121
125
103
112
130
133
165
166
174
136
247
260
370
142
145
140
141
150
352
Data content must conform to the navigation data block of ARINC 743A/B.
Label
Label 016 or 031 must be present as a minimum.
5-12
Longitude
Latitude Fine
Longitude Fine
UTC
Track Angle
Ground Speed
HIL
VIL
Vertical Velocity
N/S Velocity
E/W Velocity
VFOM
HFOM
Date (BCD)
Height Above Ellipsoid
Velocity Vertical FOM
Velocity Horizontal FOM
UTC, fine
UTC, fine fraction
UTC
FreeFlight Maintenance
Table 10. Transpnder-Cntrl Input ARINC Labels
016 TCAS/ATC Control (Squawk Code and IDENT only)
031 ATCRBS Control (Squawk Code and IDENT only)
233 Call Sign/Flight ID Characters 1&2
234 Call Sign/Flight ID Characters 3&4
235 Call Sign/Flight ID Characters 5&6
236 Call Sign/Flight ID Characters 7&8
Description
Description
