CyberData 011146 Operation Manual page 53

2. On the SSL page, enter values for the parameters indicated in
Note
Web Page Item
Server CAs
Device Certificate
Device CA
Client Certificate
Client CA
Test SSL Connection
Server
Port
CyberData Corporation
The question mark icon (
after the Toggle Help button is pressed
Table 2-10. SSL Configuration Parameters
Description
Use this button to select a configuration file to import.
Click Browse to select a CA certificate to import. After selecting a server
certificate authority (CA), click Import CA Certificate to import it to the list of
trusted CAs. CAs are used to validate the certificate presented by the server
when establishing a TLS connection.
Restore Defaults will restore the default list of registered CAs and Remove All
will remove all registered CAs.
Restore Defaults will restore the default list of registered CAs and Remove All
will remove all registered CAs.
Click on the Toggle Help button to see a short description of some of the web
page items. First click on the Toggle Help button, and you will see a question
mark ( ) appear next to some of the web page items. Move the mouse pointer
to hover over a question mark to see a short description of a specific web page
item.
When doing mutual authentication this device will present a client certificate with
these parameters.
Right click and Save Link As... to get the Cyberdata Device CA used to sign this
client certificate.
Use this button to select a configuration file to import.
Click Browse to select a CA certificate to import. After selecting a server
certificate authority (CA), click Import Device Certificate to import it to the list of
trusted Device Certificates. Device Certificates are used to validate the
certificate presented by the server when establishing a TLS connection.
Restore the device's default certificate. This will remove any user-uploaded
Device Certificate. (Server CAs and Trusted CAs are unaffected).
When doing mutual authentication this device will present a client certificate with
these parameters.
Right click and Save Link As... to get the Cyberdata CA used to sign this client
certificate.
The ssl test server address as a fully qualified domain name or in IPv4 dotted
decimal notation.
The ssl test server port. The supported range is 0-65536. SIP connections over
TLS to port 5060 will do the same.
931803A
) in the following table shows which web page items will be defined
.
Setting Up the SIP Paging Server
Configure the SSL Parameters
Table 2-10.
Operations Guide
45
